9
INSTRUMENTS AND CONTROLS
1. Steering wheel adjustment control.
2. Cruise control/speed limiter
switches.
3. Lighting and direction indicators
control stalk.
4. Central adjustable air vents.
5. Head-up display.
6. Multifunction screen.
7. Passenger's airbag.
8. Side adjustable air vent.
9. Glove box - Audio/video sockets -
Passenger's airbag deactivation.
10. Storage compartment with net.
11. Grip control switch.
12. Bonnet release.
13. Grab handle.
14. Heating/air conditioning controls.
15. Audio and telematics system.
16. Buttons:
- head-up display,
- hazard warning lamps,
- Distance alert,
- central locking.
Page 13 of 315
MONITORING
Instrument panel
A. With the ignition on, the needle
should indicate the level of fuel re-
maining.
B. With the engine running, its associ-
ated low level warning light should
switch off.
C. With the ignition on, the oil level in-
dicator should display "OIL OK" for
a few seconds.
If the levels are not correct, top up the
levels which are low.
24
Warning lamps
1. With the ignition on, the orange and
red warning lamps come on.
2. With the engine running, these
warning lamps should switch off.
If warning lamps remain on, refer to the
page concerned.
26
Switch panels
Lighting of the indicator lamp indicates
the status of the corresponding function.
A. Interior volumetric
protection alarm. 76
155
120
79, 117
139
118
141
72
B. Visual and audible
parking sensors.
C. ESP OFF (without
Grip control).
D. Child lock
E. Head-up display.
F. Hazard warning
lamps.
G. Distance alert.
H. Central locking.
Lower
Central
Page 72 of 315
71
Unfolding the key
Unlocking the vehicle
Press the open padlock to
unlock the vehicle.
Complete unlocking using the
remote control
REMOTE CONTROL KEY
System which permits central unlock-
ing or locking of the vehicle using the
lock or from a distance. It is also used to
locate and start the vehicle, as well as
providing protection against theft. Complete unlocking using the key
Turn the key to the left in the driver's
door lock to unlock the vehicle.
U n l o c k i n g i s c o n fi r m e d b y r a p i d fl a s h i n g
of the direction indicators for approxi-
mately two seconds.
According to version, the door mirrors
unfold at the same time.
Selective unlocking using the
remote control
Selective unlocking using the key
Turn the key to the left in the driver's
door lock once to unlock the driver's
door only.
Turn the key to the left in the driver's
door lock again to unlock the other
d o o r s a n d t h e b o o t .
Press the open padlock
once to unlock the driver's
door only.
Press the open padlock again to un-
l o c k t h e o t h e r d o o r s a n d t h e b o o t . E a c h u n l o c k i n g i s c o n fi r m e d b y r a p i d
fl a s h i n g o f t h e d i r e c t i o n i n d i c a t o r s f o r
approximately two seconds.
According to version, the door mirrors
u n f o l d a t t h e s a m e t i m e a s t h e fi r s t u n -
locking action.
T h e s e l e c t i v e u n l o c k i n g i s o n l y a v a i l a b l e
o n v e r s i o n s fi t t e d w i t h d e a d l o c k i n g .
The complete or selective
unlocking parameter is set
via the multifunction screen
c o n fi g u r a t i o n m e n u .
C o m p l e t e u n l o c k i n g i s a c t i v a t e d b y d e f a u l t .
F i r s t p r e s s t h i s b u t t o n t o
unfold the key.
Page 73 of 315
72
Locating your vehicle
Press the closed padlock to locate
your locked vehicle in a car park.
T h i s i s i n d i c a t e d b y l i g h t i n g o f t h e d i r e c -
tion indicators for a few seconds. Deadlocking renders the exte-
rior and interior door controls
inoperative.
It also deactivates the manual central
c o n t r o l b u t t o n .
Therefore, never leave anyone inside
the vehicle when it is deadlocked.
Deadlocking using the remote
control
Deadlocking using the key
Folding the key
Press the closed padlock
to lock the vehicle com-
pletely or press the closed
padlock for more than two
seconds to close the win-
dows automatically in ad-
dition to locking (according
to version).
Press the closed padlock again
w i t h i n fi v e s e c o n d s t o d e a d l o c k t h e
vehicle.
I f o n e o f t h e d o o r s o r t h e b o o t
is still open, the central locking
does not take place.
When the vehicle is locked, if it is
unlocked inadvertently, it will relock
automatically after thirty seconds un-
less a door is opened.
Normal locking using the key
Turn the key to the right in the driver's
door lock to lock the vehicle completely.
L o c k i n g i s c o n fi r m e d b y fi x e d l i g h t i n g o f
the direction indicators for approximately
two seconds.
According to version, the door mirrors
fold at the same time.
The folding and unfolding of
the door mirrors using the re-
m o t e c o n t r o l c a n b e d e a c t i v a -
t e d b y a P E U G E O T d e a l e r .
Locking the vehicle
Press the closed padlock
to lock the vehicle com-
pletely.
Press the closed padlock for more
than two seconds to close the win-
dows automatically in addition to
locking (according to version).
Normal locking using the remote
control
Turn the key to the right in the
driver's door lock to lock the vehicle
completely and hold it in this posi-
tion for more than two seconds to
close the windows automatically in
addition to locking (according to ver-
sion).
Turn the key to the right again within
fi v e s e c o n d s t o d e a d l o c k t h e v e h i c l e .
D e a d l o c k i n g i s c o n fi r m e d b y fi x e d l i g h t -
ing of the direction indicators for ap-
proximately two seconds.
According to version, the door mirrors
fold at the same time.
F i r s t p r e s s t h i s b u t t o n t o
fold the key.
Page 78 of 315
76
ALARM
System which protects and provides a
deterrent against the theft of your vehi-
cle. It provides two types of protection,
exterior and interior, as well as an anti-
tamper function.
Locking the vehicle with full alarm
D o n o t m a k e a n y m o d i fi c a -
tions to the alarm system, this
could cause malfunctions. T o b e e f f e c t i v e , t h i s d e a c t i v a t i o n
m u s t b e c a r r i e d o u t e a c h t i m e
the ignition is switched off.
Reactivation of the interior
volumetric protection
Unlock the vehicle using the unlock-
i n g b u t t o n o n t h e r e m o t e c o n t r o l .
Relock the vehicle using the remote
control.
T h e a l a r m i s a c t i v a t e d a g a i n w i t h b o t h
types of protection; the indicator lamp
o n b u t t o n A switches off.
Locking the vehicle with exterior protection alarm only
Activation
Switch off the ignition and get out of
the vehicle.
Lock or deadlock the vehicle using
t h e l o c k i n g b u t t o n o n t h e r e m o t e
control.
The alarm is activated; the indicator lamp
o n b u t t o n A fl a s h e s o n c e p e r s e c o n d .
Exterior perimiter protection
The system detects opening of the
vehicle.
The alarm is triggered if anyone tries to
e n t e r t h e v e h i c l e b y f o r c i n g a d o o r , t h e
b o o t o r t h e b o n n e t .
Interior volumetric protection
The system detects any variation in the
volume in the passenger compartment.
T h e a l a r m i s t r i g g e r e d i f a n y o n e b r e a k s
a window or moves inside the vehicle.
If you wish to leave a pet in the vehicle
or a window partially open, deactivate
the interior volumetric protection.
Anti-tamper function
The system detects the putting out of
service of its components.
The alarm is triggered if anyone tries
to put the wires of the siren, the central
c o n t r o l o r t h e b a t t e r y o u t o f s e r v i c e . Deactivation
Unlock the vehicle using the unlock-
i n g b u t t o n o n t h e r e m o t e c o n t r o l .
The alarm is deactivated; the indicator
l a m p o n b u t t o n A switches off. Deactivation of the interior
volumetric protection
Switch off the ignition.
W i t h i n t e n s e c o n d s , p r e s s b u t t o n A
until the indicator lamp is lit continu-
ously.
G e t o u t o f t h e v e h i c l e .
Lock or deadlock the vehicle using
t h e l o c k i n g b u t t o n o n t h e r e m o t e
control.
The exterior protection alarm alone re-
mains activated; the indicator lamp on
b u t t o n A fl a s h e s o n c e p e r s e c o n d .
Page 83 of 315
81
If the vehicle is locked or
deadlocked from the outside,
t h e r e d i n d i c a t o r l a m p fl a s h e s
a n d b u t t o n A is inactive.
In this case, use the remote control
or the key to unlock the vehicle. A c o n fi r m a t i o n m e s s a g e a p -
pears on the multifunction
s c r e e n , a c c o m p a n i e d b y a n
a u d i b l e s i g n a l . Manual centralised control
System which provides full manual
locking or unlocking of the doors from
the inside.
Locking
P r e s s b u t t o n A to lock the vehicle.
T h e r e d i n d i c a t o r l a m p o n t h e b u t t o n
comes on.
Automatic centralised control
System which provides full automatic
locking or unlocking of the doors and
b o o t w h i l e d r i v i n g , i f t h e y a r e c l o s e d
correctly.
You can activate or deactivate this function.
Locking
When the speed exceeds 6 mph
( 1 0 k m / h ) , t h e d o o r s a n d b o o t l o c k a u -
tomatically.
If one of the doors is open, the automat-
ic central locking does not take place.
I f t h e b o o t i s o p e n , t h e a u t o m a t i c c e n -
tral locking of the doors is active.
Deactivation
P r e s s b u t t o n A again for more than
two seconds.
A c o n fi r m a t i o n m e s s a g e a p p e a r s o n t h e
m u l t i f u n c t i o n s c r e e n , a c c o m p a n i e d b y
a n a u d i b l e s i g n a l .
If one of the doors is open, the
central locking from the inside
does not take place.
Unlocking
P r e s s b u t t o n A again to unlock the
vehicle.
T h e r e d i n d i c a t o r l a m p o n t h e b u t t o n
switches off. Activation
In the event of an impact, the
doors unlock automatically.
Unlocking
A b o v e 6 m p h ( 1 0 k m / h ) , p r e s s b u t -
ton A t o u n l o c k t h e d o o r s a n d b o o t
temporarily.
P r e s s b u t t o n A for more than
two seconds.
Page 136 of 315
CHILD SAFETY
117
This system is independent
and in no circumstances does
it take the place of the central
locking control.
C h e c k t h e s t a t u s o f t h e c h i l d l o c k
each time you switch on the ignition.
Always remove the key from the igni-
tion when leaving the vehicle, even
for a short time.
In the event of a serious impact,
the electric child lock is deactivated
automatically to permit the exit of
the rear passengers.
MANUAL CHILD LOCK
M e c h a n i c a l s y s t e m t o p r e v e n t o p e n i n g
of the rear door using its interior control.
The control is located on the edge of
each rear door.
Turn the red control one eighth of
a turn to the left using the ignition
key.
ELECTRIC CHILD LOCK
R e m o t e c o n t r o l s y s t e m t o p r e v e n t o p e n i n g
of the rear doors using their interior con-
trols and use of the rear electric windows.
With the ignition on, press button A .
The indicator lamp on button A comes
on.
This indicator lamp remains on until the
child lock is deactivated.
It is still possible to open the doors from
the outside and operate the rear electric
windows from the driver's control pad.
Locking
Unlocking
Turn the red control one eighth of
a turn to the right using the ignition
key. Activation
Deactivation
With the ignition on, press button A
again.
The indicator lamp on button A switches
off.
This indicator lamp remains off until the
child lock is activated.
Any other status of the indica-
tor lamp indicates a malfunction
of the electric child lock. Have
it checked by a PEUGEOT
dealer.
