260
3-1. Using the air conditioning system and defogger
Rear window and outside rear view mirror defoggers, and windshield wiper de-icer
■The defogger can be operated when
The engine switch is in the “ON” position.
■ Outside rear view mirror defoggers (vehicles with outside rear view
mirror defoggers)
Turning the rear window defogger on will turn the outside rear view mirror
defoggers on.
■ Windshield wiper de-icer (vehicl es with windshield wiper de-icer)
Turning the rear window defogger on will turn the windshield wiper de-icer
on.
The rear window defogger is used to defog the rear window. The out-
side rear view mirror defoggers
*1 are used to remove frost, dew or
raindrops from the outside rear vi ew mirrors. The windshield wiper
de-icer
*2 is used to prevent ice from building up on the windshield
and wiper blades.
On/off
The defoggers and de-icer will
automatically turn off after
approximately 15 minutes.
*1: Vehicles with outside rear view mirror defoggers
*2: Vehicles with windshield wiper de-icer

261
3-1. Using the air conditioning system
and defogger
3
Interior features
CAUTION
■Outside rear view mirror defoggers (vehicles with outside rear view
mirror defoggers)
The surfaces of the outside rear view mirrors become hot. Do not touch
them to prevent from burning yourself.
■ When the windshield wiper de-icer is on (vehicles with windshield
wiper de-icer)
Do not touch the glass at the lower part of the windshield or to the side of the
front pillars as the surfaces can become very hot and burn you.

386
3-7. Other interior features
Conversation mirror
CAUTION
■Caution while driving
Do not adjust the position of the mirror while driving.
Doing so may lead to mishandling of the vehicle and an accident, resulting in
death or serious injury.
The conversation mirror can provide the driver and the front passen-
ger with a view of the rear seat area without the need to turn around.
Push the tab and flip down the
lid.
The mirror can be adjusted by
pushing its edge.STEP1
STEP2

481
4-3. Do-it-yourself maintenance
4
Maintenance and care
■
Under the driver’s side instrument panel
FuseAmpereCircuit
1 MIR HTR 10 A Outside rear view mirror defoggers
2RAD2 7.5 A Audio system, navigation system,
rear seat entertainment system
3 PWR OUTLET 15 A Power outlets
4 CIG 15 A Cigarette lighter
5 ECU ACC 7.5 A Shift lock control system, air condi-
tioning system, power rear view
mirror control
6 GAUGE2 7.5 A Meter and gauge
7 IGN 7.5 A Multiport fuel injection system/
sequential multiport fuel injection
system, SRS airbag system, multi-
plex communication system
8 IG2 7.5 A Multiport fuel injection system/
sequential multiport fuel injection
system
9 RR WIP 15 A Rear window wiper
10 WIP 30 A Windshield wiper and rear window
wiper
11 GAUGE1 10 A Back-up lights, turn signal lights,
emergency flashers
12 S-HTR 15 A Seat heaters

482 4-3. Do-it-yourself maintenance
13 WSH20 AWindshield washer and rear win-
dow washer
14 HTR 10 A Air conditioning system
15 ECU-IG 10 AIntuitive parking assist system, rear
view monitor system, multiplex
communication system, multiport
fuel injection system/sequential
multiport fuel injection system, anti-
lock brake system, traction control
system, vehicle stability control
system, shift lock control system,
dynamic laser cruise control sys-
tem, seat heaters, power back
door, moon roof, multi-information
display, auto anti-glare inside rear
view mirror, power windows, power
outlets (115 V), power third seat,
driving position memory system
16 PANEL 10 AAir conditioning system, seat heat-
ers, audio system, navigation sys-
tem, power sliding door, power
back door, trip information display,
rear window defogger, emergency
flashers, instrument panel lights,
steering switch lights
17 TAIL 10 AStop/tail lights, license plate lights,
parking lights, side maker lights
18 S/ROOF 25 A Moon roof
19 AC INV 15 A Power outlets (115 V)
20 FR DEF 15 A Windshield wiper de-icer
21 AM1 7.5 AMultiport fuel injection system/
sequential multiport fuel injection
system, starter system
FuseAmpereCircuit

483
4-3. Do-it-yourself maintenance
4
Maintenance and care
22 STOP
10 AStop/tail lights, high mounted stop-
light, shift lock control system, anti-
lock brake system, traction control
system, vehicle stability control
system, multiport fuel injection sys-
tem/sequential multiport fuel injec-
tion system, multiplex
communication system
23 P/W 25 APower windows, power rear view
mirror
24 OBD 7.5 A On-board diagnosis system
25 FOG 15 A Front fog lights
26 P/VENT 15 A Power quarter windows
27 P/SEAT 30 A Power front seats
28 PWR 30 A Power windows
FuseAmpereCircuit

583
Alphabetical index
I/M test ...................................... 429
Identification
Engine .................................. 543
Vehicle.................................. 543
Ignition switch ......................... 167
Illuminated entry system ........ 361
Indicator lights ........................ 177
Initialization
Items to initialize ................... 568
Inside rear view mirror.............. 95
Interior lights Interior lights ......................... 361
Switch ................................... 362
Wattage ................................ 549
Intuitive parking assist ........... 209
Jack Positioning a floor jack ......... 436
Replacing the wheel ............. 516
Jack handle.............................. 516
Keyless entry ............................. 27
Keys Engine switch ....................... 167
If you lose your keys/
wireless remote control
transmitter .......................... 531
Ignition switch ....................... 167
Keyless entry .......................... 27
Key number ............................ 26
Keys ....................................... 26
Wireless remote control.......... 27 License plate lights
Replacing light bulbs .............486
Wattage .................................549
Light bulbs Replacing ..............................486
Wattage .................................549
Lights Door courtesy lights ..............361
Engine switch light ................361
Fog light switch .....................190
Headlight switch ....................185
Interior light switch ................362
Luggage compartment light .....................................363
Outer foot lights .....................361
Personal light switch .............362
Replacing light bulbs .............486
Turn signal lever....................172
Vanity lights ...........................384
Wattage .................................549
Load capacity ...........................225
Lock steering column ..............167
Luggage compartment light Switch....................................363
Wattage .................................549I
J
K
L

584 Alphabetical index
MaintenanceDo-it-yourself
maintenance ....................... 430
General maintenance ............ 426
Maintenance data.................. 542
Maintenance requirements.... 424
Meter Instrument panel light
control ................................. 176
Meters ................................... 174
Mirrors
Conversation mirror............... 386
Inside rear view mirror.............95
Side mirror heaters................260
Side mirrors .............................97
Vanity mirrors ........................ 384
Moon roof ................................. 104
MP3 disc ................................... 279
Noise from under vehicle ..........20
Note pad holder........................ 381
Odometer .................................. 174
Oil
Engine oil .............................. 439
Opener Back door ................................47
Fuel filler door ....................... 107
Hood...................................... 434
Outer foot lights
Outer foot lights ..................... 361
Replacing light bulbs ............. 486
Wattage ................................. 549
Outside rear view mirrors Adjusting and folding ...............97
Driving position memory..........80
Overheating, Engine ................536 Parking assist sensors............ 209
Parking brake ........................... 173
Parking lights
Replacing light bulbs ............. 486
Switch ................................... 185
Wattage................................. 549
Personal lights Switch ................................... 362
Wattage................................. 549
Power outlets ........................... 387
Power windows ................ 100, 102
Quarter windows...................... 102
Radiator .................................... 446
Radio ......................................... 265
Rear automatic air conditioning system ............. 256
Rear manual air conditioning system .................................... 253
Rear seat
Adjustment ........................ 59, 61
Folding third seats............. 71, 72
Installing second seats............ 66
Removing second seats.......... 65
Seating configurations ............ 63
Stowing third seats............ 73, 75
Tumbling second seats ........... 63
Rear seat entertainment system Initial setting .......................... 320
Rear seat entertainment
system ................................ 296
Rear side marker lights
Replacing light bulbs ............. 486
Wattage................................. 549M
N
O
P
Q
R
