A D V A N C E D T E C H N O L O G Y G U I D E
The Advanced Technology Guide is designed to help you get
acquainted with your new Acura and provide basic instructions
on some of the technology items.
This guide is not intended as a substitute for the Owner’s Manual.
For complete information on vehicle controls and operation\b
please refer to the respective sections in the Owner’s Manual.
As with the Owner’s Manual\b this guide covers all trim levels of the
Acura TSX Sport Wagon. Therefore\b you may find descriptions of
equipment and features that are not on your particular vehicle.
AcuraLink Real-Time WeatherTM...................................................\1...............23
AcuraLink
®Messages ....................................\1...........................................\1..... 24
Bluetooth
®HandsFreeLink®....................................\1....................................... 25
Bluetooth
®Audio ....................................\1................................................\1....... 3\f
iPod
®or USB Flash Memory....................................\1....................................... 31
Note Function (Tech) ....................................\1...........................................\1..... 31
Hard Disc Drive (HDD) Audio (Tech) ....................................\1....................... 32
Song By Voice
TM(SBV) (Tech) ....................................\1.................................. 33
My Acura....................................\1...........................................\1......................... 35
Safety Reminder ....................................\1...........................................\1............. 36
Fuel Requirement ....................................\1...........................................\1........... 36
Technology Package shown
Instrument Panel Indicators....................................\1....................................\1.... 2
Multi-Information Display (MID) ....................................\1................................. 4
Keyless Memory Settings....................................\1....................................\1......... 8
HomeLink
®....................................\1......................................................\1............ 1\f
Reverse Tilt Door Mirror....................................\1....................................\1.......... 11
Rearview Camera ...............................................\1....................................\1......11
Power Tailgate (Tech)....................................\1....................................\1........... 12
Fuel Fill Door ...............................................\1....................................\1................13
Voice Recognition ...............................................\1....................................\1..... 14
Navigation (Tech) ...............................................\1....................................\1......2\f
AcuraLink Real-Time Traffic
TM...................................................\1.................... 22
V O I C E
R E C O G N I T I O N
p.14
B L \b E T O O T H®
H A N D S F R E E L I N K ®
p. 25A U D I Op.3\f
N A V I G A T I O Np.2\f
M U L T I I N F O R M A T I O N
D I S P L A Y
p.4
11 TSX 5D ATG\fATG_NEW STYLE 9/9/2010 2\f51 PM Page 2

I N S T R U M E N T P A N E L I N D I C A T O R S
O n \b O f f I n d i c a t o r sM a l f u n c t i o n I n d i c a t o r s
If an indicator remains on\b there may be a problem; see your dealer
Charging system
Low brake fluid\b Brake system
Low oil pressure
VSA(Vehicle Stability Assist)
Malfunction indicator lamp(check engine light)
TPMS (blinks)(Tire Pressure Monitoring System)
EPS(Electric Power Steering)SRS(Supplemental Restraint System)
ABS(Anti-lock Brake System)
PASSENGERAIRBAG
OFFPASSENGER AIRBAG OFF
(above audio panel)
SIDE AIRBAG OFF
VSAOFF
Immobilizer (blinks): improperly
coded key; use correct key
Headlightson
Turn signals/hazards on
CRUISE MAIN on
CRUISE CONTROL on Fog lights
onHigh beams on
Briefly appear with each engine start. Red and amber indicators are most critical.
Blue and green indicators are used for general information.
3
2
C o n d i t i o n I n d i c a t o r s
Action is needed by driver
Parking brake on:
ReleaseMessage indicator:
See MID
Door/tailgate open:
Close door or tailgateLow tire pressure (stays on):
Add air
Seat belt reminder:
Fasten seat belt(s)Low fuel:
Refill
11 TSX 5D ATG\fATG_NEW STYLE 9/9/2010 2\f51 PM Page 3

M U L T I I N F O R M A T I O N D I S P L A Y ( M I D )
A c c e s s i n g t h e M I DM a i n D i s p l a y s
Consists of several displays that provide you with useful information.Main display
When you start the engine\b the MID shows
the last active lower display from the
previous drive cycle.
To toggle between the different
displays\bpresseither Info button
(▲/▼) for the main displays and
press the SEL/RESET button for
the lower displays.SEL/RESET
button
INFO
buttons
5
4
Instant fuel economy
Average fuel economy
Range
Bluetooth®HandsFreeLink®(HFL)*
Tire pressure monitor
Average speed
Elapsed time
* if phone is paired
L o w e r D i s p l a y s
Oil lifeOdometer\b
Outside
temperature Trip A\b
Outside
temperature Trip B\b
Outside
temperature
11 TSX 5D ATG\fATG_NEW STYLE 9/9/2010 2\f52 PM Page 4

7
6
T i r e P r e s s u r e M o n i t o r i n g S y s t e m
Alerts you when one or more of your tires have significantly low pressure.
Toggle
to the tire pressure monitor display to view pressure readings on
the MID.
H o w I t W o r k s
If the tire pressure drops significantly below recommended levels:
• The low tire pressure indicator comes on.
• A "CHECK TIRE PRESSURE" message appears on the MID.
• The tire icon(s) showing low pressure blinks.
W h a t t o D o
1. Visually inspect the tires for
damage.
2. Use a tire air pressure gauge
(or check the MID) to check
which tire(s) have low pressure.
3. Inflate the tire(s)\b if necessary\b
to the recommended pressures
listed on the label on the
driver’s doorjamb.
C u s t o m i z i n g S e t t i n g s U s i n g t h e M I D
1. Select “CHG SETTING.”
3. Select “AUTO DOOR
UNLOCK.”4. Select “ALL DOORS with
SHIFT TO P.”
5. Once the setting has been saved\b select“EXIT.”
Four groups of settings can be programmed using the MID*: Meter Setup\b Position
Setup\b Lighting Setup\b and Door Setup.
SEL/RESET
button
INFO
buttons
Pressthe Info button to toggle to
the “Keyless Memory Settings”
display\b then pressSEL/RESET to
activate the menu.
M o d i f y i n g t h e A u t o D o o r U n l o c k S e t t i n g
* See Customized Settings in your owner’s manual for other programmable settings.
2. Select “DOOR SETUP.”
As the default setting\b only the driver's door unlocks when you shift to Park.
Follow the steps below to set all doors to unlock when you shift to Park:
11 TSX 5D ATG\fATG_NEW STYLE 9/9/2010 2\f53 PM Page 5

K E Y L E S S M E M O R Y S E T T I N G S
2. Check the MID:• If you have the correct remote\b the driver ID that first appears onthe MID will match the ID number on the back of your remote.
Go to step 3.
• If the numbers do not match\b follow these simple instructions:
-Remove the key from the ignition switch.
- Press the unlock button on your remote.
- Insert the key into the ignition switch\b turnit to ON (II)\b and
check the MID. The driver ID that first appears on the MID
should now match the number on the back of your remote.
When linked\b each remote (labeled 1 or 2 on the back) activates its own set of driving
position memory and customized settings (through the MID).
1. Verify that you are using the correct remote by inserting the key inthe ignition switch and turning to ON (II).
C h e c k p o i n t
3. Once you have the correct remote\b you can begin to program yourKeyless Memory Settings.
C u s t o m i z i n g S e t t i n g s
D r i v i n g P o s i t i o n M e m o r y S y s t e m ( D P M S )
1. Turn the ignition switch to
ON (II). Shiftinto Park (P).3.Press and hold the SET button
until you hear a beep\b then
release.
2. Adjust your preferred seat
settings.4. Press and hold the memory
button # corresponding to the
remote (1 or 2) you are using
until you hear two beeps.
* See Customized Settings in your owner’s manual for other programmable settings.
Note:A stored memory position is linked to the corresponding keyless remote
(1 or 2). The driver’s seat begins to adjust when you unlock the driver’s door
with the remote and enter the vehicle.
9
8
11 TSX 5D ATG\fATG_NEW STYLE 9/9/2010 2\f53 PM Page \b

11
1\f
R E V E R S E T I L T D O O R M I R R O R
H o w I t W o r k s
When you shift into Reverse (R)\b the passenger’s outside door mirror tilts down slightly
to improve your view as you parallel park. Shifting out of Reverse returns the tilted
mirror to its original position.
• To tilt the passenger’s
door mirror\b movethe
mirror selector switch
to the right (R)
position when in
Reverse.
• To turn the feature off\b move the switch
to the middle or left
(L) position.
R E A R V I E W C A M E R A( T e c h n o l o g y P a c k a g e )
For added convenience\b the area behind your vehicle is displayed to help
you navigate while backing up.
• When you shift into Reverse\b a real-time image of the area behind your vehicle is shown in the
navigation display.
• Yellow parking guidelines also appear to help you judge distance.
• Adjust the screen brightness by turning the
Interface Dial.
• The display turns off when you shift out of Reverse.
H o w I t W o r k s
H O M E L I N K ®
Press and hold the button on the
remote and the HomeLink buttonat
the same time. Then, while
continuing to hold the HomeLink
button, press and release the button
on the remote every 2seconds.
Does the LED blink at a faster ratewithin 20
seconds?
Press and hold
the HomeLink
button again. Training
complete
YES
NO
HomeLink indicator
flashes for 2 seconds,
then remains on. HomeLink LED
remains on.YES
NO YES
NO
Position the remote transmitter you
wish to link 1–3 inches from the
HomeLink button you want to program.1
Press and hold the desired
HomeLink button and the button on
the remote transmitter.
Does the HomeLink indicator (LED) blink at a
faster rate after about 10 seconds?
2
a
The remote has a rolling code.
Pressthe “learn” button on the
remote-controlled device (e.g.,
garage door opener).
Press the programmed HomeLink
button again; the remote-controlled
device should operate. Within 30 seconds, pressand
hold the programmed HomeLink
button for 2 seconds.a
Press and hold the programmed
HomeLink button for about a
second.
Does the device (garage door opener) work?
3
b
4
5
T r a i n i n g a B u t t o n
The HomeLink Universal Transceiver built into your vehicle can be programmed to
operate up to three remote-controlled devices around your home\b such as garage
doors\b lighting\b or home security systems.
If you have any problems programming HomeLink\b see the owner’s manual
included with the device you are trying to program\b call HomeLink at
(8\f\f) 355-3515\b or visit www.homelink.com.
11 TSX 5D ATG\fATG_NEW STYLE 9/9/2010 2\f54 PM Page 7

P O W E R T A I L G A T E( T e c h n o l o g y P a c k a g e )
O p e n i n g t h e P o w e r T a i l g a t e f r o m I n s i d e t h e V e h i c l e
Use multiple methods to operate the power tailgate when the vehicle is in Park (P).
O p e n i n g t h e P o w e r T a i l g a t e U s i n g t h e K e y
In ANYTIME mode:Press and
hold the tailgate button for
about one second. In WHEN UNLOCKED mode:
Press
the unlock button twice
to unlock all doors and the
tailgate. Then press and hold
the tailgate button for about
one second.
Make sure the power tailgate keyless open mode is set to your preference using
the MID. See your Owner’s Manual for instructions\b or see
page 7for an example
of how to change a setting. •
Press and hold the tailgate
button until a beep sounds.
The tailgate begins to open.
• To close the tailgate\b press
the button again at any time.
F U E L F I L L D O O R
O p e n i n g t h e F u e l F i l l D o o r
C l o s i n g t h e F u e l F i l l D o o r
Easy-to-use locking fuel door keeps your fuel cap covered.
When you unlock the driver’s door\b
the fuel door unlocks.
To open\b push and release the fuel
door in the area shown until it
pops open.
Push the fuel door until it is flush to the
body.
When you lockthe driver’s door\b
the fuel door locks.
NOTE: If you lock the doors while
the fuel door is open\b you must
unlock the doors to close the fuel
door.
13
12
11 TSX 5D ATG\fATG_NEW STYLE 9/9/2010 2\f54 PM Page 8
