2011 Citroen C4 RHD ECO mode

221
03

For a detailed global view of the menus available, refer to the"Screen menu map" section.


For cleaning the screen, the use of a soft, non-abrasive cloth (spectacles cloth) is recommended, with no additional product. "RADIO
/MEDIA"
"
TELEPHONE"
(If conversation in progress)
SETUP
: PARAMETERS
date and time, display parameters, sound.
Changing the audio source:
RADIO:RADIObroadcasts.
MUSIC :playing MEDIA.
Press the MODE
button several times in succession for access to the following displays:

GENERAL OPERATION
"FULL SCREEN MAP"
"MAP IN WINDOW"

241
7
8
06
Enter the same code on the telephone then accept
the connection.
The "
Hands-free mode
" should be used in preference if
"Streaming" is not desired.
Then accept automatic connection on the telephone to allow the
telephone to reconnect automatically every time the vehicle is started.


USING THE TELEPHONE


The ability of the system to connect in only one mode depends on
the telephone. The two modes may both connect by default.
The services available depend on the network, the
SIM card and the compatibility of the Bluetooth telephone used. Check the telephone manual and with your network provider for details of the services available to you.
Select a code for the connection thenconfi rm "OK
".
On return to the vehicle,the last telephone connected
automatically reconnects, within around 30 seconds after switching on the ignition (Bluetooth activated and visible).
To modi
fy the automatic connection mode, remove the pairingand pair the telephone again with the desired mode.

07
1a
1b
1c
1
2
By alphabetical list
Pr
ess RADIOor LIST , select the station
of your choice and confi rm.
B
y automatic frequency search
Press or for the automatic searchfor a lower or higher radio frequency.
Or turn the thumb wheel on the steering
mounted control.
B
y manual frequency search
Pr
ess or to adjust the radiofrequency step by step.Pr
ess the button on the numericalkeypad to recall a preset station.
Or press then turn the thumb wheel at
the steering mounted controls.






SELECTING A STATION


The external environment (hill, building, tunnel, underground car park...) may interfere with the reception, including in RDS station tracking mode.
This phenomenon is a normal result of the way in which radio waves are transmitted and does not in any way indicate a fault with the audio system.

PRESETTING A STATION


Press one of the buttons on thenumerical keypad for 2 seconds topreset the current station.
An audible si
gnal confi rms that thestation has been preset. The qualit
y of reception is represented by this symbol.

08

CD, MP3 CD, USB PLAYER


The audio equipment will only play audio fi les with ".m4a, .m4b, .aac,.fl ac, .ogg and .mp3" fi le extensions and with a bit rate of between32 Kbps and 320 Kbps.
It also supports the VBR
(Variable Bit Rate) mode.
No other t
ype of fi le (.wma, .mp4, .m3u...) can be played.
The samplin
g rates supported are 11, 22, 44 and 48 KHz.

It is advisable to restrict
fi le names to 20 characters, without using of special characters (e.g.: " " ? ; ˘) to avoid any playing and
displaying problems.

In order to be able to pla
y a recorded CDR or CDRW, when recording
it is preferable to select the ISO 9660 level 1, 2 or Joliet standard.
If the disc is recorded in another format it ma
y not be played correctly.

It is recommended that the same recording standard is always used for an individual disc, with as low a speed as possible (4x maximum)for optimum sound quality.
In the particular case o
f a multi-session CD, the Joliet standard isrecommended.
INFORMATION AND ADVICE
The s
ystem supports USB mass storage or IPod
devices via the USB port (suitable cable not supplied).

Control of the peripheral device is with the audiosystem controls.

Other peripherals, not recognised on connection, must
be connected to the auxiliary socket using a Jack cable (not supplied).
In order to be read, a USB memor
y stick must be formatted FAT 16 or 32.

256
1
2
1
2
08






AUDIO STREAMING
Streaming allows audio fi les on your telephone to be played via the
vehicle's speakers.
Connect the telephone: see "USING THE TELEPHONE".
Select " Audio" or " All" profi le.
If pla
y does not start automatically, it may be necessary to start the audio playback from the telephone.
Control is from the peripheral device only.
Once connected in streaming mode, the telephone is considered
to be a media source.
It is recommended that
you activate " Repeat" on the Bluetooth
peripheral.

MUSIC MEDIA PLAYERS


IPOD/IPHONE
Connect the IPod or IPhone to the USB port using a suitable cable (not supplied).
Play starts automatically.
Control is via the audio system.
The classifi cations available are those of the portable device
connected (artists/albums/genres/playlists/audiobooks/podcasts).
The de
fault classifi cation used is by artist. To modify the classifi cationused, return to the fi rst level of the menu then select the desired classifi cation (playlists for example) and confi rm to go down through
the menu to the desired track.

264
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWERSOLUTION
Certain traffi c jams alongthe route are not indicatedin real time. On startin
g, it is several minutes before the system begins to receive
the traffi c information.Wait until the traffi c information is bein
g received correctly (display of the traffi c information icons
on the map).
Th
e fi lters are too restrictive. Modify the "Geographic fi lter" settings.
In certain countries, onl
y major routes (motorways...) are listed for
the traffi c information.This phenomenon is normal. The system is
dependent on the traffi c information available.
Th
e altitude is not
displayed.
On starting, the initialisation of the GPS may take up to 3 minutes to
receive more than 4 satellites correctly.Wait until the s
ystem has started up completely.
Check that there is a GPS coverage of at least
4 satellites (long press on the SETUP button,
then select "GPS coverage").
Dependin
g on the geographical environment (tunnel...) or the weather,
the conditions of reception of the GPS signal may vary. This phenomenon is normal. The s
ystem
is dependent on the GPS signal receptionconditions.
I cannot connect my Bluetooth telephone. The telephone's Bluetooth function ma
y be switched off or the telephone
may not be visible. - Check that
your telephone's Bluetooth
function is switched on.
-
Check in the telephone settings that it is "visible to all".
The Bluetooth telephone is not compatible with the s
ystem. A list of compatible Bluetooth mobile telephones
is available from the dealer network.
Th
e volume of the
telephone connected in Bluetooth mode isinaudible. The volume depends both on the s
ystem and on the telephone. Increase the volume of the audio system, to
maximum if required, and increase the volume of
the telephone if necessary.
The ambient noise level has an infl uence on the qualit
y of telephonecommunication.Reduce the ambient noise level
(close the
windows, reduce the booster fan speed, slow
down, ...).

265
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWERSOLUTION
Some contacts are
duplicated in the list. The options for synchronizing contacts are synchronizing the contactson the SIM card, the contacts on the telephone, or both. When both synchronizations are selected, some contacts may be duplicated.
Select "Display SIM card contacts" or "Display
telephone contacts".
Contacts are not shown in
alphabetical order. Some telephones offer display options. Depending on the settingschosen, contacts can be transferred in a specifi c order.Modify the display setting in the telephone
directory.
The s
ystem does not receiveSMS text messages. The Bluetooth mode does not permit sending SMS text messages to the system.
The
CD is ejected
automatically or is notplayed by the player. The CD is inserted upside down, is unpla
yable, does not contain any
audio data or contains an audio format which the player cannot play.
Le CD has been recorded in a format that is not compatible with
t
he player.
The
CD is protected by an anti-pirating protection system which is not
recognised by the audio system.- Check that the CD is inserted in the pla
yer
the right way up.
-
Check the condition of the CD: the CD cannot be played if it is too damaged.
-
Check the content in the case of a recordedCD: consult the advice in the "Audio" section.
- The audio s
ystem's CD player does not play
DVDs.
- Some recorded CDs will not be pla
yed by
the audio system because they are not of
the correct quality.
There is a long waiting periodfollowing the insertion of a CD or connection of a USBmemory stick. When a new medium is inserted, the s
ystem reads a certain amount of
data (directory, title, artist, etc.). This may take from a few seconds to a
few minutes.This phenomenon is normal.
The CD pla
yer sound ispoor. The
CD used is scratched or of poor quality.Insert good quality CDs and store them in suitable conditions.
The audio equipment settin
gs (bass, treble, ambiences) are unsuitable.Set the treble or bass level to 0, without
selecting an ambience.

267
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWERSOLUTION
In changing the setting of treble and bass the equalizer setting is deselected.
The selection of an equalizer setting imposes the balance settings.
Modif
ying one without the other is not possible. Modify the balance or equalizer settings toobtain the desired musical ambience.
In changing the equalizer
setting, treble and bass return to zero.
When chan
ging the balance
settings, the distribution
setting is deselected.
The selection of a distribution setting imposes the balance settings.
Modi
fying one without the other is not possible. Modify the balance or distribution settings to obtain the desired musical ambience. When changing an
distribution setting,
the balance settin
g isdeselected.
Th
ere is a difference in
sound quality between the different audio sources (radio, CD...). For optimum sound qualit
y, the audio settings for Volume, Bass, Treble, Equalizer and Loudness can be adapted to the different sound sources,
which may result in audible differences when changing source (radio, CD...).
Check that the audio settings for (Volume, Bass,
Treble, Equalizer, Loudness) are adapted to
the sources listened to. It is advisable to set the
AUDIO functions (Bass, Treble, Fr-Re balance, Le-Ri balance) to the middle position, select the"None", musical ambience and set the loudnesscorrection to the "Active" position in CD mode or
to the "Inactive" position in radio mode.
With the en
gine off, the
system switches off after a few minutes of use. When the en
gine is switched off, the system's operating time depends on
the battery charge.
The switch-off is normal: the s
ystem switches to economy mode andswitches off to prevent discharging of the vehicle's battery. Start the vehicle's en
gine to increase the battery charge.
