2011 HONDA PILOT key

µµ
µ
µ
The ignition switch has f our
positions: LOCK (0), ACCESSORY
(I), ON (II), and START (III).
You can insert or
remove the key only in this position.
To turn the key to the LOCK (0)
position, the shif t lever must be in
Park, and you must push the key in
slightly. If the f ront wheels are turned, the
anti-theft lock may make it difficult
to turn the key. Firmly turn the
steering wheel to the lef t or right as
you turn the key.
You can
operate the audio system and the
accessory power sockets in this
position.
This is the normal key
position when driving. Several of the
indicators on the instrument panel
come on as a test when you turn the
ignition switch f rom the
ACCESSORY (I) to the ON (II)
position.
Use this position
only to start the engine. The switch
returns to the ON (II) position when
you let go of the key. You will hear a reminder beeper if
you leave the key in the ignition
switch in the LOCK (0) or the
ACCESSORY (I) position and open
the driver’s door. Remove the key to
turn of f the beeper.
You will also see a ‘‘REMOVE KEY’’
message on the multi-information
display (see page ).
TheshiftlevermustbeinPark
bef ore you can remove the key f rom
the ignition switch.
96
On vehicles with navigation system
Ignition Switch
LOCK (0) A CCESSORY (I)
ON (II)
ST A RT (III)
Inst rument s and Cont rols
137
10/01/26 18:46:14 31SZA620_142
2011 Pilot

All doors and the tailgate can be
locked f rom the outside by using the
key in the driver’s door lock. To
unlock only the driver’s door, insert
the key, turn the key, and release it.
The remaining doors and the tailgate
unlock when you turn the key a
second time within a f ew seconds. The lock tab on any passenger’s door
locks and unlocks that door.To change the ‘‘KEY AND REMOTE
UNLOCK MODE’’ setting, see page
.
To lock all doors and the tailgate,
push the top of the master door lock
switch on either f ront door, pull the
locktabrearwardonthedriver’s
door, or use the key on the outside
lock on the driver’s door.
Pushing the rear of either master
door lock switch will unlock all doors
and the tailgate. Pushing f orward the
lock tab on the driver’s door unlocks
only that door. When the vehicle speed reaches
about 10 mph (U.S.) and 15 km/h
(Canada) or more, all the doors lock
automatically.
To change the ‘‘AUTO DOOR
UNLOCK’’ setting, see page . When you shif t to P af ter driving, the
driver’s door unlocks. To change the ‘‘AUTO DOOR
LOCK’’ setting, see page .
119
117
116
On vehicles with navigation system
Door L ocks
138
Lock
Unlock Lock
Unlock
10/01/26 18:46:25 31SZA620_143
2011 Pilot

With any door and the tailgate open
andthekeyintheignition,both
master door lock switches are
disabled. They are not disabled if all
thedoorsandthetailgateareclosed.
If you try to lock an open driver’s
door by pulling the lock tab rearward
the lock tab on the driver’s door pops
out.The childproof door locks are
designed to prevent children seated
in the rear f rom accidentally opening
the rear doors. Each rear door has a
lock lever near the edge. With the
lever in the LOCK position (lever is
down), the door cannot be opened
fromtheinsideregardlessof the
position of the lock tab. To open the
door, push the lock tab f orward and
use the outside door handle.Make sure the shif t lever is in the
Park (P) position.
To open the tailgate, press and hold
the switch, then lift up. To close the
tailgate, use the inner handle to pull
it down, then press down on the back
edge.
L ockout Prevent ionChildproof Door L ocks
T ailgate
Door L ocks, T ailgat e and Glass Hat ch
144
Lock
10/01/26 18:47:46 31SZA620_149
2011 Pilot

µ
µ Pressthisbuttononce
to unlock the driver’s door. Push it
twice to unlock the other doors.
Some exterior lights will f lash twice
when you push the button. If you do
not open any door or the tailgate
within 30 seconds, they will
automatically relock.
To change the ‘‘KEY AND REMOTE
UNLOCK MODE’’ setting, see page .
To change the ‘‘SECURITY
RELOCK TIMER’’ setting, see page .
Press this button once to
lock all doors and the tailgate. Some
exterior lights will f lash. When you
push LOCK twice within 5 seconds,
you will hear a beep to verify that the
doors and tailgate are locked and the
security system has set. This button
does not work if any door or tailgate
is not f ully closed. To change the ‘‘KEYLESS LOCK
ACKNOWLEDGEMENT’’ setting,
see page .
120 119
121
On vehicles with navigation system
On vehicles with navigation system
Remote Transmitter
UNL OCK
LOCK
150
Except Touring models On Touring models
UNLOCK
BUTTON UNLOCK
BUTTON
LOCK
BUTTON
PANIC
BUTTON LOCK
BUTTON
PANIC
BUTTON TAILGATE
BUTTON
GLASS
HATCH
RELEASE
BUTTON
10/01/26 18:48:47 31SZA620_155
2011 Pilot

µ
µ
µ Press and hold this
button for about 1 second to attract
attention; the horn will sound, and
the exterior lights will f lash f or about
30 seconds. To cancel panic mode,
press any other button on the remote
transmitter, or turn the ignition
switch to the ON (II) position. Panic
mode does not work when the key is
in the ignition switch.
Avoid dropping or throwing the
transmitter.
Protect the transmitter from
extreme temperature.
Do not immerse the transmitter in
any liquid.
If you lose a transmitter, the
replacement needs to be
reprogrammed by your dealer.
When you press the UNLOCK
button, the f ront and rear individual
map lights and the cargo area light,
depending on their switch positions,
will come on (see page ). If you
do not open any door or the tailgate,
the lights stay on for about 30
seconds, then go out. If you relock
thedoorsandthetailgatewiththe
remote transmitter before 30
seconds have elapsed, the lights will
go of f immediately.
If you push the same button again
while the tailgate is opening or
closing, three beeps sound, the
tailgate stops moving, reverses
direction and stops in the f ully
opened or f ully closed position.Press and hold the
TAILGATE button to open or close
the power tailgate. When the tailgate
begins to move, you will hear a beep,
and some f ront and rear lights will
flash.
Press this button f or about 1 second
to open the glass hatch. Even if the
glass hatch is open, the tailgate can
be locked with the remote
transmitter. 176
Except Touring models
On Touring models
Remote Transmitter
PA NIC
TAILGATE
GLASS HATCH RELEASE
Remote Transmitter Care
Inst rument s and Cont rols
151
10/01/26 18:48:59 31SZA620_156
2011 Pilot

Inside the transmitter, separate
the inner cover f rom the keypad
by releasing the two tabs on the
cover.
If it takes several pushes on the
button to lock or unlock the doors
and the tailgate, replace the battery
as soon as possible.
Battery type: CR1616
To replace the battery:Remove the screw at the base of
the transmitter with a small
Phillips-head screwdriver.
Separate the transmitter by prying
its middle seam with your
f ingernail. 3.
1.
2.
Remote Transmitter
Replacing the Transmitter
Battery
152
SCREW BATTERY
10/01/26 18:49:09 31SZA620_157
2011 Pilot

´
As required by the FCC:This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device. On Touring modelsRemove the old battery, and insert
a new battery into the back of the
cover with the side f acing down.
Install the parts in reverse order. An improperly disposed of battery
can hurt the environment.
Always conf irm local regulations
for battery disposal.
When you unlock the door with your
remote, each remote activates the
keyless memory settings related to
that remote. The driver’s ID (Driver
1orDriver2)isshownontheback
of each remote.
4.
5.
CONT INUED
Remote Transmitter
K eyless Memory Settings
Inst rument s and Cont rols
153
TM
10/01/26 18:49:19 31SZA620_158
2011 Pilot

Insert the key in the driver’s door
lock.
Turn the key clockwise, then
release it.Turnthekeyclockwiseagain,and
hold it. All f our windows and the
moonroof start to open. To stop
the windows and the moonroof ,
release the key.
To open:
You cannot close the windows or the
moonroof with the remote
transmitter. To open the windows and
moonroof f urther, press the
button again (within 10 seconds of
step 1) and hold it. If the windows
and the moonroof stop bef ore the
desired position, repeat steps 1
and 2. Press the UNLOCK button a
second time, and hold it. All the
doors unlock, and all f our windows
and moonroof start to open. To
stop the windows and moonroof ,
release the button. Press the UNLOCK button once
to unlock the driver’s door.
To open the windows and the
moonroof f urther, turn and hold
the key again (within 10 seconds
of step 2).
To close: Insert the key in the driver’s door
lock.
Turn the key counterclockwise,
then release it.
Turn the key counterclockwise
again, and hold it. All four
windows and the moonroof start to
close. To stop the windows and
the moonroof , release the key.
You can open all of the windows and
the moonroof (if equipped) f rom the
outside with the remote transmitter.
You can open and close the windows
and the moonroof (if equipped) with
the key in the driver’s door lock.
1.
2.
2.
3. 3.
1.
2.
3. 4.
1.
CONT INUED
Opening/Closing the Windows
and Moonroof with the K ey
Opening the Windows and
Moonroof with the Remote
Transmitter
Power Windows
Inst rument s and Cont rols
167
10/01/26 18:51:55 31SZA620_172
2011 Pilot
