2010 PEUGEOT 308 boot

FITTINGS
102
REAR ARMREST SKI FLAP
Opening

 Lower the rear armrest.

 Pull the fl ap handle downwards.

 Lower the fl ap.

 Load the objects from inside the
boot.

 Lower the rear armrest for a more
comfortable position.
The armrest incorporates two cup holders.
Comfort and storage device for the rear
passengers. Device for storing and transporting long
objects.
STORAGE UNDER THE REAR FOOTWELL
Depending on the confi guration, the
vehicle has storage compartments un-
der the footwell, located in front of the
rear seats. They can be accessed via
clipped fl aps with a handle
A .

FITTINGS
102
REAR ARMREST SKI FLAP
Opening

 Lower the rear armrest.

 Pull the fl ap handle downwards.

 Lower the fl ap.

 Load the objects from inside the
boot.

 Lower the rear armrest for a more
comfortable position.
The armrest incorporates two cup holders.
Comfort and storage device for the rear
passengers. Device for storing and transporting long
objects.
STORAGE UNDER THE REAR FOOTWELL
Depending on the confi guration, the
vehicle has storage compartments un-
der the footwell, located in front of the
rear seats. They can be accessed via
clipped fl aps with a handle
A .

FITTINGS
104
BOOT FITTINGS

1. Load space cover

2. Hooks

3. 12 V accessories socket (120 W)

4. Torch

5. Rear seats folding controls

6. Adjustable
boot
(3
position
fl oor )

7. Stowing rings on the fl oor

8. Luggage retaining net

9. Storage trays

FITTINGS
105
Rear parcel shelf To fold it:

 unhook the two cords,

 fold it concertina-style to the rear
seats.
To remove it:

 fold the rear parcel shelf as de-
scribed above,

 unclip the fi xings on the left and on
the right by pushing gently,

 place your hands as shown on the
illustration then pull the assembly
towards you, To store it at the bottom of the boot:

 remove the rear parcel shelf as de-
scribed above,

 place the fl oor at an angle,

 place the rear parcel shelf in its lo-
cation (recess marked A ), at bottom
of the boot,

 the rear parcel shelf will be protect-
ed if you place the fl oor in the inter-
mediate position.
This consists of three sections which
can be folded back on each other.
To put it back in place:

 take hold of the rear parcel shelf
with both hands then place it on its
support,

 unfold it to the boot pillars,

 hook the two cords,

 if necessary, press on the top of the
rear parcel shelf, on the left and on
the right, to engage the fi xings.

FITTINGS
When changing a wheel
The hooks permit easy access
to the spare wheel by retain-
ing the boot carpet by means of the
two cords.
The hooks permit the securing of
shopping bags.
Hooks

 In order to connect a 12 V accessory
(max power: 120 Watts), remove
the cap and connect the appropriate
adaptor.

 Turn the key to the ignition position.
12 V accessories socket Luggage retaining net
Hooked onto the stowing rings on the
movable boot fl oor, this enables you to
secure your luggage.
Observe the loads indicated on the side
of the boot, in accordance with the posi-
tion of the movable fl oor.
For safety reasons in case of sharp
braking, we recommend that heavy ob-
jects are placed on the fl oor as close as
possible to the back of the rear seats.

FITTINGS
107

 Raise the boot carpet, hooking the
two cords on the hooks, then gain
access to the storage box.
Depending on the confi guration, this
has areas for storing:
- a box of spare bulbs,
- a fi rst aid kit,
- a tyre repair kit,
- two warning triangles,
- ... Storage box CD changer
This holds up to 6 discs.
Access
- Place the fl oor in the low position.
- Remove the fl ap by turning its button.
- Pivot the changer towards you then change the discs, one by one.
- Put the changer back in its location.
- Close the fl ap correctly to prevent the changer from coming out of its
location while driving. The use of copied compact
discs may cause faults.
Insert circular compact discs only.

FITTINGS
108
Adjustable boot floor
This three position fl oor allows you to opti-mise the volume of the boot by means
of the guides placed on the sides:
- High position (50 kg max): the fl oor is level with the closed lower tail-
gate.
You can load objects while keeping an area protected and isolated.
- Intermediate position (100 kg max): the fl oor is level with the open lower
tailgate.
You obtain a fl at fl oor to the front seats when the rear seats are in the
retracted position.
- Low position (150 kg max): maxi- mum boot volume. To place and support the fl oor at an angle:

 From the high position, raise the
fl oor towards the load space cover.

 Do not hesitate to pass the two re-
tractable stops then place the fl oor
back on these two stops.
To change the height of the fl oor:

 Push the fl oor fully forwards then, with
the help of the support stops A , move
the fl oor to the position required. The fl oor is equipped with four stowing
rings to secure your luggage, observing
the loads indicated (in the boot).

FITTINGS
109
Torch
This is a removable lamp, incorporated
in the boot wall, which can be used to
light the boot or as a torch.
Operation
This torch operates with NiMH type re-
chargeable batteries.
It has a battery life of approximately
45 minutes and charges while you are
driving. Use

 Extract the torch from its location
pulling the side of the torch A .

 Press the switch, located on the
back, to switch the torch on or off.

 Unfold the support, located on the
back, to set down and raise the
torch; for example, when changing
a wheel.
Storing

 Put the torch back in place in its loca-
tion starting with the narrow part B .
If you have forgotten to switch off the torch, this switches it off auto-
matically. Rear side blinds
Fitted on the rear windows, these protect
your young children from the sun.

 Pull the blind by the central tab.

 Position the blind attachment on the
hook.
Observe the polarities when
fi tting the batteries.
Never replace the rechargeable batteries
with normal single-use batteries.
It the torch is not engaged cor-
rectly, it may not charge and
may not come on when the
boot is opened.
For the boot lighting function,
refer to the "Visibility - § Boot
lighting" section.
