2010 Seat Altea Owner's Manual

ALTEAOWNER’S MANUALInglés 5P0012003DG (07.09) (GT9)
5P0012003DG
ALTEA Inglés (07.09)
Portada ALTEA.qxd:Maquetación 1 1/9/09 13:08 Página 3

SEAT S.A. se preocupa constantemente por mantener todos sus tipos y modelos en un desarrollo continuo. Por ello le rogamos que com-
prenda que, en cualquier momento, puedan producirse modificaciones del vehículo entregado en cuanto a la forma, el equipamiento y la
técnica. Por esta razón, no se puede derivar derecho alguno ba sándose en los datos, las ilustraciones y descripciones del prese nte
Manual.
Los textos, las ilustraciones y las normas de este manual se basan en el estado de la información en el momento de la realizaci ón de la
impresión. Salvo error u omisión, la información recogida en el presente manual es válida en la fecha de cierre de su edición.
No está permitida la reimpresión, la reproducción o la traducción, total o parcial, sin la autorización escrita de SEAT.
SEAT se reserva expresamente todos los derechos según la ley sobre el "Copyright". Reservados todos los derechos sobre modifica ción.
Este papel está fabricado con celulosa blanqueada sin cloro.
© SEAT S.A. - Reimpresión: 15.07.09
Portada ALTEA_interior.qxd:maquetación 1/9/09 13:12 Página 1

ForewordThis Instruction manual and its corresponding supplements should be read carefully to familiarise yourself with
your vehicle.
Besides the regular care and maintenance of the vehicle, its correct handling will contribute to preserve its value.
For safety reasons, note the information concerning accessories, modifications and parts change.
If selling the vehicle, give all of the onboard documentation to the new owner as this should be kept with the
vehicle.
