270
Practical Tips, Emergency Service
Fitting towing hook
When fitting on the rear of the vehicle, the license
plate must be removed.
1. Press the lower edge of the appropriate
plastic cover into the bumper until the cover
disengages.
2. Pull cover out of the bumper and let it hang by its thread.
3. Completely screw in the towing hook A. Removing towing hook
1. Unscrew the towing hook
A.
2. Insert plastic cover at the lower edge of the opening.
3. Fold the cover up and press on its upper edge to engage it in the bumper.
When removing on the rear of the vehicle, the
license plate must be mouted.
Practical Tips, Emergency Service
271
Pulling vehicle onto flat bed 1. Position wooden ramps at the base of the flat bed to reduce the angle of the pull.
2. Reel in the hoist cable and check the underside of the vehicle for any interference.
Tieing down vehicle on flat bed 1. Carefully feed towing straps through the open-ing in the rear wheels .
Make sure metal parts of straps do not dam-
age rim.
Make sure the strap is flat over the rim bead.
Make sure brake backing plate is not dam-
aged.
2. Secure straps to rear of flat bed.
3. Reel in hoist cable only far enough to tension
tie-down straps. 4. Carefully feed towing
straps through the open-
ing in the front wheels .
Make sure metal parts of straps do not dam-
age rim.
Make sure the strap is flat over the rim bead.
Make sure brake backing plate is not dam-
aged.
5. Secure straps to front of flat bed.
6. Release tension on hoist cable, but do not dis- connect.
Use hoist cable as a safety cable.
Index
291
Pressure plate .................................... 275
Removing and storing.......................... 229
Sealant ...................... ................ 239, 240
Sidewall ..................... ........................ 232
Size ................................................... 232
Snow tires .............. ............................ 230
Tools ................ ........................................... 94
Towing ........................... .................... 269, 271
Towing hook............... ................................ 269
TPM Tire pressure moni toring ...................... 147
Track ............................. ............................ 278
Transmission Drive-Off Assistant... ............................ 172
Fluid........................... ................ 211, 281
Manual transmission ............................ 172
Porsche Doppelkupplung (PDK) .... 172, 174
Trip Odometer ............ ................................ 121
Trunk entrapment ....... .................................. 95
Turn signal Indicator light.......... ............................ 123
Turn signal light, front Changing bulb......... ............................ 263
Turn signals ......................................... 81, 123
UUndercoating ................ ......................208, 217VValves ........................................................228
Vanity mirror............. ....................................41
Vehicle Care......................... ..........................213
Engine number....................................275
Identification ......... ..............................274
Identification labe l ...............................274
Identification numbe r ...........................274
Lifting................... ..............................242
Load capacity ....... ..............................235
Putting into operat ion ..........................251
Safety compliance st icker ....................274
Washing ................... ..........................214
Vehicle identification number ........................274
Ventilation .................... ..............................109
Vents ................... ......................106, 109, 112
Viscosity, engine oil .....................................201
Voice control, button . ..................................130
Voice control, PCM ... ..................................130
WWarning lights and me ssages ...................... 162
Washer
Fluid ........................ .......................... 210
Fluid warning light. .............................. 210
Washer fluid ................................. .............. 281
Washer lever................................ ................ 82
Washing ...................... .............................. 214
Weights ........................................... .......... 282
Welcome Home Function ........................ 79, 80
Wheel ................. ................. 10, 223, 278, 279
Alignment ................ .......................... 229
Balancing........................................... 229
Bolts ....................... .......................... 236
Care ........................ .......................... 223
Changing ................. .......................... 239
Checking pressure ............................. 238
Inscription ............ .............................. 232
Loading information . ........................... 234
Securing bolts...... .............................. 236
Security wheel bolts ............................. 15
Sidewall ................... .......................... 232
Size .................................................. 232
Tire pressure ....... .............................. 224
Tire pressure plate ............... .............. 275
Tire sealant .............. .................. 239, 240
Wheels
Assembly aids for wheel changes ........ 237
Care ........................ .......................... 218
TPM sensors............ .......................... 229
Windows.......................... .................. 182, 216
Anti-crushing protection ........................ 28
Care ........................ .......................... 216
Opening/Closing ...................... ............ 27
