2010 RENAULT SCENIC Petrol Injection S3000 Injection Workshop Manual

PETROL INJECTION
Fault finding - Conformity check
17B
17B-161
PETROL INJECTION
Fault finding - Conformity check
17B
17B-161V9 MR-372-J84-17B050$517.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
SUB-FUNCTION: COLD LOOP (continued 1):
NOTESOnly perform this conformity check after a complete check with the diagnostic tool.
The values shown in this conformity check are given as a guide.
Application conditions: Engine warm, idling.
Order FunctionParameter or Status
Checked or ActionDisplay and notes Fault finding
4 ET023:Fast idle speed
requestUCH requests the
injection system to
increase the idling
speed.
INACTIVE: The UCH
has not formulated a
request.
ACTIVE: The UCH has
formulated a requestIf ET023 is
inconsistent, run a
multiplex network
test using the
diagnostic tool; then
if the test is in order,
consult the UCH.
5 Engine speed PR055:Engine speedShows the speed of
rotation in rpm.
700 rpm < PR055
< 800 rpmIn the event of a fault,
apply the
interpretation for
DF154 Flywheel
signal sensor
circuit.
6
Air conditioningPR037:Refrigerant
pressure2Bar <27Bar
Default value: 0 Bar.If 1.DEF, apply
interpretation of
PR037 Coolant
pressure.
7 ET674:Refrigerant
pressure statusCORRECT
TOO LOW
8PR125:Power used by the
AC compressor0 < PR125 < 300 W WITHOUT
9Coolant
temperaturePR064:Coolant
temperature- 40°C < PR064
< 120°C
Safe value: - 39°CIn the event of a fault,
apply the
interpretation of
DF001 Coolant
temperature sensor
circuit.
10 Vehicle speed PR089:Vehicle speedGives the vehicle
speed in mph (km/h).
This parameter is
sent to the injection
by the ABS computer
via the multiplex
network.In the event of a fault,
apply the
interpretation of
DF091 Vehicle speed
signal.

PETROL INJECTION
Fault finding - Conformity check
17B
17B-162
PETROL INJECTION
Fault finding - Conformity check
17B
17B-162V9 MR-372-J84-17B050$517.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
SUB-FUNCTION: COLD LOOP (continued 2):
NOTESOnly perform this conformity check after a complete check with the diagnostic tool.
The values shown in this conformity check are given as a guide.
Application conditions: Engine warm, idling.
Order FunctionParameter or Status Checked
or ActionDisplay and notes Fault finding
11
Fan assemblyET022:Low speed fan
assembly requestIf the coolant
temperature reaches
98°C, the low-speed
fan unit is activated,
and is shut down at
96°C
ACTIVE
INACTIVEIn the event of a
fault, run a multiplex
network test using
the diagnostic tool
then, if the test is in
order, consult the
Protection and
Switching Unit.
12 ET021:High speed fan
assembly requestIf the coolant
temperature reaches
102°C, the low-speed
fan assembly is
activated, and is shut
down at 99°C
ACTIVE
INACTIVE

PETROL INJECTION
Fault finding - Conformity check
17B
17B-163
PETROL INJECTION
Fault finding - Conformity check
17B
17B-163V9 MR-372-J84-17B050$517.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
HEATING SUB-FUNCTION:
OCR: Opening Cycle Ratio
NOTESOnly perform this conformity check after a complete check with the diagnostic tool.
The values shown in this conformity check are given as a guide.
Application conditions: Engine warm, idling.
Order FunctionParameter or Status
Checked or ActionDisplay and notes Fault finding
1Coolant
temperaturePR064:Coolant
temperature- 40°C < PR064 < 120°C
Safe value: - 39°CIn the event of a fault,
apply the
interpretation of
DF001 Coolant
temperature sensor
circuit.
2
Passenger
compartment
heating
resistorET111:RCH number setYES
NOIn the event of a
fault, run a multiplex
network test using
the diagnostic tool
then, if the test is in
order, consult the
Protection and
Switching Unit. 3ET112:RCH cut-offYES
NO

PETROL INJECTION
Fault finding - Conformity check
17B
17B-164
PETROL INJECTION
Fault finding - Conformity check
17B
17B-164V9 MR-372-J84-17B050$517.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
CRUISE CONTROL/SPEED LIMITER SUB-FUNCTION:
NOTESOnly perform this conformity check after a complete check with the diagnostic tool.
The values shown in this conformity check are given as a guide.
Application conditions: Engine warm, idling.
Order FunctionParameter or Status
Checked or ActionDisplay and notes Fault finding
1
Cruise control/
Speed limiterET042:Cruise control/
Speed limiterNOT DETECTED
INACTIVE
CRUISE CONTROL
SPEED LIMITERIn the event of a fault,
apply the
interpretation of
ET042 Cruise
control/speed
limiter.
2ET415:Deactivation of
cruise control/
speed limiterWITHOUT
STATUS 1: Traction
control request
STATUS 2: Brake pedal
depressed
STATUS 3: Clutch pedal
depressed
STATUS 4: Suspend
button pressed
STATUS 5: Cruise control
or speed limiter monitoring
STATUS 6: Gear lever in
neutral (manual gearbox)
or neutral position
(automatic transmission)
STATUS 7: Inconsistency
between the request and
the vehicle speed
STATUS 8: Automatic
transmission in defect
mode
STATUS 9: Vehicle speed
monitoring
STATUS 10: Monitoring
by injection computerIn the event of a fault,
apply the
interpretation of
ET415 Cruise
control/Speed
limiter deactivation.
3ET703:Cruise control/
speed limiter
buttonsINACTIVE
DECREASE
INCREASE
SUSPEND
RESUMEIn the event of a fault,
apply the
interpretation of status
ET703 Cruise
control/speed limiter
buttons.

PETROL INJECTION
Fault finding - Conformity check
17B
17B-165
PETROL INJECTION
Fault finding - Conformity check
17B
17B-165V9 MR-372-J84-17B050$517.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
CRUISE CONTROL/SPEED LIMITER SUB-FUNCTION (continued):
NOTESOnly perform this conformity check after a complete check with the diagnostic tool.
The values shown in this conformity check are given as a guide.
Application conditions: Engine warm, idling.
Order FunctionParameter or Status Checked
or ActionDisplay and notes Fault finding
4 Vehicle speed PR089:Vehicle speedGives the vehicle
speed in mph (km/h).
This parameter is
sent to the injection
by the ABS computer
via the multiplex
network.In the event of a fault,
apply the
interpretation of
DF091 Vehicle speed
signal.
5 Brake pedalET704:Brake switch no. 1
ACTIVE
INACTIVEIn the event of a fault,
apply the
interpretation of
statuses ET704
Brake switch no. 1
and ET705 Brake
switch no. 2. ET705:Brake switch no. 2
6Clutch pedal
switchET405:Clutch pedal switchINACTIVE: Clutch
pedal released.
ACTIVE: Clutch pedal
depressed.
If the vehicle is
fitted with an automatic
gearbox,
status ET405 must be
ACTIVEIn the event of a fault,
apply the
interpretation of
ET405 Clutch pedal
switch.

PETROL INJECTION
Fault finding - Conformity check
17B
17B-166
PETROL INJECTION
Fault finding - Conformity check
17B
17B-166V9 MR-372-J84-17B050$517.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
STARTING SUB-FUNCTION:
NOTESOnly perform this conformity check after a complete check with the diagnostic tool.
The values shown in this conformity check are given as a guide.
Application conditions: Engine warm, idling.
Order FunctionParameter or Status
Checked or ActionDisplay and notes Fault finding
1StartingET076:StartingAUTHORISEDAuthorisation to start is
given once the petrol
pump is pressurised
and if the motorised
throttle has emerged
from the stop and limp-
home position
programming phase.
2Actuator relay
controlET048:Actuator relay
controlACTIVEIf INACTIVE, apply the
interpretation of DF084
Actuator relay control
circuit.
3 Battery voltage PR074:Battery voltage11 V < PR074 < 15 VIn the event of a fault,
apply the interpretation of
DF046 Battery voltage.
4 Impact signal ET077:Impact
detectedNOIn the event of a fault,
run a multiplex network
test using the
diagnostic tool; then, if
the test is OK, carry out
fault finding on the
airbag computer.

PETROL INJECTION
Fault finding - Conformity check
17B
17B-167
PETROL INJECTION
Fault finding - Conformity check
17B
17B-167V9 MR-372-J84-17B050$517.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
PROTECTION SUB-FUNCTION:
NOTESOnly perform this conformity check after a complete check with the diagnostic tool.
The values shown in this conformity check are given as a guide.
Application conditions: Engine warm, idling.
Order FunctionParameter or Status
Checked or ActionDisplay and notes Fault finding
1Code
programmedET006:Code
programmedIndicates whether or
not the immobiliser
code has been
programmed by the
computer.
PROGRAMMED: Code
programmed.
NOT PROGRAMMED:
Code not programmed
by the injection
computer.If NOT PROGRAMMED,
contact the Techline
2Engine
immobiliserET003:Engine
immobiliserIndicates the status of
the immobiliser
system.
INACTIVEIf ET003 is inconsistent,
run a multiplex network
test using the
diagnostic tool; then if
the test is in order, carry
out fault finding on the
UCH.
3StartingET076:StartingAUTHORISEDAuthorisation to start is
given once the petrol
pump is pressurised
and if the motorised
throttle has emerged
from the stop and limp-
home position
programming phase.

PETROL INJECTION
Fault finding - Status summary table
17B
17B - 168
PETROL INJECTION
Fault finding - Status summary table
17B
17B - 168V9 MR-372-J84-17B050$564.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54PETROL INJECTION
Fault finding - Status summary table
Tool status Diagnostic tool title
ET001+ After ignition computer feed
ET003Engine immobiliser
ET004Air conditioning authorisation
ET006Code programmed
ET021High speed fan assembly request
ET022Low speed fan assembly request
ET023Fast idle speed request
ET042Cruise control/speed limiter
ET047Fuel pump control circuit
ET048Actuator relay control
ET050Canister bleed control
ET051Throttle stop programming
ET052Upstream O
2 sensor heating
ET053Downstream O
2 sensor heating
ET054Idle speed regulation
ET056Richness double loop
ET057Misfiring on cylinder 1
ET058Misfiring on cylinder 2
ET059Misfiring on cylinder 3
ET060Misfiring on cylinder 4
ET061Cylinder 1 recognition
ET062Flywheel signal
ET063Park/Neutral position
ET064Level 1 injection fault
ET065Level 2 Injection fault
ET066LPG fault
ET067LPG ready
ET068LPG tank empty
ET071Transition from petrol mode to LPG mode
ET072Transition from LPG mode to petrol mode
ET073Conditions for switching to LPG mode
ET075Pedal released and throttle closed
