2011 Citroen C4 RHD ECO mode

268
QUESTIONANSWERSOLUTION
Playback of my USB memory stick starts only
after a very long wait(around 2 to 3 minutes). Some fi les supplied with the memor
y stick may greatly slow down access
to reading the memory stick (multiplication by 10 of the catalogue time). Delete the
fi les supplied with the memory stick and limit the number of sub-folders in the fi lestructure on the memory stick.
When I connect my iPhone
as telephone and to the
USB port at the same time, I am unable to play themusic fi les. When the iPhone connects automaticall
y as a telephone, it is possible
that it connects streaming and telephone functions simultaneously. Thestreaming function takes the place of the USB function which is then not useable.Two possible solutions
(depending on the
iPhone):
- disconnect then reconnect the U
SB connection (the USB function then takes the
place of the streaming function),
-
go to the "Bluetooth functions"\"List of the paired peripherals" menu, disconnect the
iPhone then reconnect it in "Hands-free
mode" only.
FREQUENTLY ASKED QUESTIONS

282
04
1
2
1
2
3
4
5
AUDIO






STREAMING - PLAYING AUDIO FILES
VIA BLUETOOTH
Depending on the compatibility of the phone
Connect the telephone: see the "USING THE
TELEPHONE" section.
Streaming allows music fi les on a telephone to be heard via
the vehicle's speakers.
The telephone must support the appropriate bluetooth pro
fi les (Profi les A2DP/AV RCP).

Activate the streaming source by pressing SOURCE.Control of playback is via the audio system. Thecontextual information can be displayed on the screen.
In certain cases, pla
ying of the audio fi les must be initiated from
the telephone.
The audio quality depends on the quality o
f the transmission from
the telephone.

PLAY MODE


The play modes available are:


- Normal: the tracks are pla
yed in order, depending onthe classifi cation of the selected fi les.

- Random: the tracks in an album or
folder are played in arandom order.

- Random all: all o
f the tracks saved in the media ar played in random order.

- Repeat: the tracks pla
yed are only those from the currentalbum or folder.




Press OKfor access to the contextualmenu.

or
Pr
ess MENU.


Select "Multimedia" and confi rm.

Select "Media parameters
" and confi rm.

Select "Read mode
" and confi rm.

Select the desired play mode and confi rm OKto save the modifi cations.

289
1
2a2c
2b
05USING THE TELEPHONE
During a call, press OK
to displaythe contextual menu.

Han
g up

In the contextual menu:

-
select "Telephone mode" to
transfer the call to the telephone.

-
deselect " Telephone mode
" totransfer the call to the vehicle. In th
e contextual menu:
-
select " Micro OFF
" to switch offthe microphone.
-
deselect " Micro OFF" to switchthe microphone on.
In certain cases, the combined mode has to activated
from
the telephone.
If the contact has been cut off, when
you reconnect on returning to
the vehicle, the Bluetooth connection will be restored automatically (depending on the compatibility of the telephone).


MANAGING CALLS


A long press on SOURCE
or TEL
also ends the call.
In the contextual menu, select "Hang up"to end the call.
Secret - Mute

(so that the caller cannot hear)

Combined mode

(to leave the vehicle without ending the call)

295
08TRIP COMPUTER

Each press of the button, located at the end of the
wiper stalk, displays the different trip computer
information in succession, depending on the screen.


- th
e "vehicle
" tab with:
●
the ran
ge, the current fuel consumption and
the distance remaining to the destination or the Stop & Start time counter,

- the "1" tab
(trip 1) with:
●
t
he average speed, the average consumptionand the distance travelled calculated over
trip " 1 ",

- the "2" tab
(trip 2) with the same information for a second trip.

Z
ero reset
When the required trip is displa
yed, press the control
for more than two seconds.
Range:displays the distance which can travelled with the remaining fuel
detected in the tank, based on the average fuel consumption over the last few miles (kilometres).
This displa
yed value may vary signifi cantly following a change in the
vehicle speed or the relief of the route.
When the ran
ge falls below 20 miles (30 km), dashes are displayed.After fi lling with at least 5 litres of fuel, the range is recalculated and is
displayed when it exceeds 60 miles (100 km).
If, whilst driving, dashes are displayed continuously in place of the digits, contact a CITROËN dealer. ,g,

A FEW DEFINITIONS
Current fuel consumption:only calculated and displayed above 20 mph (30 km/h).
Average fuel consumption:
this is the average fuel consumption since
the last trip computer zero reset.
Distance travelled:calculated since the last trip computer zero reset.
Distance remaining to the destination: calculated with reference to
the fi nal destination, entered by the user. If guidance is activated, the navigation system calculates it as a current value.
Avera
ge speed: this is the average speed calculated since the last tripcomputer zero reset (ignition on).
Sto
p & Start time counter
(minutes/seconds or hours/minutes)
I
f your vehicle is fi tted with Stop & Start, a time counter calculates
the time spent in STOP mode during a journey.
It resets to zero ever
y time the ignition is switched on with the key.

300
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWERSOLUTION
The quality of reception of the radio stationlistened to graduallydeteriorates or the storedstations do not function (no sound, 87.5 MHz is
displayed...).The vehicle is too
far from the transmitter used by the station listened to
or there is no transmitter in the geographical area through whichthe vehicle is travelling. Activate the RD
S function to enable the system
to check whether there is a more powerful
transmitter in the geographical area.
The environment
(hills, buildings, tunnels, basement car parks...) block
reception, including in RDS mode. This phenomenon is normal and does not indicatea failure of the audio equipment.
The aerial is absent or has been dama
ged (for example when goingthrough a car wash or into an underground car park). Have the aerial checked by a CITROËN dealer.
Sound cut-outs of 1 to2 seconds in radio mode. During this brief sound cut-out, the RDS searches for any frequency
permitting better reception of the station. Deactivate the RDS function if the phenomenon is
too frequent and always on the same route.
Th
e traffi c announcement (TA) is displayed. I do not receive any traffi cinformation.Th
e radio station does not broadcast traffi c information. Tune to a radio station which broadcasts traffi c
information.
The stored stations arenot found (no sound,87.5 MHz is displayed...). An incorrect waveband is selected.Press the BAND AST button to return to the
waveband (AM, FM1, FM2, DAB * ) on whichthe stations are stored.
* Digital Audio Broadcasting.

302
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWERSOLUTION
A telephone connects
automatically,
disconnecting another
telephone. A
utomatic connection overrides manual connection. Modify the telephone settings to remove automatic connection.

An IPod is not recognised
when connecting to theUSB port.The IPod is of a generation that is not compatible with the USB. Connect the IPod to the AUX Jack socket using a
suitable cable (not supplied).
Th
e hard disk or deviceis not recognised when connecting to the USB port. Some hard disks and devices need a power suppl
y greater than is
provided by the audio system.
Connect the device to the 230 V socket, the 12 V
socket or an external power supply.
Caution
: ensure that the device does not transmit a voltage greater than 5 V (risk of destruction of
the system).
When streaming, the
sound cuts momentarily. Some telephones prioritise connection of the "hands-free" profi le. Delete the "hands-free" connection profi le toimprove streaming.
In "Random all" pla
y, not all of the tracks areplayed.
In "Random all" play, the system can only take into account up to999 tracks.
With the en
gine off, the
audio system switchesoff after a few minutes of use.When the en
gine is switched off, the audio system operating timedepends on the battery charge.
The switch-o
ff is normal: the audio system switches to economy modeand switches off to prevent discharging the vehicle's battery.
Start the vehicle's engine to increase the batterycharge.
The message "the audio
system is overheated"appears on the display.In order to protect the installation i
f the surrounding temperature is too high, the audio system switches to an automatic thermal protection mode
leading to a reduction of the volume or stopping of the playing of the CD.Switch the audio s
ystem off for a few minutes toallow the system to cool.

306
VISUAL SEARCH
TECHNICAL DATA - MAINTENANCE


Running out of Diesel fuel ............. 171

Checking levels ...................... 174-175


- oil

- brake fl uid

- coolant

- power steering fl uid

- screenwash/headlamp wash fl uid

- additive (Diesel with particle
emissions fi lter)


Changing bulbs....................... 187-192


- front

- rear

Petrol engines......................... 207-210
Diesel engines .........................211-212
Dimensions .................................... 213
Identifi cation markings ................... 214

Bonnet ........................................... 170
Petrol underbonnet ........................ 172
Diesel underbonnet ....................... 173
Checking components ............ 176-177


- battery

- air fi lter/passenger compartment
fi lter

- oil fi lter

- particle emissions fi lter (Diesel)

- brake pads/discs


Battery .................................... 197-199
Energy economy mode.................. 199

Engine compartment fuses .... 193, 196

308
ALPHABETICAL INDEX
E EBA (Emergency braking
assistance) ...............................128
Economy mode ..........................199
Electric parking brake .........138-141
Electric seats ................................71
Electric window controls ...............89
Electronic brake force distribution
(EBFD) .....................................128
Electronic engine
immobiliser ...........................80, 82
Electronic gearbox
system ......................147, 154, 177
Emergency boot release ..............88
Emergency braking system ........128
Emergency call ...................130, 216
Emergency warning lamps .........126
eMyWay .....................................217
Energy economy mode ..............199
Engine compartment ..........172, 173
Engine compartment
fusebox .....................................195
Engine oil level
indicator ........................43, 46, 174
Engines .............................. 207, 211
Environment .....63, 69, 82, 152, 175
ESP/ASR ....................................129
F Filling with fuel ........................92, 93
Fittings, boot ............................... 115
Fitting speakers ..........................204
Flashing
indicators ............97, 126, 188, 190
Front airbags ......................134, 137
Front armrest .......................111, 112
Front foglamps .....95, 100, 187, 190
Front head restraints ....................72
Front parking sensors ................168F Front seats ..............................70-73
Front wash-wipe .........................102
Fuel ..............................................93
Fuel fi ller fl ap ..........................92, 93
Fuel gauge ...................................92
Fuel tank ................................92, 93
Fuses .........................................193
G G.P.S. ..................................223-235
Gear effi ciency indicator .............146
Gear lever, automatic gearbox ...150
Gear lever, electronic gearbox
system ......................................147
Gear lever, manual gearbox .......145
Glove box ...................................108
Grab handles ..............................107
Guidance .............................223-235
H Halogen headlamps ...................187
Hands-free telephone .........240, 283
Hazard warning lamps ...............126
Headlamp adjustment ..................98
Headlamps, directional .........99, 187
Headlamp wash .........................102
Heated seats ................................72
Heating ...................................64, 66
Height and reach adjustment,
steering wheel ............................77
Hill start assist ............................153
Hooks ......................................... 116
I Indicator/warning lamps ..........32-42
Indicators, direction ....126, 188, 191
Infl ating accessories
(using the kit) ............................182
Inputs for
audio system ............108, 257, 281
Installing speakers .....................204I Instrument panel lighting ..............48
Instrument
panels ................. 27-30, 46, 49, 56
Instrument panel
screen .......................... 27-30, 146
Intelligent Traction Control .........129
Interior fi ttings .....................107, 108
Interior mood lighting ..................105
ISOFIX child seats ..............122-124
ISOFIX mountings ......................122
J Jack ............................................183
K Keeping children
safe ..... 90, 118-125, 133, 135, 139
Key in ignition warning .................80
Key with remote control ...........78-82
L Labels, identifi cation ...................214
Lamps, warning and
indicator ..........................32, 39, 42
Lateral airbags ...................136, 137
Level, brake fl uid ........................174
Level, power steering fl uid .........174
Levels and checks ...............172-177
Lighting, guide-me home ........96, 97
Lighting, interior ..................104, 105
Lighting bulbs
(replacement) ....................187-192
Lighting dimmer .................27-30, 48
Lighting stalk ..........................94, 97
Load reduction mode .................199
Locating your vehicle ...................80
Locking from the inside ................83
Locking the boot ...........................88
Long objects, transporting .......... 114
Luggage retaining strap ............. 115
