68 1-3. Adjustable components (seats, mirrors, steering wheel)
Center seat: Disengage the rear
leg locks by pulling the rear leg
release lever.
Reinstall the seat following the correct procedure.
■ Changing the installed position
Outer seat (7-passenger models)
The right side second seat can
be moved to the inside when the
console box (if equipped) is not
installed between the second
seats.STEP1
STEP2
368 3-6. Using the storage features
CAUTION
■Caution while driving
Keep the console box closed.
Injuries may result in the event of an accident or sudden braking.
■ When installing the console box (7-passenger models)
●Be careful not to catch hands or feet in or under the console box.
● Make sure that the console box is securely installed by pushing it back and
forth, upward and sideways. Failure to do so may result in serious injury in
the event of sudden braking or a collision.
■ When installing the console box between the second seats (7-passen-
ger models)
Do not install the console box by any means other than the center striker
between the second seats. Doing so may result in serious injury in the event
of sudden braking or a collision, which may lead to an accident.
Console box
