2010 NISSAN TIIDA headrest

SE-16
< SERVICE INFORMATION >
REAR SEAT
Removal and Installation
INFOID:0000000005396873
CAUTION:
When removing and in stalling, use shop cloths to protect parts from damage.
60:40 SPLIT FOLD DOWN SEAT - HATCHBACK
Removal
1. Pull seat cushion up, and then remove the seat cushion from the
seat cushion hook.
2. Remove the center seatbelt anchor bolt (A) from under the seat.
3. Remove the seatback mounting bolts from the right rear seat back brackets.
CAUTION:
Tighten seatback mounting bolts in the order as shown.
7. Headrest 8. Headrest holder (free)9. Headrest holder (locked)
10. Striker cover 11. Seatback trim12. Seatback pad
13. Rear seatback lock knob 14. Rear seat lock assembly15. Seatback frame
16. Rear seatback center bracket 17. Rear seatback side bracket 18. Rear seat striker
19. Seat cushion hook 20. Center seat belt assembly
PIIB4085J
WIIA1234E
WIIA1287E
Revision: January 20102010 Versa

REAR SEATSE-19
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
SE
N
O P
Assembly of Armrest
Assembly is in the reverse order of disassembly.
Disassembly of Seatback Trim and Pad
1. Remove the headrest.
2. Remove the retainer under the back of seatback.
3. Remove the clips, and then remove the striker cover.
4. Remove the headrest holder.
5. To remove armrest, refer to "Disassembly of Armrest " .
6. Remove the seatback trim.
7. Remove the bolts, and then remove the rear seat lock assembly.
8. Remove the seatback pad from the seatback frame.
9. Remove the seatback center bracket
bolt and then remove the seatback frame.
PIIB2486J
PIIB2485J
PIIB4084J
PIIB2487J
Revision: January 20102010 Versa

SE-20
< SERVICE INFORMATION >
REAR SEAT
Assembly of Seatback Trim and Pad
Assembly is in the reverse order of disassembly.
• Before installing headrest holder, check its orientation (front/rear and right/left).
Disassembly of Seat Cushion Trim and Pad
Remove the rings to separate the trim and pad.
Assembly of Seat Cushion Trim and Pad
Assembly is in the reverse order of disassembly.
Revision: January 20102010 Versa

REAR SEATSE-21
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
SE
N
O P
Component Parts DrawingINFOID:0000000005396875
60:40 SPLIT FOLD DOWN SEAT - SEDAN
WBIA0849E
1. Seat cushion trim 2. Seat cushion pad3. Seatback side
4. Armrest 5. Rear seat bushing6. Armrest hinge cover
7. Headrest 8. Headrest holder (free)9. Headrest holder (locked)
10. Striker cover 11. Seatback trim12. Seatback pad
Revision: January 20102010 Versa

REAR SEATSE-25
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
SE
N
O P
Disassembly of Seatback Trim and Pad
1. Remove the headrest.
2. Remove the retainer under the back of seatback.
3. Remove the clips, and then remove the striker cover.
4. Remove the headrest holder.
5. To remove armrest, refer to "Disassembly of Armrest " .
6. Remove the seatback trim.
7. Remove the bolts, and then remove the rear seat lock assembly.
8. Remove the seatback pad from the seatback frame.
9. Remove the seatback center bracket
bolt and then remove the seatback frame.
Assembly of Seatback Trim and Pad
Assembly is in the reverse order of disassembly.
• Before installing headrest holder, check its orientation (front/rear and right/left).
PIIB2486J
PIIB2485J
PIIB4084J
PIIB2487J
