Page 29 of 237
Instruments and controls
32
Warning light is indicates Solution - action
ESP/ASR fl a s h i n g .
wheel skid avoided. The system optimises the traction and improves
t h e d i r e c t i o n a l s t a b i l i t y o f t h e v e h i c l e . C h a p t e r 4 ,
"Driving safety" section.
remaining on.
a malfunction of the system.
E . g . : u n d e r - i n fl a t i o n o f t h e t y r e s . Check the pressure of the tyres. Call a PEUGEOT
dealer.
remaining on with
t h e b u t t o n ( b e l o w
the steering
wheel on the left)
pressed.
deactivation of the system. T h e o p e r a t i o n o f t h e s y s t e m h a s b e e n
deactivated. Chapter 4, "Driving safety" section.
Diesel
pre-heating lit. climatic conditions requiring
pre-heating. W a i t u n t i l t h e w a r n i n g l i g h t i s s w i t c h e d o f f b e f o r e
operating the starter.
Dipped
headlamps/
Daytime
lights lit. manual selection or
automatic lighting.
Rotate the ring on the lights stalk to the second
position.
lighting of the dipped headlamps
from the time the ignition is switched
on - daytime lights. Depending on the
country in which the vehicle is sold.
Chapter 3, "Steering wheel controls" section.
Main beam
headlamps
pulling of the stalk towards
you. Pull the stalk to return to dipped headlamps.
and with an
a u d i b l e s i g n a l ,
ignition off. opening of the driver's door
with the lights still on.
Rotate the ring on the lights stalk to position 0.
Direction
indicators fl a s h i n g w i t h
b u z z e r . change of direction via the
lights stalk, to the left of the
steering wheel. T o t h e R i g h t : c o n t r o l t o b e p u s h e d u p w a r d s .
T o t h e L e f t : c o n t r o l t o b e p u s h e d d o w n w a r d s .
Page 40 of 237
42
Starting and stopping
STARTING AND STOPPING
STOP position: steering lock.
The ignition is off.
Good practice when starting Handbrake
I f y o u r v e h i c l e i s fi t t e d w i t h a
version with a rotating front seat,
t h e h a n d b r a k e c a n b e d i s e n g a g e d .
P u l l i n g t h e h a n d b r a k e t o i m m o b i l i s e
the vehicle then lowering the lever
d o e s n o t r e l e a s e t h e b r a k e , i t p e r m i t s
rotation of the driver’s seat.
P u l l t h e b u t t o n p l a c e d a t t h e e n d o f t h e
h a n d b r a k e f o r w a r d s .
T h e h a n d b r a k e l e v e r l o w e r s .
You can now rotate the seat.
To return to normal operation, pull the
lever up until it clicks.
I f t h e h a n d b r a k e i s o n o r h a s
n o t b e e n r e l e a s e d f u l l y , t h i s i s
i n d i c a t e d b y :
- a warning light which comes
on on the instrument panel,
- a n a u d i b l e s i g n a l ,
- a message on the display.
Key
Take care not to place the key in
contact with grease, dust, rain or a
damp environment.
A h e a v y o b j e c t a t t a c h e d t o t h e k e y
(key ring, ...) weighing down on the
shaft of the key in the ignition switch
may cause a malfunction.
Running and accessories position.
C e r t a i n a c c e s s o r i e s c a n b e u s e d .
Starting position.
The starter is operated. Diesel pre-heating warning
light
Turn the key to the Running
position.
In cold weather, wait for this warning
light to switch off then operate the
starter (Starting position) until the
engine starts.
If the temperature is high enough, the
warning light comes on for less than
one second, you can start without
waiting. Good practice when stopping
Minimise engine and gearbox wear
When switching off the ignition, let the
engine run for a few seconds to allow
t h e t u r b o c h a r g e r t o r e t u r n t o i d l e .
Do not press the accelerator when
switching off the ignition.
There is no need to engage a gear
after parking the vehicle.
Page 62 of 237
ERGONOMICS and COMFORT
3
6 3
Seats
Memorising seat positions
T w o d r i v i n g p o s i t i o n s c a n b e
m e m o r i s e d , u s i n g buttons M/1 a n d
M/2 .
T h e s e a r e l o c a t e d o n t h e s i d e o f t h e
seat:
- Place the ignition key in the " r u n n i n g " p o s i t i o n ( 2 n d n o t c h ) ,
- A d j u s t y o u r s e a t ,
- Press button M , t h e n b u t t o n 1 for
a fi r s t d r i v i n g p o s i t i o n w i t h i n f o u r
s e c o n d s .
Repeat the same actions on buttons M
a n d 2 t o s t o r e a n o t h e r d r i v i n g p o s i t i o n .
A n a u d i b l e s i g n a l c o n fi r m s t h a t a
p o s i t i o n h a s b e e n m e m o r i s e d .
Memorising a new position cancels the
previous one. Activating a memorised driving
position
Front heated seat controls
W h e n t h e e n g i n e i s r u n n i n g , t h e f r o n t
s e a t s c a n b e h e a t e d s e p a r a t e l y .
U s e t h e a d j u s t m e n t c o n t r o l s l o c a t e d o n
t h e s i d e o f e a c h f r o n t s e a t t o s w i t c h o n
a n d s e l e c t t h e s e l f - r e g u l a t e d l e v e l o f
heating:
1: Low.
2: M e d i u m .
3: High.
0: Off.
A f t e r r e c a l l i n g a m e m o r i s e d
p o s i t i o n fi v e t i m e s i n s u c c e s s i o n ,
t h e f u n c t i o n w i l l b e c a n c e l l e d u n t i l
t h e e n g i n e i s s t a r t e d .
Engine running
- Keep button 1 or 2 p r e s s e d d o w n
u n t i l t h e e n d o f s e t t i n g o f t h e
c o r r e s p o n d i n g m e m o r i s e d p o s i t i o n .
Engine off
- B r i e fl y p r e s s b u t t o n
1 or 2 to recall
t h e c o r r e s p o n d i n g m e m o r i s e d
position.
