56
The air conditioning system
does not contain chlorine and
does not present any danger
to the ozone layer. RECOMMENDATIONS FOR VENTILATION AND AIR CONDITIONING
In order for these systems to be fully effective, follow the operation and
maintenance guidelines below:
If the interior temperature remains very high aft er the vehicle has been parked
i n t h e s u n f o r a c o n s i d e r a b l e t i m e , fi r s t v e n t i l a t e t h e p a s s e n g e r c o m p a r t m e n t
for a few minutes.
P l a c e t h e a i r fl o w c o n t r o l a t a s u f fi c i e n t l e v e l t o p r o v i d e a n a d e q u a t e r e n e w a l
of air in the passenger compartment.
To obtain an even air distribution, take care not to obst ruct the exterior air
intake grilles located at the base of the windscreen, the n ozzles, the vents
and the air outlets, as well as the air extractor located in the boot.
Use in preference the intake of exterior air as prolonged use of the air recir-
culation may cause misting of the windows and side windows.
Do not cover the sunshine sensor, located on the dashboard; this is used for
regulation of the automatic air conditioning system.
Operate the air conditioning system for 5 to 10 minutes, on ce or twice a
month to keep it in perfect working order.
E n s u r e t h a t t h e p a s s e n g e r c o m p a r t m e n t fi l t e r i s i n g o o d c o n d i t i o n a n d h a v e
t h e fi l t e r e l e m e n t s r e p l a c e d r e g u l a r l y ( r e f e r t o t h e " C h e c k s " s e c t i o n ) .
W e r e c o m m e n d t h e u s e o f a c o m b i n e d p a s s e n g e r c o m p a r t m e n t fi l t e r . T h a n k s
t o i t s s e c o n d s p e c i a l a c t i v e fi l t e r , i t c o n t r i b u t e s t o t h e p u r i fi c a t i o n o f t h e a i r
breathed by the occupants and the cleanliness of the passenge r compart-
m e n t ( r e d u c t i o n o f a l l e r g i c s y m p t o m s , b a d o d o u r s a n d g r e a s y d e p o s i t s ) .
To ensure correct operation of the air conditioning system, you are also ad-
vised to have it checked regularly.
If the system does not produce cold air, do not use it and contact a PEUGEOT
dealer.
When towing the maximum load on a steep gradient in high temperatures,
switching off the air conditioning saves engine power and i mproves towing ca-
pacity.
The condensation created by the air conditioning results in a discharge of water
under the vehicle which is perfectly normal.
Page 67 of 315
66
F o l d i n g t h e s e a t f r o m t h e b o o t
E a c h s e c t i o n o f t h e b e n c h s e a t ( 1 / 3 o r
2 / 3 ) h a s i t s o w n c o n t r o l t o r e l e a s e t h e
seat back and its seat cushion from the
boot.
Check that nothing is preventing
t h e s e a t b a c k f r o m f o l d i n g ( h e a d r e -
s t r a i n t , s e a t b e l t s , . . . ) ,
check also that no object on or under
the seat could hinder its movement,
pull the control from the boot.
REAR SEATS
Never drive with rear passen-
gers when the head restraints
are removed; the head re-
straints must be in place and in the
high position.
R e a r h e a d r e s t r a i n t s
T h e s e h a v e a h i g h p o s i t i o n ( c o m f o r t a n d
s a f e t y ) a n d a l o w p o s i t i o n ( r e a r v i s i b i l i t y ) .
They can also be removed.
To remove a head restraint:
pull the head restraint fully upwards,
then, press the lug A .
B e n c h s e a t t h e l e f t - h a n d ( 2 / 3 ) o r r i g h t -
h a n d ( 1 / 3 ) s e c t i o n o f w h i c h c a n b e f o l -
ded to adapt the boot load space.
Page 84 of 315
82
Emergency control
System which locks or unlocks the
doors mechanically in the event of a
m a l f u n c t i o n o f t h e b a t t e r y o r o f t h e c e n -
tral locking.
Insert the key in the lock, located on
the edge of the door, then turn it one
eighth of a turn .
Locking the driver's door
Insert the key in the lock, then turn it
to the right.
Unlocking the driver's door
Insert the key in the lock, then turn it
to the left.
Locking the front and rear
passenger doors
Unlocking the front and rear
passenger doors
Pull the interior door opening control.
Opening
After unlocking the vehicle using the
remote control or the key, press the
handle A and raise the tailgate.
BOOT
Closing
Close the lower tailgate.
Pull the handle B downwards to
guide the tailgate.
Page 85 of 315
82
Emergency control
System which locks or unlocks the
doors mechanically in the event of a
m a l f u n c t i o n o f t h e b a t t e r y o r o f t h e c e n -
tral locking.
Insert the key in the lock, located on
the edge of the door, then turn it one
eighth of a turn .
Locking the driver's door
Insert the key in the lock, then turn it
to the right.
Unlocking the driver's door
Insert the key in the lock, then turn it
to the left.
Locking the front and rear
passenger doors
Unlocking the front and rear
passenger doors
Pull the interior door opening control.
Opening
After unlocking the vehicle using the
remote control or the key, press the
handle A and raise the tailgate.
BOOT
Closing
Close the lower tailgate.
Pull the handle B downwards to
guide the tailgate.
Page 97 of 315
92
Windscreen and headlamp wash
B. rear wiper selection ring:
park,
intermittent wipe,
w a s h - w i p e ( s e t d u r a t i o n ) .
Reverse gear
When reverse gear is engaged, the
rear wiper will come into operation if the
windscreen wipers are operating.
Programming
Pull the windscreen wiper stalk to-
wards you. The windscreen wash
then the windscreen wipers operate
f o r a fi x e d p e r i o d .
The headlamp washers only operate
when the dipped
beam
headlamps
are on .
Rear wiper
I f a s i g n i fi c a n t a c c u m u l a t i o n
of snow or ice is present, or
when using a bicycle carrier
on the boot, deactivate the auto-
matic rear wiper via the multifunction
s c r e e n c o n fi g u r a t i o n m e n u . The function is activated or
deactivated via the multi-
f u n c t i o n s c r e e n c o n fi g u r a -
tion menu.
This function is activated
by default.
Screenwash/headlamp wash low
I n t h e c a s e o f v e h i c l e s fi t t e d w i t h
headlamp washers, when the
minimum level of the reservoir
is reached, this warning lamp is
displayed on the instrument panel, ac-
companied by an audible signal and a
message on the multifunction screen.
N e x t t i m e y o u s t o p , fi l l t h e s c r e e n w a s h /
headlamp wash reservoir.
The warning lamp is displayed when
the ignition is switched on, or every time
the stalk is operated, until the reservoir
i s fi l l e d .
Page 102 of 315
96
Different lighting times are
available:
This comes on automatically when the
boot is opened and switches off auto-
matically when the boot is closed.
BOOT LAMP TORCH
P o r t a b l e l a m p , fi t t e d i n t h e b o o t w a l l ,
which can be used to light the boot or
as a torch.
Operation
O n c e e n g a g e d fi r m l y i n i t s l o c a t i o n , i t
comes on automatically when the boot
is opened and switches off automati-
cally when the boot is closed.
It operates with NiMH type recharge-
able batteries.
It has a battery life of approximately
45 minutes and recharges while you are
driving.
O b s e r v e t h e p o l a r i t i e s w h e n fi t -
ting the rechargeable batteries.
Never replace the rechargeable batte-
ries with normal single-use batteries. For the torch function, refer to
the "Fittings - § Torch" section.
The soft lighting provided by the foot-
well lamps improves visibility in the ve-
hicle when the light is poor.
Activation
Its operation is identical to that of the
courtesy lamps. The lighting comes on
when one of the doors is opened.
- when the ignition is off, approxi-mately ten minutes,
- in energy economy mode, approxi- mately thirty seconds,
- when the engine is running, no limit.
Page 103 of 315
96
Different lighting times are
available:
This comes on automatically when the
boot is opened and switches off auto-
matically when the boot is closed.
BOOT LAMP TORCH
P o r t a b l e l a m p , fi t t e d i n t h e b o o t w a l l ,
which can be used to light the boot or
as a torch.
Operation
O n c e e n g a g e d fi r m l y i n i t s l o c a t i o n , i t
comes on automatically when the boot
is opened and switches off automati-
cally when the boot is closed.
It operates with NiMH type recharge-
able batteries.
It has a battery life of approximately
45 minutes and recharges while you are
driving.
O b s e r v e t h e p o l a r i t i e s w h e n fi t -
ting the rechargeable batteries.
Never replace the rechargeable batte-
ries with normal single-use batteries. For the torch function, refer to
the "Fittings - § Torch" section.
The soft lighting provided by the foot-
well lamps improves visibility in the ve-
hicle when the light is poor.
Activation
Its operation is identical to that of the
courtesy lamps. The lighting comes on
when one of the doors is opened.
- when the ignition is off, approxi-mately ten minutes,
- in energy economy mode, approxi- mately thirty seconds,
- when the engine is running, no limit.
Page 104 of 315
FITTINGS
109
Torch
This is a removable lamp, incorporated
in the boot wall, which can be used to
light the boot or as a torch.
Operation
This torch operates with NiMH type re-
chargeable batteries.
It has a battery life of approximately
45 minutes and charges while you are
driving. Use
Extract the torch from its location
pulling the side of the torch A .
Press the switch, located on the
back, to switch the torch on or off.
Unfold the support, located on the
back, to set down and raise the
t o r c h ; f o r e x a m p l e , w h e n c h a n g i n g
a wheel.
Storing
Put the torch back in place in its loca-
tion starting with the narrow part B .
If you have forgotten to switch off the torch, this switches it off auto-
matically. Rear side blinds
Fitted on the rear windows, these protect
your young children from the sun.
Pull the blind by the central tab.
Position the blind attachment on the
hook.
Observe the polarities when
fi t t i n g t h e b a t t e r i e s .
Never replace the rechargeable batteries
with normal single-use batteries.
It the torch is not engaged cor-
rectly, it may not charge and
may not come on when the
boot is opened.
For the boot lighting function,
refer to the "Visibility - § Boot
lighting" section.
