d Shift the transmission into Park (P) (automatic) or Neutral (manual
only) ⇒  Shifting.
d Stop the engine and remove the key from the ignition switch ⇒ 
Starting and stopping the engine.
d Let the engine cool down sufficiently.
d Keep children and others away from the vehicle.
d Make sure the vehicle cannot move unexpectedly.
WARNING
Disregarding the safety-related checklist may result in serious
injuries.
Always review and follow the checklist. Follow accepted safe-
ty practices and use common sense.
Opening or closing the engine compartment

Fig. 163 In the footwell on the driver side: Inside engine hood release
lever.

Fig. 164 Above the radiator grille: Outside engine hood release.

WARNING
If the hood is not closed properly, it could fly up and block your
view while you are driving. This can lead to a crash and serious
personal injuries.
After closing the engine hood, check that the hood release
lever is properly latched into the hood latch. The engine hood
must be flush with the surrounding auto body parts.
If you ever notice that the hood latch is not properly secured
when the vehicle is moving, stop at once and close it.
Never let anyone get in the way of the hood when closing it.
NOTICE
Make sure the windshield wipers are switched off and the
windshield wiper arms are resting on the windshield before you
open the hood. Otherwise, the windshield wipers and the hood
may be damaged.
Always put the windshield wiper arms down against the wind-
shield before driving the vehicle.
NOTICE
Before opening or closing the engine hood, make sure there is
enough room to do so, for example when the vehicle is in a gar-
age.

Engine oil

properly in accordance with applicable environmental laws and regu-
lations.
Warning and indicator lights

For vehicles with the 3.6 liter engine, the engine oil temperature can
be displayed in the Volkswagen Information System MFI menu ⇒  MFI
menu (Multi-Function Indicator).
WARNING
Failure to heed warning lights and instrument cluster text mes-
sages can cause the vehicle to break down in traffic and result
in a collision and serious personal injury.
Never ignore warning lights or text WARNINGS.
Always stop the vehicle as soon as it is safe to do so.
NOTICE
Failure to heed warning lights or text WARNINGS can result in
vehicle damage.
Engine oil specifications

Your engine was factory-filled with a high-quality, “synthetic” all-
season engine oil that meets strict Volkswagen oil quality standards
and has a viscosity grade of SAE 5W-40 or SAE 5W-30. You can use
this oil for normal driving in all temperatures.
If you need to add oil between oil changes, use only a high quality oil
that expressly complies with the Volkswagen oil quality standard
specified for your vehicle's engine:

Engines Engine oil specification
200 hp (147 kW), 2.0L
VW 502 00
VW 503 00
VW 504 00
280 hp (206 kW), 3.6L
VW 501 01
VW 502 00
VW 503 00

At the time this Manual was printed, the engine oils available in the
U.S. that meet these Volkswagen standards are “synthetic” oils. This
does not mean, however, that any “synthetic” engine oil will meet
Volkswagen standards. Always use an approved oil that expressly
complies with the Volkswagen oil quality standard that applies to your
vehicle's engine.
General recommendations:
If “synthetic” oil that meets the applicable Volkswagen oil quality
standard with viscosity grade SAE 5W-40 or SAE 5W-30 is not avail-
able in your area, be sure to use a viscosity grade suitable for the
climate, season, and operating conditions that exist where the vehicle
is used. Make sure the oil meets the quality standard.
Engine oils are constantly being improved. Authorized Volkswagen
dealers and authorized Volkswagen Service Facilities are always up-
to-date regarding new developments and changes. Volkswagen
therefore recommends that you have the engine oil changed by an
authorized Volkswagen dealer or an authorized Volkswagen Service
Facility.

NOTICE
If you need to add oil and there is none available that meets
the Volkswagen oil quality standard your engine requires, you
may add a total of no more than 1/2 quart (0.5 liter) of a high-
quality “synthetic” oil that meets ACEA A3 specifications and
has a viscosity grade of SAE 5W-40 or SAE 5W-30.
Use only a high quality engine oil that expressly complies with
the Volkswagen oil quality standard specified for your vehicle's
engine. Using any other oil can cause serious engine damage
that will not be covered by any Volkswagen Limited Warranty.
Do not mix any lubricants or other additives into the engine
oil. Doing so can cause engine damage! Damage caused by the-
se kinds of additives are not covered by any Volkswagen Limited
Warranty.
Engine oil capacities
