2011 AUDI S8 display

Night vision assistant
Description
Applies to vehicles: with night vision assistant
Fig. 110 Display: nightv ision assistant
"Night v ision assistant with pedestrian detec­
tion" uses an infrared camera to mon itor the
area in front of your vehicle at night . Within
the limits of the system, it can display objects
up to about 1000 feet (300 mete rs) away. The
heat image of a pedestrian detected by the
camera is shown in the instrument cluster dis­
p lay
¢ fig. 110. Warm areas appear lighter
and cold areas appear darker.
Pedestrian detection
Applies to vehicles: with night vision assistant
Fig. 111 Display: yellow pedestrian marking
Fig. 112 Display: symbol when infra red image is not
visib le
Night vision assistant 109
Night vision assistant can detect pedestrians
that are between about 50 and 300 feet (15
and 90 meters) in front of the vehicle, under ideal conditions . If a pedestrian is detected
when it is dark outside and the vehicle head­
lights are switched on, the pedestrian is high ­
lighted in yellow
~ fig. 111, ¢page 110,
General information .
If another display such
as navigat ion replaces the image from the
night vis ion assistant, the symbo l
~11 appears
in a tab
¢fig. 112.
(D Tips
-If the night vision assistant image does
not appear when the system is switched
on, you can access it with the buttons on
the multifunction steering whee l
~page 24.
Pedestrian warning
Applies to vehicles: with night vision assistant
Fig . 113 D isp lay: pedestr ian wa rning
Fig. 114 Disp lay: pedestrian wa rnin g with anot her dis ­
play
If a pedestrian is detected in an area in front
of the vehicle that the system considers criti­
cal, the pedestrian is highlighted in red
¢fig . 113 and a warning tone sounds. This
area is based on the vehicle speed and

110 Night vis ion assis tant
steering angle. The pedestrian warning
prompts you to pay even closer attention to
the area in front of the vehicle and to watch
out for pedestrians.
I f another display such as the tr ip computer
replaces the image from the night vision as­
sistant, the indicator light turns red when
there is a pedestrian warning
I c:> fig. 114.
@ Tips
The pedestrian marking and warning tone
can be adjusted in the MMI
r::!)poge 111.
General information
Applies to vehicles: with night vision assistant
Fig. 115 Front of the vehi cle: night vision assistant
camera
The following s ituations may affect the func­
tion of the night vision assistant system:
- poor vis ibility such as snow, ra in , fog or
heavy road spray
- dirty lens on the night vision ass istant cam -
era
Make sure the night vis ion assistant camera
r::!) fig. 115 is not cove red by stickers, deposits
or any other obstruc tions because tha t can
p revent the camera from working p roperly.
F or information on cleaning the lens, refer to
r::!) page 208.
Pedestrian detect ion depends o n the differ­
ence in temperat ure between the person and
the background. Pedestrians may not be de­
tected if the temperature difference is too
small. The pedestrian highlighting feature is
deactivated at temperatures above 77 °F (25
0
() and when it is light outside.
A WARNING
--
Night vision assistant has limits and can­
not always detect pedestrians . Always pay
close attention to traffic and the area
around your vehicle even when night vision
assis tant is sw itched on.
- Night vision assistant can only warn
about people located within the visual
range of the infrared camera. The visual
ra nge corresponds to the image in the in­
strument cluster display .
- Night vision assistant may not detect
peop le and highlight them if
- they are not in an upright posit ion, for
example if they are sitting, crouching
o r lying down and/or
- if the outline in the disp lay is incom­
plete or interrupted, for example be­
cause the perso n is part ial ly hidden by
a parked vehicle.
@ Tips
- Pedestrian detection and the pedestrian
warm ing are limited to objects that are
detected as pedest rians . The system
does not detect an imals. Even though
the shape and warmth radiate d by each
objec t detected is eval uated, the system
does have limitat ions and it can g ive in­
correct warnings .
- For technical reasons, the image pauses
in split second intervals.
Switching on and off
Applies to vehicles : with night vision assistant
Fig. 116 Area around the light switch: night vis ion as-
s istant button ..,_

.. Swi tch the ign ition on and turn the lig ht
switch to the
AUTO pos ition or io .
.. To switch night vision assistant on , press the
~ ,, button
~ fig . 116. The image from the
night vision camera appears in the instru­
me nt cluster d isp lay.
.. Press t he button ~,, aga in to swi tc h ni ght vi­
s ion assistant off .
Settings in the MMI
Applies to vehicles: with night vision assistant
F ig. 117 D isp lay: examp le of pedestr ia n detectio n and
warni ng tone switched off
.. Se lect: ICARI f unct ion but ton> Car sy stems
co ntrol b utton > Dr iver assist > Night vision
a ssist.
Highlight pedestrians -
You can switch pedes­
tr ian detection
on and off . If yo u sw itch pe­
destrian detect ion off, the pedestrian war ning
t one also switches off . The symbols
II and !:a
a p pe ar in the upper righ t area of the ins tru­
men t cluster display~
fig. 117.
Warning tone -You can switch the to ne fo r
the pedestrian warning
on a nd off . Whe n the
warn ing tone is swi tc h ed off, a ye llow sym bol
fo r the de activa ted w arning tone with a line
through it appears in the upper right of the in­
strument cluster display ~
fig. 117 .
Contrast -When the nigh t vis ion assis tan t is
switche d on and the ima ge is visible in t he in ­
strument cluster disp lay, yo u can adjust the
contrast in the image from
Min to Max.
Driver messages
Applies to vehicles: with night visio n assistant
Night vision assistant : system malfunction! Night
vision assistant 111
The system cannot work properly and is
switched off. See your authorized Audi dealer
for assistance .
Night vision assistant: not available
The system cannot detect p roperly under cur­
r ent cond itions and is switc hed off tempora ri­
ly.
Night vision assistant: only available in dark­
nes s and with lights switched on
N ight vision assistant only works when it is
dark outside a nd the head lights are on .
Night vision assistant: pedestrian detection
not available
The system has deactivated the pedestrian de­
tection function .

112 Automatic Transmission
Automatic
Transmission
tiptronic (8-speed
transmission)
Introduction
Your vehicle is equipped with an electronically controlled 8-speed automatic transmission .
Upshifting and downshifting take place auto­
matically .
The driver also has the option to shift the
gears manuafly c;,page 115 .
Dynamic Shift Program (DSP)
When a moderate driving style is used , the
transmission selects the most economical
driving mode. The transmission upshifts at a
lower RPM and downshifts at a higher RPM to
improve fuel effic ie ncy .
The transmission switches to a sporty mode
after a kick-down or when the driver uses a
sporty driving style characterized by quick ac­
celerator pedal movements, heavy accelera­
tion, frequent changes in speed and traveling
at the maximum speed .
Selecting the best driving mode is a continu­
ous process . However, the transmission will
also jump to a sporty driving mode if you
press the accelerator pedal quickly. When you
do this, the transmission shifts down into a
lower gear, which makes it possible to acceler­
ate quickly (for example, when passing anoth­
er vehicle) without having to press the pedal
down into the kick-down area . Once the trans ­
mission has shifted up again, it returns to the
original driving mode as long as it matches
the current driving style.
When driving in hills and mountains , the gear
selection adapts to the grade. This prevents
constant upshifting and downshifting when
driving uphill.
Indicator in the display
Fig. 118 Display : selecto r leve r position
@ -The current selector lever position is dis ­
played continuously . The gear is also dis­
played in manual mode
M.
@ -This indicato r appears temporarily if you
ch ange the selector lever position or if you
press the button on the selec tor lever
¢ page 112, fig . 119 . The current selector
lever pos ition is shown with a wh ite back­
ground .
Selecting a selector lever position
Fig. 119 Selector lever
----R----
- -- N- -- -1
- D/S--
Fig. 120 Pressing the button o n the selector leve r
The current selector lever position is displayed
on the selector lever <=;>fig. 119. ..,_

the selector lever to the P position. This p re­
vents too much stress from being placed on
the locking mechanism .
.&_ WARNING
Read and follow all WARNINGS c> .&. in Se­
lecting a selector lever position on
page
114 .
-Do not press the accelerator pedal when
changing the selector lever pos ition
wh ile the vehicle is stat ionary and the
engine is running . This could result in a
crash .
- Never engage
R or P while dr iving . It
cou ld cause a crash .
- Power is still transmitted to the wheels when the eng ine is running at idle. To
prevent the vehicle from "creep ing", you
must keep your foo t on the b rake in all
selector lever positions ex cept
P and N
when the engine is running . Do not inad­
vertent ly press the accelerator pedal
when the vehicle is stationary. Otherwise
the vehicle will start to move immediate ­
ly, even if the parking brake is set. This
cou ld result in a crash .
Kick-down
Kick-down enables maximum acceleration.
When you press the accelerator pedal down
beyond the resistance point, the automatic
transmission downshifts into a lower gear, d e­
pending on vehicle speed and engine RPM. It
shift s up into the next higher gear once the
maximum specified engine RPM is reached .
.&_ WARNING
Please note that the wheels could spin on
slick or slippery roads when kick-down is
act ive .
Autom atic Tra nsmi ssi on 115
Shifting manually
T he shift paddles allow the driver to shift the
gears manually .
Fig . 1 21 Steer ing w hee l: s hifting man ually
... To shift to a higher or lowe r gear temporari­
ly , tap the
0 or O shift padd le c> fig. 121 .
... To switch manua l mode on, press the~
button .
M and the gear that is current ly en­
gaged @appears in the instrument cluste r
display
c> page 112, fig. 118.
... To shift up one gear, tap the righ t shift pad­
dle
0 c> fig . 121 .
... To sh ift down one gear, tap the left shift
paddle Q .
... To swi tch manua l mode off, press the~
button aga in , or
... Move the selector lever back and release it .
When you accelerate o r reduce the speed, the
transmission automa tical ly shifts into the cor ­
rect gear sho rtly before reaching the RPM lim­
it. If you select a lower gear than the one c ur­
rently shown in the display, the automatic
transmiss ion will on ly shift down once there is
no danger of exceeding the maximum RPM .
T he engine braking effect increases when yo u
downshift when going downhill.
Transmission malfunction
[G) Transmiss ion : please press the brake ped ­
a l and select the po sit ion again
Press the brake pedal and select the desired
selector lever position again. You can then
continue driving.
[G] Tran smi ssion h ot: plea se m odify driving
~le
~

Rea r vi ew camer a coverag e area
The MM I display shows the area covered by
the rear view camera ¢
fig. 126 (D. Objects
that are not in the area covered @are not
shown on the MMI display.
We recommend that yo u practice parking with
the rear view camera in a traffic -free location
or parking lot to become familiar with the sys ­
tem, the orientation lines, and their function.
When do ing th is, there should be good light
and weather conditions.
I n the MMI disp lay, objects or vehicles appear
closer or further away if:
- you are driving in reverse gear from a level
surface onto an incline, or a downward
s lope,
- yo u are driving in reverse gear toward pro ­
truding objects,
- the vehicle is carrying too much load in the
rear .
The accuracy of the or ientat ion lines and blue
surfaces d imin ishes if:
- the adapt ive air suspension/sport* is faulty,
the vehicle is lifted or dynamic mode is se­
lected
¢page 106,
- the rear view camera does not prov ide a reli­
able image, for examp le, in poor visibility
condit ions or if the lens is dirty,
- the image on the screen is not visible due to
sun g lare and reflect ion.
Car ing for the rear view came ra len s
The rear view camera is located above the rear
license plate bracket . For the parking system
to operate, the lens¢
fig. 12 7 must be kept
clean:
- Dampen the lens with a household alcoho l­
based glass cleaner, and then wipe the lens
clean with a dry cloth ¢CI).
- Remove snow with a hand brush and ice
preferably with a de-icing spray ¢(D.
A WARNING
-Senso rs have blind spots in which objects
cannot be detected . Pay special attention
Ad vanced P arking S ystem 119
to small children and animals because
the sensors cannot always detect them.
- The parking system cannot replace the
driver's attention. The driver alone is re­
sponsible for parking and similar driving maneuvers.
-Always keep your eyes on the vehicle's
surroundings, us ing the rear v iew mirror
as well.
- Do not allow yourself to be distracted
from traffic by the rear view camera p ic­
tures .
- If the position and the installation angle
of the camera has changed, for example,
after a rear end collision, do not continue
to use the system for safety reasons.
Have it checked by a qualified dea le rship.
(D Note
- Low obstacles a lready s ignaled by a
warning can disappear from the system's
detect ion range as they are approached
and w ill not continue to be s ignaled. Ob­
jects such as ba rr ie r chains, trai le r d raw
bars, thin painted vert ica l poles or fen­
ces may not be detected by the system,
posing r isk of damage .
- Never use warm or hot wate r to remove
snow or ice from the rear view camera
lens - this could cause the lens to crack!
- When cleaning the lens, never use prod ­
ucts that are ab rasive.

120 Advanced Parking System
Switching on and off
Applies to vehicles: with park ing system advanced
The rear view camera switches on automati­
cally together with the acoustic and visual
park assist when you put the vehicle in re­
verse.
Fig. 128 Ce nter console: Park ing system swi tc h
Fig. 129 MMI disp lay: v isual distance d isplay
Switching on
,. Switch the MMI on
,. Act ivate
comfort or auto mode in Audi dr ive
select
¢page 106.
,. Shift into reverse or
,. Press the switch
P,qi in the center console
¢
fig. 128 . A short confirmation tone
sounds and the ind icator light in the sw itch
lights up.
Switching between the rear view camera
and visual display
,. Press the Graphic control button
¢
page 121, fig . 130 ® to see the visual
display .
,. Press the
Rearview control button to see the
rear view ca mer a image
¢ fig . 129 .
Switching off
,. Drive faster than 6 mph (10 km/h), or ,.
press the switch
P,#A or
,. switch off the ignition.
Segments in the visual display
The red segments in front of and behind the
vehicle ¢
fig. 129 help yo u to determine the
distance between you and an obstacle. As
your vehicle comes closer to the obstacle, the segments move closer to the vehicle . The col ­
li sion area has been reached when the next to
last segment is displayed . Do not continue
driv ing farther ¢
A in General Information
on page
119!
A WARNING
- The MMI display cannot show, or cannot
adequately show, ce rtain objects (such as
small posts or grating), recesses in the
g round and protruding parts on another
car .
- Only use the rear view camera to assist
you if it shows a good, clear pict ure. For
examp le, the image may be affected by
the sun shining into the lens, dirt on the
lens or if there is a defect.
- Use the rear view camera on ly with the
rea r lid comp lete ly closed . Make su re any
objects you may have mounted on the
rear lid do not block the rear view cam­
era.
(D Tips
- The sensors must be kept clean and free
of snow and ice for the park assist to op­
erate.
- If your vehicle is near an obstacle, an ad­
ditional visual indicator appears in the
rearview camera image. This superim­
posed image is there to help you to de­
termined which area of the vehicle is af­
fected .
- You can change the volume and pitch of
the signals as well as the display
¢page 122.
-What appears in the display is time-de­
layed .

Reverse Parking
Applies to vehicles: with parking system advanced
Parking mode 1 can be used when parking in
a garage or into a parking space.
Fig. 130 MMI display: a im ing at a park ing spot
Fig. 131 MMI display : al ign ing the veh icle
... Turn the steer ing wheel until the orange ori­
entat ion lines
(D appear in the park ing spot
Q fig . 130. Use the markings @to help you
est imate the distance from an obstacle.
E ach marking rep resents 3
ft (1 meter). The
blue area represents an ex tension of the ve­
hicle 's outline by approx imately 16
ft (5 me­
ters) to the rear .
... While driving in reverse gear, adjust the
steering wheel angle to fit the parking space
with the aid of the orange orientation lines
c>(D. @ marks the rear bumper. Stop the
vehicle when the red orientation line © bor­
ders an object
c::> _& !
..&, WARNING
- The rear view came ra does not show the
entire area beh ind the veh icle
c::>page 118, fig. 126 . Watch out espe­
cially for small children and animals . The
Ad vanced Parking S yste m 12 1
rear view camera cannot always detect
them, posing risk of an accident!
- Please note that objects not touching the
ground can appear to be further away
than they really are (for example, the
bumper of a parked vehicle, a trailer
hitch, or the rea r ofa truck). In this case,
you shou ld not use the help lines to help
with parking, wh ich pose s danger of an
accident!
(D Note
In the MMI d isplay, the direction of travel
of the vehicle rear is represented depend­ ing on the steering wheel angle. The vehi­
cle front swings out more than the vehicle
r ear. Maintai n plenty of d istance so that
your outside mirror or a corner o f your ve ­
hicle does not co llide with any obstacles.
This can damage to your vehicle .
Parallel Parking
Applies to vehicles: with parking system advanced
Use parking mode 2 to help you parallel park
along the side of a street .
F ig . 1 32 MMI display: blue surface in the park ing spot
F ig . 1 33 MMI disp lay: Blue curve on the curb
