— P0725 ENGINE SPEED
TM-112
P0729 P0729 6GR INCORRECT RATIO TM-114
P0730 P0730 INCORRECT GR RATIOTM-116
P0731 P0731 1GR INCORRECT RATIOTM-118
P0732 P0732 2GR INCORRECT RATIOTM-120
P0733 P0733 3GR INCORRECT RATIOTM-122
P0734 P0734 4GR INCORRECT RATIOTM-124
P0735 P0735 5GR INCORRECT RATIOTM-126
P0740 P0740 TORQUE CONVERTERTM-128
P0744 P0744 TORQUE CONVERTERTM-129
P0745 P0745 PC SOLENOID ATM-131
P0750 P0750 SHIFT SOLENOID ATM-132
P0775 P0775 PC SOLENOID BTM-133
P0780 P0780 SHIFTTM-134
P0795 P0795 PC SOLENOID CTM-136
— P1705 TP SENSORTM-137
— P1721 VEHICLE SPEED SIGNALTM-138
P1730 P1730 INTERLOCK TM-140
P1734 P1734 7GR INCORRECT RATIOTM-142
— P1815 M-MODE SWITCHTM-144
P2713 P2713 PC SOLENOID D TM-147
P2722 P2722 PC SOLENOID ETM-148
P2731 P2731 PC SOLENOID FTM-149
P2807 P2807 PC SOLENOID GTM-150
— U0300 CAN COMM DATATM-102
U1000 U1000 CAN COMM CIRCUIT TM-103
DTC*1
Items
(CONSULT-III screen terms) Reference
MIL*2, “ENGINE” with
CONSULT-III or GST CONSULT-III only
“TRANSMISSION”
Revision: 2010 May2011 QX56

ADDITIONAL SERVICE WHEN REPLACING TRANSMISSION ASSEMBLY
TM-91
< BASIC INSPECTION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
ADDITIONAL SERVICE WHEN REPL ACING TRANSMISSION ASSEMBLY
DescriptionINFOID:0000000006233270
Decel G sensor calibration must be performed when replacing A/T assembly.
Special Repair RequirementINFOID:0000000006233271
1.PREPARATION BEFORE CALIBRATION PROCEDURE
1. Park the vehicle on a flat road.
2. Adjust pressure in all tires to the specified value. Refer to WT-69, "
Tire Air Pressure".
>> GO TO 2.
2.PERFORM CALIBRATION
With CONSULT-III
1. Turn ignition switch ON.
CAUTION:
Never start the engine.
2. Select “G SENSOR CALIBRATION” in “Work Support” in “TRANSMISSION”.
3. Touch “START”. CAUTION:
Never give any motion to the vehicle during the calibration.
Is
“completed” displayed?
YES >> GO TO 3.
NO >> Perform the calibration again.
3.CHECK DTC
With CONSULT-III
1. Turn ignition switch OFF and wait 10 seconds or more.
2. Turn ignition switch ON.
3. Select “Self Diagnostic Results” in “ABS”.
Is
“C1145” or “C1146” detected?
YES >> Refer to BRC-51, "DTC Index".
NO >> Calibration end.
Revision: 2010 May2011 QX56

TM-92
< BASIC INSPECTION >[7AT: RE7R01B]
ADDITIONAL SERVICE WHEN RE
PLACING CONTROL VALVE & TCM
ADDITIONAL SERVICE WHEN REPLACING CONTROL VALVE & TCM
DescriptionINFOID:0000000006233274
Decel G sensor calibration must be performed when replacing control valve & TCM.
Special Repair RequirementINFOID:0000000006233275
1.PREPARATION BEFORE CALIBRATION PROCEDURE
1. Park the vehicle on a flat road.
2. Adjust pressure in all tires to the specified value. Refer to WT-69, "
Tire Air Pressure".
>> GO TO 2.
2.PERFORM CALIBRATION
With CONSULT-III
1. Turn ignition switch ON.
CAUTION:
Never start the engine.
2. Select “G SENSOR CALIBRATION” in “Work Support” in “TRANSMISSION”.
3. Touch “START”. CAUTION:
Never give any motion to the vehicle during the calibration.
Is
“completed” displayed?
YES >> GO TO 3.
NO >> Perform the calibration again.
3.CHECK DTC
With CONSULT-III
1. Turn ignition switch OFF and wait 10 seconds or more.
2. Turn ignition switch ON.
3. Select “Self Diagnostic Results” in “ABS”.
Is
“C1145” or “C1146” detected?
YES >> Refer to BRC-51, "DTC Index".
NO >> Calibration end.
Revision: 2010 May2011 QX56

CALIBRATION OF DECEL G SENSORTM-93
< BASIC INSPECTION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
CALIBRATION OF DECEL G SENSOR
DescriptionINFOID:0000000006233272
Decel G sensor calibration must be performed when the following operation is performed.
 Removal and installation or replacem ent of yaw rate/side/decel G sensor
 Replacement of A/T assembly
 Replacement of ABS actuator and electric unit (control unit)
CAUTION:
After removing/replacing the yaw rate/side/decal G sensor or replaci ng the ABS actuator and electric
unit (control unit), the decel G sensor of the ABS act uator and electric unit (control unit) must be cali-
brated first. Refer to BRC-66, "
Description".
Special Repair RequirementINFOID:0000000006233273
CAUTION:
After removing/replacing the yaw rate/side/decal G sensor or replaci ng the ABS actuator and electric
unit (control unit), the decel G sensor of the ABS act uator and electric unit (control unit) must be cali-
brated first. Refer to BRC-66, "
Description".
1.PREPARATION BEFORE CALIBRATION PROCEDURE
1. Park the vehicle on a flat road.
2. Adjust pressure in all tires to the specified value. Refer to WT-69, "
Tire Air Pressure".
>> GO TO 2.
2.PERFORM CALIBRATION
With CONSULT-III
1. Turn ignition switch ON. CAUTION:
Never start the engine.
2. Select “G SENSOR CALIBRATION” in “Work Support” in “TRANSMISSION”.
3. Touch “START”. CAUTION:
Never give any motion to the vehicle during the calibration.
Is
“completed” displayed?
YES >> GO TO 3.
NO >> Perform the calibration again.
3.CHECK DTC
With CONSULT-III
1. Turn ignition switch OFF and wait 10 seconds or more.
2. Turn ignition switch ON.
3. Select “Self Diagnostic Results” in “ABS”.
Is
“C1145” or “C1146” detected?
YES >> Refer to BRC-51, "DTC Index".
NO >> Calibration end.
Revision: 2010 May2011 QX56

P0710 TRANSMISSION FLUID TEMPERATURE SENSOR A
TM-107
< DTC/CIRCUIT DIAGNOSIS > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0710 TRANSMISSION FLUI D TEMPERATURE SENSOR A
DTC LogicINFOID:0000000006226806
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” is previously c onducted, always turn ignition switch OFF and wait at
least 10 seconds before performing the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT-III
1. Start the engine.
2. Select “SLCT LVR POSI” and “VHCL/S SE-A/T ” in “Data Monitor” in “TRANSMISSION”.
3. Drive vehicle and maintain the following conditions for 14 minutes or more.
4. Perform “Self Diagnostic Resu lts” in “TRANSMISSION”.
With GST
Follow the procedure “With CONSULT-III”.
Is
“P0710” detected?
YES >> Go to TM-107, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006226807
1.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace the control valve & TCM. Refer to TM-182, "Exploded View".
DTC Trouble diagnosis name DTC is detected if... Possible cause
P0710 Transmission Fluid Tempera-
ture Sensor A Circuit TCM judges that the A/T fluid temperature is -40
°C (-40
° F) or less continuously for 5 seconds while driving at 10
km/h (7 MPH) or more.  Harness or connectors
(Sensor circuit is open.)
 A/T fluid temperature sensor
TCM judges that the A/T fluid temperature is 180 °C (356
° F) or more continuously for 5 seconds.  Harness or connectors
(Sensor circuit is short.)
 A/T fluid temperature sensor
TCM judges the following conditions while driving the ve-
hicle at 10 km/h (7 MPH) or more:
 The time required for A/T fluid temperature to rise by 1 °C (1.8 °F) exceeds 14 minutes when A/T fluid tem-
perature is -20 °C (-4 °F) or less.
 The time required for A/T fluid temperature to rise by 1 °C (1.8 °F) exceeds 7 minutes when A/T fluid tem-
perature is between -19 °C (-2 °F) and 0 °C (32 °F).
 The time required for A/T fluid temperature to rise by 1 °C (1.8 °F) exceeds 4 minutes when A/T fluid tem-
perature is between 1 °C (34 °F) and 20 °C (68 °F).  Harness or connectors
(Sensor circuit is stuck.)
 A/T fluid temperature
sensor
SLCT LVR POSI : D
VHCL/S SE-A/T : 10 km/h (7 MPH) or more
Revision: 2010 May2011 QX56

TM-108
< DTC/CIRCUIT DIAGNOSIS >[7AT: RE7R01B]
P0710 TRANSMISSION FLUID
TEMPERATURE SENSOR A
NO >> Repair or replace damaged parts.
Revision: 2010 May2011 QX56

P0717 INPUT SPEED SENSOR ATM-109
< DTC/CIRCUIT DIAGNOSIS > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0717 INPUT SPEED SENSOR A
DTC LogicINFOID:0000000006226808
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” is previously c onducted, always turn ignition switch OFF and wait at
least 10 seconds before performing the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT-III
1. Start the engine.
2. Select “SLCT LVR POSI”, “GEAR”, “VHCL/S SE-A/ T”, “W/O THL POS” and “ENGINE SPEED” in “Data
Monitor” in “TRANSMISSION”.
3. Drive vehicle and maintain the following conditions for 5 seconds or more. CAUTION:
Keep the same gear position.
NOTE:
Driving the vehicle uphill (increased engine load) will hel p maintain the driving conditions required for this
test.
4. Perform “Self Diagnostic Resu lts” in “TRANSMISSION”.
With GST
Follow the procedure “With CONSULT-III”.
Is
“P0717” detected?
YES >> Go to TM-109, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006226809
1.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace the control valve & TCM. Refer to TM-182, "Exploded View".
NO >> Repair or replace damaged parts.
DTC Trouble diagnosis name DTC is detected if... Possible cause
P0717 Input/Turbine Speed Sensor A
Circuit No Signal The revolution of input speed
sensor 1 and/or 2 is 270 rpm or
less. Harness or connectors
(Sensor circuit is open.)
 Input speed sensor 1 and/or 2
SLCT LVR POSI : D
GEAR : 2nd, 3rd, 4th, 5th or 6th
VHCL/S SE-A/T : More than 40 km/h (25 MPH)
W/O THL POS : ON
ENGINE SPEED : More than 1,500 rpm
Revision: 2010 May2011 QX56

TM-110
< DTC/CIRCUIT DIAGNOSIS >[7AT: RE7R01B]
P0720 OUTPUT SPEED SENSOR
P0720 OUTPUT SPEED SENSOR
DTC LogicINFOID:0000000006226810
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
 Always drive vehicle at a safe speed.
 Be careful not to rev engine into
the red zone on the tachometer.
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” is previously c onducted, always turn ignition switch OFF and wait at
least 10 seconds before performing the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT-III
1. Start the engine.
2. Select “ESTM VSP SIG” in “Data Monitor” in “TRANSMISSION”.
3. Drive vehicle and maintain the following conditions for 60 seconds or more.
4. Perform “Self Diagnostic Results” in “TRANSMISSION”.
With GST
Follow the procedure “With CONSULT-III”.
Is
“P0720” detected?
YES >> Go to TM-110, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006226811
1.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
Is the inspection result normal?
DTC Trouble diagnosis name DTC is detected if... Possible cause
P0720 Output Speed Sensor Circuit  The vehicle speed detected
by the output speed sensor is
5 km/h (3MPH) or less when
the vehicle speed transmitted
from the combination meter
to TCM is 20 km/h or more.
(Only when starts after the ig-
nition switch is turned ON.)
 The vehicle speed transmit- ted from the combination
meter to TCM does not de-
crease despite the 36 km/h
(23 MPH) or more of deceler-
ation in vehicle speed detect-
ed by the output speed
sensor. when the vehicle
speed detected by the output
speed sensor is 36 km/h (23
MPH) or more and the vehicle
speed transmitted from the
combination meter to TCM is
24 (15 MPH) or more.  Harness or connectors
(Sensor circuit is open.)
 Output speed sensor
ESTM VSP SIG : 40 km/h (25 MPH) or more
Revision: 2010 May2011 QX56
