2010 RENAULT SCENIC wheel

PETROL INJECTION
Fault finding - Interpretation of faults
17B
17B-116
PETROL INJECTION
Fault finding - Interpretation of faults
17B
17B-116V9 MR-372-J84-17B050$423.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
DF639
PRESENT
OR
STOREDCOMBUSTION MISFIRE IN LPG MODE
1.DEF: Destructive misfiring
2.DEF: Pollutant misfiring
3.DEF: Non-compliance with emission control standards
NOTESPriority when dealing with a number of faults:
– LPG fuel system: see 17C, LPG injection,
– ignition:
DF361 Ignition coil circuit cylinders 1-4,
DF362 Ignition coil circuit cylinders 2-3.
– flywheel signal:
DF154 Flywheel signal sensor circuit,
DF457 Engine flywheel target.
– cylinder combustion misfires:
DF059 Combustion misfire in cylinder 1,
DF060 Combustion misfire in cylinder 2,
DF061 Combustion misfire in cylinder 3,
DF062 Combustion misfire in cylinder 4.
Conditions for applying the fault finding procedure to stored faults:
The fault is considered present under the following conditions:
– there must be no further electrical faults,
– the programming must have been done, particularly the flywheel target,
– engine warm (min 75°C),
– run the engine at idle speed with all electrical consumers switched on for
approximately 15 minutes.
Special note:
– catalytic converter misfire: OBD warning light flashes when the fault is present then
is continuously lit,
– pollutant combustion misfire: OBD warning light lit continuously.
– engine unstable, loss of power and vibrations.
Check the LPG injectors.
Check the condition and conformity of the spark plugs.
Check the ignition pencil coils.
If the fault is still present, carry out the following checks:
– check the flywheel sensor,
– check the condition and cleanliness of the flywheel,
– check the flywheel sensor mounting,
– check the sensor/flywheel air gap,
– check the cylinder compressions,
– check the LPG fuel system,
– check the complete ignition system (see MR 364 or 370 Mechanics, 17A, Ignition),
– check the hydraulic tappets if there is camshaft noise (see MR 364 or 370 Mechanics, 11A, Top and front of
engine).
If the fault is still present, deal with the other faults then proceed with the conformity check.
AFTER REPAIRFollow the instructions to confirm repair.
Deal with any other faults.
Clear the stored faults.
S3000_V4C_DF639/S3000_V54_DF639

PETROL INJECTION
Fault finding - Conformity check
17B
17B-121
PETROL INJECTION
Fault finding - Conformity check
17B
17B-121V9 MR-372-J84-17B050$470.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
SUB FUNCTION: SUB-FUNCTION (TURBOCHARGING/INLET):
NOTESOnly check the conformity after a complete check with the diagnostic tool. The values
shown in this conformity check are given as a guide.
Application conditions: Engine off, ignition on.
Order FunctionParameter or Status
Checked or ActionDisplay and notes Fault finding
1
Air circuit
pressurePR035:Atmospheric
pressurePR035 = 1000 mb
± 100 mbIf not consistent, check
PR035 = PR312 = local
atmospheric pressure,
with the engine stopped
and ignition on.
2 PR312:Inlet manifold
vacuumPR312 = 1000 mb
± 100 mbIn the event of a fault
apply the interpretation for
PR312 Inlet manifold
vacuum.
3 Engine speed PR055:Engine speedIndicates the engine's
speed of rotation in
rpm.
PR055 = 0 rpmIn the event of a fault,
apply the interpretation for
DF154 Flywheel signal
sensor circuit.
4
Idle speedET054:Idle speed
regulationINACTIVE None
5 PR010:Idle speed
regulation
setting700 < X < 750 rpm
Indicates the speed of
rotation setpoint before
last engine stop in rpm.None
6Air
temperaturePR058:Air
temperature- 40°C < PR058 < 120°C
Default value: 120°CIn the event of a fault,
apply the interpretation of
DF002 Air temperature
sensor circuit.
7 Coolant
temperaturePR064:Coolant
temperature- 40°C < PR064 < 120°C
Default value: - 39°CIn the event of a fault,
apply the interpretation of
DF001 Coolant
temperature sensor
circuit.

PETROL INJECTION
Fault finding - Conformity check
17B
17B-123
PETROL INJECTION
Fault finding - Conformity check
17B
17B-123V9 MR-372-J84-17B050$470.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
FUEL CIRCUIT SUB-FUNCTION:
NOTESOnly check the conformity after a complete check with the diagnostic tool. The values
shown in this conformity check are given as a guide.
Application conditions: Engine off, ignition on.
Order FunctionParameter or Status Checked
or ActionDisplay and notes Fault finding
1 Engine speed PR055:Engine speedIndicates the
engine's speed of
rotation in rpm.
PR055= 0rpmIn the event of a fault,
apply the
interpretation for
DF154 Flywheel
signal sensor
circuit.
2
Idle speedPR014:Idle speed correctionIndicates the engine
rotation speed
correction
in rpm.
0rpmNone
3ET054:Idle speed regulationINACTIVE None
PR010:Idle speed regulation
setting700 < X < 750 rpm
Indicates the speed
of rotation setpoint
before last engine
stop in rpm.None

PETROL INJECTION
Fault finding - Conformity check
17B
17B-133
PETROL INJECTION
Fault finding - Conformity check
17B
17B-133V9 MR-372-J84-17B050$470.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
PRE-HEATING/IGNITION SUB-FUNCTION:
NOTESOnly check the conformity after a complete check with the diagnostic tool. The values
shown in this conformity check are given as a guide.
Application conditions: Engine off, ignition on.
Order FunctionParameter or Status Checked
or ActionDisplay and notes Fault finding
1Cylinder
recognitionET061:Cylinder 1
recognitionCOMPLETEDIn the event of a fault,
apply the
interpretation for
status ET061
Cylinder 1
recognition.
2 Engine speed PR055:Engine speedIndicates the
engine's speed of
rotation in rpm.
PR055= 0rpmIn the event of a fault,
apply the
interpretation for
DF154 Flywheel
signal sensor
circuit.
3 Flywheel target ET089:Flywheel target
programmingCOMPLETEDSTATUS 1: Flywheel
target fault.
WITHOUT
4 Flywheel signal ET062:Flywheel signalNOT DETECTEDIn the event of a fault,
apply the
interpretation for
status ET062
Flywheel signal.
5
IgnitionPR448:Ignition advancePR448 = 0 °V
WITHOUT 6PR095:Anti-pinking
correctionPR095 = 0 °V
7 PR126:advance after anti-
pinking correction- 23.6 °V < PR126
<72°V
8PR427:Average pinking
signal0In the event of a fault,
apply the
interpretation of
DF088 Pinking
sensor circuit.

PETROL INJECTION
Fault finding - Conformity check
17B
17B-137
PETROL INJECTION
Fault finding - Conformity check
17B
17B-137V9 MR-372-J84-17B050$470.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
SUB-FUNCTION: COLD LOOP (continued 1):
NOTESOnly check the conformity after a complete check with the diagnostic tool. The values
shown in this conformity check are given as a guide.
Application conditions: Engine off, ignition on.
Order FunctionParameter or Status
Checked or ActionDisplay and notes Fault finding
4 Idle speed ET023:Fast idle speed
requestUCH requests the
injection system to
increase the idling
speed.
INACTIVE: The UCH
has not formulated a
request.
ACTIVE: The UCH has
formulated a requestIf ET023 is
inconsistent, run a
multiplex network
test using the
diagnostic tool; then
if the test is in order,
consult the UCH.
5 Engine speed PR055:Engine speedShows the speed of
rotation in rpm.
PR055= 0rpmIn the event of a fault,
apply the
interpretation for
DF154 Flywheel
signal sensor
circuit.
6
Air conditioningPR037:Refrigerant
pressure2Bar <27Bar
Default value: 0 Bar.If 1.DEF, apply
interpretation of
PR037 Coolant
pressure.
7 ET674:Refrigerant
pressure statusCORRECT
TOO LOW
8PR125:Power used by the
AC compressorPR125 = 300 W WITHOUT
9Coolant
temperaturePR064:Coolant
temperature- 40°C < PR064
< 120°C
Default value: - 39°CIn the event of a fault,
apply the
interpretation of
DF001 Coolant
temperature sensor
circuit.
10 Vehicle speed PR089:Vehicle speedGives the vehicle
speed in mph (km/h).
This parameter is
sent to the injection
by the ABS computer
via the multiplex
network.In the event of a fault,
apply the
interpretation of
DF091 Vehicle speed
signal.

PETROL INJECTION
Fault finding - Conformity check
17B
17B-145
PETROL INJECTION
Fault finding - Conformity check
17B
17B-145V9 MR-372-J84-17B050$470.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
SUB FUNCTION: AIR CIRCUIT (TURBOCHARGING/INLET):
NOTESOnly perform this conformity check after a complete check with the diagnostic tool.
The values shown in this conformity check are given as a guide.
Application conditions: Engine warm, idling.
Order FunctionParameter or Status
Checked or ActionDisplay and notes Fault finding
1
Air circuit
pressurePR035:Atmospheric
pressure200 mb < PR035 < 1047 mbIf not consistent, check
PR035 = PR312 =
local atmospheric
pressure, with the
engine stopped and
ignition on.
In the event of a fault
apply the
interpretation for
PR312 Inlet manifold
vacuum. 2 PR312:Inlet manifold
vacuumFor K4M:
240 mb < PR312 < 410 mb
For K4J:
330 mb < PR312 < 400 mb
For > F4Rt:
270 mb < PR312 < 400 mb
For F4R:
270 mb < PR312 < 410 mb
3 Engine speed PR055:Engine speedShows the engine's speed
of rotation
in rpm.
PR055= 0rpmIn the event of a fault,
apply the
interpretation for
DF154 Flywheel
signal sensor circuit.
4
Idle speedET054:Idle speed
regulationINACTIVE None
5 PR010:Idle speed
regulation
setting700 < X < 750 rpm
Indicates the rotation
speed setpoint before last
engine stop
in rpm.None
6Air
temperaturePR058:Air
temperature- 40°C < PR058 < 120°C
Default value: 120°CIn the event of a fault,
apply the
interpretation of
DF002 Air
temperature sensor
circuit.
7 Coolant
temperaturePR064:Coolant
temperature- 40°C < PR064 < 120°C
Default value: 120°CIn the event of a fault,
apply the
interpretation of
DF001 Coolant
temperature sensor
circuit.

PETROL INJECTION
Fault finding - Conformity check
17B
17B-147
PETROL INJECTION
Fault finding - Conformity check
17B
17B-147V9 MR-372-J84-17B050$517.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54PETROL INJECTION
Fault finding - Conformity check
FUEL CIRCUIT SUB-FUNCTION:
NOTESOnly perform this conformity check after a complete check with the diagnostic tool.
The values shown in this conformity check are given as a guide.
Application conditions: Engine warm, idling.
Order FunctionParameter or Status Checked
or ActionDisplay and notes Fault finding
1
Engine speedPR055:Engine speedIndicates the
engine's speed of
rotation in rpm.
700 rpm < PR055
< 800 rpmIn the event of a fault,
apply the
interpretation for
DF154 Flywheel
signal sensor
circuit.
2 PR014:Idle speed correctionIndicates the
correction of the
engine's rotational
speedin rpm.
0rpmIn the event of a fault,
apply the
interpretation for
DF154 Flywheel
signal sensor
circuit.
3
Idle speedET054:Idle speed regulationACTIVE None
4 PR010:Idle speed regulation
setting700 < X < 750 rpm
Indicates the speed
of rotation setpoint
before last engine
stop in rpm.None
MR-372-J84-17B050$517.mif

PETROL INJECTION
Fault finding - Conformity check
17B
17B-157
PETROL INJECTION
Fault finding - Conformity check
17B
17B-157V9 MR-372-J84-17B050$517.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
PREHEATING/IGNITION SUB-FUNCTION:
NOTESOnly perform this conformity check after a complete check with the diagnostic tool.
The values shown in this conformity check are given as a guide.
Application conditions: Engine warm, idling.
Order FunctionParameter or Status Checked
or ActionDisplay and notes Fault finding
1Cylinder
recognitionET061:Cylinder 1
recognitionCOMPLETEDIn the event of a fault,
apply the
interpretation for
status ET061
Cylinder 1
recognition.
2 Engine speed PR055:Engine speedIndicates the
engine's speed of
rotation in rpm.
700 rpm < PR055
< 800 rpmIn the event of a fault,
apply the
interpretation for
DF154 Flywheel
signal sensor
circuit.
3 Flywheel target ET089:Flywheel target
programmingCOMPLETEDSTATUS 1: Flywheel
target fault.
WITHOUT
4 Flywheel ET062:Flywheel signalDETECTEDIn the event of a fault,
apply the
interpretation for
status ET062
Flywheel signal.
5
IgnitionPR448:Ignition advance- 23.6 °V < PR448
<72°V
WITHOUT 6PR095:Anti-pinking
correction0 °V < PR095 < 8 °V
7 PR126:advance after anti-
pinking correction- 23.6 °V < PR126
<72°V
8PR427:Average pinking
signal10,000 < PR427
< 20,000In the event of a fault,
apply the
interpretation of
DF088 Pinking
sensor circuit.
