2011 HONDA ODYSSEY Fluid

If it remains on af ter you have
fully released the parking brake
while the engine is running, or if it
comes on while driving, there
could be a problem with the brake
system. For more inf ormation, see
page .
You will also see a ‘‘BRAKE
FLUID LOW’’ or ‘‘CHECK
BRAKE SYSTEM’’ message on
the multi-information display (see
page ).
This indicator has two f unctions:
Itcomesonwhenyouturnthe
ignition switch to the ON (II)
position. It is a reminder to check
the parking brake. A beeper
sounds if you drive with the
parking brake not f ully released.
Driving with the parking brake not
fully released can damage the
brakes and tires.
You will also see a ‘‘RELEASE
PARKING BRAKE’’ message on
the multi-information display (see
page ) . You will also see a ‘‘CHECK
AIRBAG SYSTEM’’ message on the
multi-inf ormation display (see page
).
This indicator comes on f or several
seconds when you turn the ignition
switch to the ON (II) position. If it
comes on at any other time, it
indicates a potential problem with
your f ront airbags. This indicator will
also alert you to a potential problem
with your airbag system components.
For more inf ormation, see page .
1. 2.
90 90
32
90 672On Touring models
On Touring models
On Touring models
Instrument Panel Indicators
Supplemental Restraint
System (SRS) Indicator
Parking Brake
and Brake
System
Indicator (Red)
Instruments and Controls
67
Canada
U.S.
10/07/17 09:43:19 31TK8600_072
2011 Odyssey

This indicator comes on when the
washer f luid level is low. Add washer
f luid when you see this indicator
come on (see page ).
You will also see a ‘‘WASHER
FLUID LOW’’ message on the multi-
inf ormation display (see page ).This indicator is in the f uel gauge. It
comesonasareminderthatyou
must ref uel soon.
When the indicator comes on, there
are about 3.0 US gal (11.4
)of fuel
remaining in the tank.
When the needle reaches E, there is
a very small amount of f uel in the
tank. You will also see a ‘‘FUEL LOW’’
message on the multi-information
display (see page ).
This indicator comes on f or a f ew
seconds when you turn the ignition
switch to the ON (II) position. If it
comes on at any other time, there is
a problem in the power tailgate
system. Have the system checked by
your dealer as soon as possible. You
can still open or close the tailgate
manually. For more inf ormation on
the power tailgate, see page .
You will also see a ‘‘CHECK POWER
TAILGATE SYSTEM’’ message on
the multi-information display.
92 92
162
620
On Canadian models
On Canadian Touring models On Touring models
On Touring models
On EX-L modelsInstrument Panel Indicators
Low Fuel Indicator
Washer Level Indicator
Power Tailgate
Indicator
74
WASHER LEVEL INDICATOR
LOW FUEL INDICATORU.S. Canada
10/07/19 15:50:48 31TK8600_079
2011 Odyssey

Any hitch used on your vehicle must
be properly bolted to the underbody,
using the six threaded holes
provided. A hitch and the required
f luid coolers designed especially f or
your Odyssey can be obtained f rom
your Honda dealer.Always use saf ety chains when you
tow a trailer. Make sure the chains
are secured to the trailer and hitch,
and that they cross under the tongue
and can catch the trailer if it
becomes unhitched. Leave enough
slack to allow the trailer to turn
corners easily, but do not let the
chains drag on the ground.
An additional ATF (automatic
transmission f luid) cooler should be
installed. This device will help
prevent automatic transmission
overheating, which could cause
serious damage. The additional ATF
cooler can be obtained f rom your
dealer.
Your vehicle is designed to tow
without the need f or a load
distributing hitch. If you wish to use
one, please consult your trailer
maker f or proper installation and set-
up. Improper set-up could degrade
the handling, stability, and braking
perf ormance of your vehicle. A sway control device helps
minimize swaying that can occur in
crosswinds and in normal and
emergency driving maneuvers. If
you experience swaying when
pulling your trailer, consult the
trailer maker f or the specif ic type of
device and how to install it properly.
CONT INUED
Hitches
Weight Distributing Hitch Saf et y Chains
Sway Cont rol
A ut omat ic T ransmission FluidCooler
Towing a Trailer
Driving
591
10/07/17 10:53:34 31TK8600_596
2011 Odyssey

This section explains why it is
important to keep your vehicle well
maintained and how to f ollow basic
maintenance saf ety precautions.
If you have the skills and tools to
perf orm more complex maintenance
tasks on your vehicle, you may want
to purchase the service manual. See
page f or inf ormation on how to
obtain a copy, or see your dealer.U.S. Vehicles:
This section also includes
instructions on how to read the
Maintenance Minder messages on
the inf ormation display or multi-
inf ormation display (depending on
models), and instructions f or simple
maintenance tasks you may want to
take care of yourself . ......................
Maintenance Saf ety .598
.................
Maintenance Minder . 599
..............................
Fluid Locations .613
........................
Adding Engine Oil .614
Changing the Engine Oil and ...........................................
Filter .616
..............................
Engine Coolant .618
....................
Windshield Washers .620
....
Automatic Transmission Fluid . 621
....................................
Brake Fluid .623
....................
Power Steering Fluid . 624
....................................
Timing Belt .624
.............................................
Lights .625
................
Cleaning the Seat Belts . 636
..................
Dust and Pollen Filter . 636
.....................................
Floor Mats .637
.................................
Wiper Blades .638
...........................................
Wheels .642
...............................................
Tires .642
...................
Checking the Battery . 649
.............................
Vehicle Storage .651
..................................
Interior Care .652
707
Maintenance
Maintenance, replacement, or
repair of emissions control
devices and systems may be done
by any automotive repair
establishment or individual using
parts that are ‘‘certif ied’’ to EPA
standards.
Maint enance
597
TM
10/07/17 10:54:18 31TK8600_602
2011 Odyssey

Î
Î
Ì Ì
µ
µ
Ì
ÎMaintenance Minder612
:
TM
Maintenance Main Items
Replace engine oil
Replace engine oil and oil filter
Inspect front and rear brakes
Check parking brake adjustment
Inspect these items: Tie rod ends, steering gear box, and boots
Suspension components
Driveshaft boots
Brake hoses and lines (including ABS/VSA)
All fluid levels and condition of fluids
Exhaust system
Fuel lines and connections Maintenance Sub Items
Rotate tires
Replace air cleaner element If you drive in dusty conditions, replace
every 15,000 miles (24,000 km).
Replace dust and pollen filter If you drive primarily in urban areas that have high
concentrations of soot in the air from industry and
from diesel-powered vehicles, replace every 15,000
miles (24,000 km).
Inspect drive belt
Replace transmission fluid
Replace spark plugs
Replace timing belt and inspect water pump If you drive regularly in very high temperatures (over
110°F, 43°C), in very low temperatures (under 20°F,
29°C), replace every 60,000 miles/100,000 km.
Inspect valve clearance
Replace engine coolant
A
B
Symbol
Symbol
1
2
3
4
5
1
1
See information on maintenance and emissions warranty in the first column
on page .
Adjust the valves during services A, B, 1, 2, or 3 only if they are noisy. Inspect idle speed every 160,000 miles (256,000 km).
If the message ‘‘SERVICE DUE NOW’’ does not appear within 12 months
after the display was last reset, change the engine oil every year.
Independent of the Maintenance Minder information, replace the brake
fluid every 3 years.
NOTE: 1:
611
Maintenance Minder
10/07/17 10:56:13 31TK8600_617
2011 Odyssey

Fluid Locations
Maint enance
613
ENGINE OIL DIPSTICK
(Orange loop)RADIATOR CAP
POWER STEERING FLUID
(Red cap)
WASHER FLUID
(Blue cap)
ENGINE COOLANT RESERVOIR
BRAKE FLUID
(Black cap)
AUTOMATIC
TRANSMISSION
FLUID DIPSTICK
(Yellow loop)
ENGINE OIL FILL CAP
10/07/17 10:56:17 31TK8600_618
2011 Odyssey

Check the f luid level in the
windshield washer reservoir at least
monthly during normal use. This
reservoir supplies the windshield and
rear window washers.
Check the f luid level by removing
the cap and looking at the level
gauge attached to the cap.The low washer
level indicator comes on when the
level is low (see page ).
You will also see a ‘‘WASHER
FLUID LOW’’ message on the multi-
inf ormation display (see page ). Fill the reservoir with a good-quality
windshield washer f luid. This
increases the cleaning capability and
prevents f reezing in cold weather.
When you ref ill the reservoir, clean
the edges of the windshield wiper
blades with windshield washer f luid
on a clean cloth. This will help to
condition the blade edges.
74 92
On Canadian models:On Canadian Touring model:
Windshield Washers620
LEVEL GAUGE
Do not use engine antif reeze or a
vinegar/water solution in the
windshield washer reservoir. Antif reeze
can damage your vehicle’s paint, while
a vinegar/water solution can damage
the windshield washer pump. Use only
commercially-available windshield
washer f luid.
10/07/17 10:57:08 31TK8600_625
2011 Odyssey

CONT INUED
Insert the dipstick all the way into
the transmission securely as
shown in the illustration.
Remove the dipstick, and check
the f luid level. It should be
between the upper and lower
marks.
Remove the dipstick (yellow loop)
f rom the transmission, and wipe it
with a clean cloth.
Check the f luid level with the engine
at normal operating temperature.
Park the vehicle on level ground.
Start the engine, let it run until the
radiator f an comes on, then shut
of f the engine. For accurate
results, wait about 60 seconds (but
no longer than 90 seconds) bef ore
doing step 2.
1.
2.
3.
4.
Automatic Transmission Fluid
Maint enance
621
DIPSTICK UPPER MARK
LOWER MARK
Except Touring models
Touring models
DIPSTICK Except Touring models
10/07/17 10:57:16 31TK8600_626
