5-2. Steps to take in an emergency
If a war ning light tur ns on or a war ning buzzer sounds...
Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous.
The following warning indicates a possible problem in the brake sys-
tem. Immediately stop the vehicle in a safe place and contact your
Toyota dealer.
*: Parking brake engaged warning buzzer: The buzzer sounds to indicate that the parking brake is still engaged (with the vehicle having reached a speed
of 3 mph [5 km/h]).
Warning lightWarning light/Details
(U.S.A.)
(Canada) Brake system warning light (warning buzzer)*
• Low brake fluid
• Malfunction in the brake system
This light also comes on when the parking brake is not
released. If the light turns off after the parking brake is fully
released, the system is operating normally.
Calmly perform the following actions if any of the warning lights turn
on or flash. If a light turns on or flashes, but then turns off, this does
not necessarily indicate a malfunction in the system.

581
Alphabetical index
Emergency, in case of
If the back door opener is
inoperative ........................... 49
If the engine will not start...... 529
If the shift lever cannot be shifted ................................ 530
If the vehicle has discharged battery ................................ 532
If the warning buzzer sounds... ........................... 504
If the warning light turns
on ....................................... 504
If you have a flat tire .... 515, 516
If you lose your keys/ wireless remote control
transmitter .......................... 531
If you think something is
wrong ................................. 500
If your vehicle becomes stuck................................... 539
If your vehicle needs to be towed ................................. 496
If your vehicle overheats ...... 536
Engine Compartment........................ 438
Engine switch ....................... 167
Hood ..................................... 434
How to start the engine ................................ 167
Identification number ............ 543
If the engine will not start...... 529
Ignition switch ....................... 167
Overheating .......................... 536 Engine coolant
Capacity ................................546
Checking ...............................444
Preparing and checking before winter ..................................226
Engine coolan t temperature
gauge ......................................174
Engine immobilizer system.....111
Engine oil
Capacity ................................545
Checking ...............................439
Preparing and checking before winter ..................................226
Engine oil maintenance
data .........................................442
Event data recorder .................502
Floor mat...................................401
Fluid Brake .....................................446
Power steering ......................448
Washer ..................................453
Fog lights Replacing light bulbs .............486
Switch....................................190
Wattage .................................549
Front automatic air conditioning system..............246E
F

586 Alphabetical index
Spare tireInflation pressure................... 548
Spare tire............................... 516
Spark plug ................................ 546
Specifications........................... 542
Speech command switch ........ 332
Speedometer ............................ 174
Steering Column lock release.............. 167
Steering wheel Adjustment ..............................94
Audio switches ...................... 292
Stop lights Replacing light bulbs ............. 486
Wattage ................................. 549
Storage feature......................... 364
Storage precautions ................223
Stuck If your vehicle becomes stuck ................................... 539
Sunshades Rear door .............................. 393
Roof....................................... 105
Sun visors................................. 383
Switch Engine switch ........................ 167
Fog light switch ..................... 190
Ignition switch........................ 167
Light switches........................ 185
Power door lock switch ...........33
Power window switch .... 100, 102
Window lock switch ............... 100
Wiper and washer
switch .......................... 191, 193 Tables
Front seat side table ............. 399
Seatback tables .................... 397
Tachometer .............................. 174
Tail lights Replacing light bulbs ............. 486
Switch ................................... 185
Wattage................................. 549
Talk switch ............................... 332
Telephone switch..................... 332
Theft deterrent system Alarm..................................... 113
Engine immobilizer system ... 111
Theft prevention labels ........... 115
Third seats.................................. 61
Tire inflation pressure ............. 463
Tire information
Glossary ................................ 559
Size ....................................... 548
Tire identification number...... 555
Uniform tire quality grading................................ 557
Tires
Chains ................................... 226
Checking ............................... 454
If you have a flat tire...... 515, 516
Inflation pressure .................. 463
Information ............................ 553
Replacing .............................. 516
Rotating tires ......................... 454
Size ....................................... 548
Snow tires ............................. 226
Tire pressure warning system ........................ 454, 507
Tools ......................................... 516
Total load capacity .................. 225T

587
Alphabetical index
Towing
Dinghy towing ....................... 237
Trailer towing ........................ 229
Traction control ....................... 215
TRAC ........................................ 215
Trays......................................... 380
Trip information display ......... 181
Trip meter................................. 174
Turn signal lights Replacing light bulbs ............ 486
Switch ................................... 172
Wattage ................................ 549
Valet key..................................... 26
Vanity lights Vanity lights .......................... 384
Wattage ................................ 549
Vanity mirrors .......................... 384
Vehicle identification number................................... 543
Vehicle stability control .......... 215
VSC ........................................... 215 Warning buzzers
Brake system ........................504
Seat belt reminder .................507
Warning lights Anti-lock brake system ..........505
Brake assist system ..............505
Brake system ........................504
Charging system .... ...............505
Dynamic laser cruise control master warning light............507
Engine oil pressure ...............505
Low fuel level ........................507
Low washer fluid ...................507
Malfunction indicator lamp ....505
Master warning light ..............507
Open door .............................507
Pretensioners ........................505
Seat belt reminder light .........507
SRS airbags ..........................505
Third seat warning light ......... 507
Tire pressure warning light ....507
Vehicle stability control system ................................505
Washer Checking ...............................453
Preparing and checking before winter .......................226
Switch............................191, 193
Washing and waxing ...............418
V
W

591
What to do if...
■
Warning lights
P. 507
or
P. 5 0 4P. 507
P. 5 0 5P. 507
P. 5 0 5P. 507
P. 507
or
P. 5 0 5P. 507
P. 5 0 5P. 507
P. 5 0 7P. 507
or
P. 5 0 5
P. 5 0 5
Brake system warning
lightLow fuel level warning
light
Driver’s seat belt
reminder light
Charging system warn-
ing lightFront passenger’s seat belt
reminder light
Low engine oil pressure
warning lightEngine oil replacement
reminder light
Malfunction indicator
lampLow washer fluid warn-
ing light
Tire pressure warning
light
SRS warning lightThird seat warning light
Open door warning lightDynamic laser cruise control
master warning light
“ABS” warning light
“VSC” warning light
