2011 HONDA ODYSSEY fuse

This section covers the more
common problems that motorists
experience with their vehicles. It
gives you inf ormation about how to
safely evaluate the problem and what
to do to correct it. If the problem has
stranded you on the side of the road,
you may be able to get going again.
If not, you will also f ind instructions
on getting your vehicle towed.......................
Compact Spare Tire .654
....................
Changing a Flat Tire .655
.............
If the Engine Won’t Start . 662
................................
Jump Starting .665
..............
If the Engine Overheats . 667
.........
Low Oil Pressure Indicator . 669
..........
Charging System Indicator . 670
.......
Malf unction Indicator Lamp . 671
...............
Brake System Indicator . 672
..............................................
Fuses .673
..............................
Fuse Locations .678
......................
Emergency Towing .683
Taking Care of the Unexpected
Taking Care of the Unexpected
653
10/07/17 11:01:44 31TK8600_658
2011 Odyssey

The vehicle’s f uses are located in
five fuse boxes.
Thedriver’ssideinteriorfuseboxis
under the dashboard on the driver’s
side. The fuse label is attached to the
side panel.Therearfuseboxislocatedatthe
lef t side of cargo area.
Place a cloth on the edge of the
cover to prevent scratches, then
remove it by caref ully prying in the
notch on its middle edge with a small
f lat-tip screwdriver.
The passenger’s side interior f use
box is under the dashboard. Push
down the tab and slide the cover
upward to remove it.
CONT INUED
Fuses
Taking Care of the Unexpected
673
INTERIOR (Driver’s side)
INTERIOR (Passenger’s side)INTERIOR (Rear)
FUSE LABEL NOTCH
COVER
COVER
NOTCH
10/07/17 11:04:14 31TK8600_678
2011 Odyssey

µ
The primary under-hood f use box is
locatedonthepassenger’sside.The
secondary f use box is located next to
the battery.
To open each under-hood f use box,
pushthetabsasshown. If something electrical in your
vehicle stops working, the first thing
youshouldcheckforisablownfuse.
Determine f rom the chart on pages
, or the diagram on the
f use box lid or the f use label, which
f use or f uses control that component.
Check those f uses f irst, but check all
the f uses bef ore deciding that a
blown f use is not the cause. Replace
any blown fuses and check if the
device works.
Turn the ignition switch to the
LOCK (0) position. Make sure the
headlights and all other
accessories are of f .
Remove the cover f rom the f use
box.
1.
2. 678 682
Except the interior f use box on the
driver’s side
Fuses
Checking and Replacing Fuses
674
TAB
TAB
UNDER-HOOD (Primary)
UNDER-HOOD (Secondary)
10/07/17 11:04:22 31TK8600_679
2011 Odyssey

CONT INUED
Check each of the large f uses in
the under-hood f use box by
looking through the side window
at the wire inside. Removing these
f uses requires a Phillips-head
screwdriver.Also check the combined f use box
in the under-hood f use box.
Check the smaller f uses in the
under-hood f use boxes and all the
fuses in the interior fuse boxes by
pulling out each one with the f use
puller provided in the primary
under-hood f use box.
3.
4.
Fuses
Taking Care of the Unexpected
675
FUSEFUSE
BLOWN
FUSE PULLER
10/07/17 11:04:29 31TK8600_680
2011 Odyssey

If you cannot drive the vehicle
without f ixing the problem, and you
do not have a spare fuse, take a fuse
of the same rating or a lower rating
from one of the other circuits. Make
sureyoucandowithoutthatcircuit
temporarily (such as the accessory
power socket or radio).
If you replace the blown f use with a
spare f use that has a lower rating, it
might blow out again. This does not
indicate anything wrong. Replace the
f use with one of the correct rating as
soon as you can.
Look f or a blown wire inside the
fuse.If itisblown,replacethefuse
withoneof thesparefusesof the
same rating or lower.
5.
Fuses676
BLOWN
FUSE PULLER
Replacing a f use with one that has a
higher rating greatly increases the
chances of damaging the electrical
system. If you do not have a
replacement f use with the proper
rating f or the circuit, install one with
a lower rating.
10/07/17 11:04:35 31TK8600_681
2011 Odyssey

If the replacement fuse of the
same rating blows in a short time,
there is probably a serious
electrical problem with your
vehicle. Leave the blown fuse in
that circuit, and have your vehicle
checked by a qualif ied technician.Your vehicle has spare fuses on the
back of the primary under-hood f use
box cover.
6.
Fuses
Taking Care of the Unexpected
677
SPARE FUSES
10/07/17 11:04:39 31TK8600_682
2011 Odyssey

µ
µ
µ
µ
µ
µµ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
Î
Î
No. Amps. Circuits Protected No. Amps. Circuits Protected1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16 15 A
15 A
7.5 A
7.5 A
15 A
15 A
15 A
15 A
20 A
10 A ACG FR
Washer
VBSOL
ECU FR
FI Sub
DBW
FI Main
Ignition Coil
Radio
Back Up 17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
7.5 A
20 A
10 A
10 A
10 A
15 A
15 A
7.5 A
30 A
30 A
30 A MG Clutch
Front Fog Lights
Right Headlight High Beam
Small Lights
Left Headlight High Beam
Right Headlight Low Beam
Left Headlight Low Beam
IGPS Oil Level
Cooling Fan
Sub Fan
Wiper Main
: If equipped
Fuse Locations678PRIMARY UNDER-HOOD FUSE BOX
10/07/17 11:04:46 31TK8600_683
2011 Odyssey

µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
Î
Î
Amps.
No. Amps.
No.
CONT INUED
Circuits Protected
Circuits Protected
125 A
60 A
50 A
30 A
30 A
40 A
30 A
30 A
30 A
50 A
50 A
60 A
50 A
50 A
60 A
40 A
14
0A
40 A
7.5 A 20 A
15 A
7.5 A
38
4
5
6
7
8
9
10
11 Passenger’s Side Power
Slide Door Motor
Rear Window Defogger
Battery Management
System
Stop & Horn
Hazard
Interior Lights
Battery
Fan Main
Passenger’s Side Fuse Box 2
Rear Blower
FI Main
VSA Motor
Stop & Horn, Hazard
VSA FSR
Battery Management
System Main
Driver’s Side Fuse Box 2
IG1 Main
Rear Fuse Box 1
Passenger’s Side Fuse Box 1
Driver’s Side Fuse Box 1
Primary Under-hood Fuse
Box Main
Front Blower
: If equipped
21
22
23
24
25
26
27
28
31
32
33
34
35
36
37
Fuse Locations
Taking Care of the Unexpected
679
SECONDARY UNDER-HOOD FUSE BOX
10/07/17 11:04:53 31TK8600_684
2011 Odyssey
