2010 NISSAN LATIO sensor

EC-492
< PRECAUTION >[HR16DE]
PRECAUTIONS
•
After performing each TROUBLE DIAGNOSIS, perform DTC
CONFIRMATION PROCEDURE or Component Function
Check. The DTC should not be displayed in the DTC Confir-
mation Procedure if the repair is completed. The Component
Function Check should be a good result if the repair is com-
pleted.
• When measuring ECM signals with a circuit tester, never allow
the two tester probes to contact.
Accidental contact of probes will cause a short circuit and
damage the ECM power transistor.
• Do not use ECM ground terminals when measuring input/out-
put voltage. Doing so may result in damage to the ECM’s tran-
sistor. Use a ground other than ECM terminals, such as the
ground.
• Do not operate fuel pump when there is no fuel in lines.
• Tighten fuel hose clamps to the specified torque.
- Fuel level sensor unit and fuel pump (1)
- Fuel pressure regulator (2)
- Fuel level sensor (3)
- Fuel tank temperature sensor (4)
SEF217U
SEF348N
BBIA0704E
Revision: January 20102010 Versa

PREPARATIONEC-495
< PREPARATION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Fuel filler cap adapter
i.e.: (MLR-8382)
Checks fuel tank vacuum relief valve opening
pressure
Socket wrench Removes and installs engine coolant temperature
sensor
Oxygen sensor thread
cleaner
i.e.: (J-43897-18)
(J-43897-12) Reconditions the exhaust system threads before
installing a new oxygen sensor. Use with anti-
seize lubricant shown below.
a: 18 mm diameter with pitch 1.5 mm for Zirco-
nia Oxygen Sensor
b: 12 mm diameter with pitch 1.25 mm for Tita-
nia Oxygen Sensor
Anti-seize lubricant
i.e.: (Permatex
TM
133AR or equivalent
meeting MIL specifica-
tion MIL-A-907) Lubricates oxygen sensor thread cleaning tool
when reconditioning exhaust system threads.
Tool name
(Kent-Moore No.)
Description
S-NT815
S-NT705
AEM488
S-NT779
Revision: January 20102010 Versa

EC-500
< ON-VEHICLE REPAIR >[HR16DE]
EVAP CANISTER
ON-VEHICLE REPAIR
EVAP CANISTER
Exploded ViewINFOID:0000000005398652
Removal and InstallationINFOID:0000000005398653
EVAP CANISTER
Removal
1. Remove EVAP canister protector.
2. Disconnect the EVAP control pressure sensor connector.
3. Remove the EVAP control pressure sensor and O-ring, if necessary.
4. Disconnect EVAP canister purge hose.
5. Remove the EVAP canister retaining bolt.
6. Disconnect fuel tank EVAP breather hose.
7. Disconnect EVAP vent control valve connector.
8. Disconnect the EVAP vent control valve hose.
9. Remove the EVAP canister.
10. Remove the EVAP vent control valve and O-ring, if necessary.
Installation
Installation is in the reverse order of removal.
CAUTION:
Always replace O-rings with a new one.
EVAP CANISTER CONTROL PRESSURE SENSOR
Removal
1. Remove EVAP canister protector.
2. Disconnect the EVAP control pressure sensor connector.
3. Remove the EVAP canister control pressure sensor and O-ring.
Installation
Installation is in the reverse order of removal.
CAUTION:
Always replace O-ring with a new one.
EVAP CANISTER VENT CONTROL VALVE
PBIB1214E
Revision: January 20102010 Versa

EC-502
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Idle SpeedINFOID:0000000005398655
*: Under the following conditions
• A/C switch: OFF
• Electric load: OFF (Lights, heater fan & rear window defogger)
• Steering wheel: Kept in straight-ahead position
Ignition TimingINFOID:0000000005398656
*: Under the following conditions
• A/C switch: OFF
• Electric load: OFF (Lights, heater fan & rear window defogger)
• Steering wheel: Kept in straight-ahead position
Calculated Load ValueINFOID:0000000005398657
Mass Air Flow SensorINFOID:0000000005398658
*: Engine is warmed up to normal operating temperature and running under no load.Transmission
ConditionSpecification
A/T No load* (in P or N position) 700 ± 50 rpm
M/T No load* (in Neutral position) 650 ± 50 rpm
Transmission ConditionSpecification
A/T No load* (in P or N position) 6 ± 5 °BTDC
M/T No load* (in Neutral position) 6 ± 5 °BTDC
Condition Specification (Using CONSULT-III or GST)
At idle 10 – 35 %
At 2,500 rpm 10 – 35 %
Supply voltageBattery voltage (11 – 14 V)
Output voltage at idle 0.9 – 1.3V*
Mass air flow (Using CONSULT-III or GST) 1.0 – 4.0 g·m/sec at idle*
2.0 – 10.0 g·m/sec at 2,500 rpm*
Revision: January 20102010 Versa

INDEX FOR DTCEC-503
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
SERVICE INFORMATION
INDEX FOR DTC
U0101-U1001INFOID:0000000005532361
*1: 1st trip DTC No. is
the same as DTC No.
*2: This number is prescri bed by SAE J2012/ISO 15031-6.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
*4: The troubleshooting for this DTC needs CONSULT-III.
P0011-P0075INFOID:0000000005532362
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescri bed by SAE J2012/ISO 15031-6.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
P0101-P0128INFOID:0000000005532363
DTC*1
Items
(CONSULT-III screen terms) Reference
CONSULT-III
GST*
2ECM*3
U0101 0101*4LOST COMM (TCM) EC-639
U0140
0140*4LOST COMM (BCM) EC-641
U1001
1001*4CAN COMM CIRCUIT EC-643
DTC*1
Items
(CONSULT-III screen terms) Reference
CONSULT-III
GST*
2ECM*3
P0011 0011 INT/V TIM CONT-B1 EC-645
P00310031 A/F SEN1 HTR (B1) EC-649
P00320032 A/F SEN1 HTR (B1) EC-649
P00370037 HO2S2 HTR (B1) EC-654
P00380038 HO2S2 HTR (B1) EC-654
P00750075 INT/V TIM V/CIR-B1 EC-659
DTC*1
Items
(CONSULT-III screen terms) Reference
CONSULT-III
GST*
2ECM*3
P0101 0101 MAF SEN/CIRCUIT-B1 EC-664
P01020102 MAF SEN/CIRCUIT-B1 EC-672
P01030103 MAF SEN/CIRCUIT-B1 EC-672
P01120112 IAT SEN/CIRCUIT-B1 EC-679
P01130113 IAT SEN/CIRCUIT-B1 EC-679
P01160116 ECT SEN/CIRC EC-683
P01170117 ECT SEN/CIRC EC-683
P01180118 ECT SEN/CIRC EC-683
P01220122 TP SEN 2/CIRC-B1 EC-691
P01230123 TP SEN 2/CIRC-B1 EC-691
P01250125 ECT SENSOR EC-696
Revision: January 20102010 Versa

EC-504
< SERVICE INFORMATION >[MR18DE]
INDEX FOR DTC
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012/ISO 15031-6.
*3: In Diagnostic Test
Mode II (Self-diagnostic results), this number is controlled by NISSAN.
P0130-P0183INFOID:0000000005532364
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012/ISO 15031-6.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
P0222-P0420INFOID:0000000005532365
P0127 0127 IAT SENSOR-B1 EC-699
P01280128 THERMSTAT FNCTN EC-702
DTC*1
Items
(CONSULT-III screen terms) Reference
CONSULT-III
GST*
2ECM*3
DTC*1 Items
(CONSULT-III screen terms) Reference
CONSULT-III
GST*
2ECM*3
P0130 0130 A/F SENSOR1 (B1) EC-704
P01310131 A/F SENSOR1 (B1) EC-710
P01320132 A/F SENSOR1 (B1) EC-716
P01370137 HO2S2 (B1) EC-722
P01380138 HO2S2 (B1) EC-731
P01390139 HO2S2 (B1) EC-741
P014C014C A/F SENSOR1 (B1) EC-750
P014D014D A/F SENSOR1 (B1) EC-750
P015A015A A/F SENSOR1 (B1) EC-750
P015B015B A/F SENSOR1 (B1) EC-750
P01710171 FUEL SYS-LEAN-B1 EC-758
P01720172 FUEL SYS-RICH-B1 EC-764
P01810181 FTT SENSOR EC-770
P01820182 FTT SEN/CIRCUIT EC-774
P01830183 FTT SEN/CIRCUIT EC-774
DTC*1
Items
(CONSULT-III screen terms) Reference
CONSULT-III
GST*
2ECM*3
P0222 0222 TP SEN 1/CIRC-B1 EC-778
P02230223 TP SEN 1/CIRC-B1 EC-778
P03000300 MULTI CYL MISFIRE EC-783
P03010301 CYL 1 MISFIRE EC-783
P03020302 CYL 2 MISFIRE EC-783
P03030303 CYL 3 MISFIRE EC-783
P03040304 CYL 4 MISFIRE EC-783
P03270327 KNOCK SEN/CIRC-B1 EC-789
P03280328 KNOCK SEN/CIRC-B1 EC-789
Revision: January 20102010 Versa

INDEX FOR DTCEC-505
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
*1: 1st trip DTC No. is
the same as DTC No.
*2: This number is prescri bed by SAE J2012/ISO 15031-6.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
P0441-P0463INFOID:0000000005532366
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescri bed by SAE J2012/ISO 15031-6.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
P0500-P0643INFOID:0000000005532367
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescri bed by SAE J2012/ISO 15031-6.
P0335 0335 CKP
SEN/CIRCUIT EC-793
P03400340 CMP SEN/CIRC-B1 EC-799
P04200420 TW CATALYST SYS-B1 EC-805
DTC*1
Items
(CONSULT-III screen terms) Reference
CONSULT-III
GST*
2ECM*3
DTC*1 Items
(CONSULT-III screen terms) Reference
CONSULT-III
GST*
2ECM*3
P0441 0441 EVAP PURG FLOW/MON EC-810
P04420442 EVAP SMALL LEAK EC-815
P04430443 PURG VOLUME CONT/V EC-822
P04440444 PURG VOLUME CONT/V EC-830
P04450445 PURG VOLUME CONT/V EC-830
P04470447 VENT CONTROL VALVE EC-836
P04480448 VENT CONTROL VALVE EC-842
P04510451 EVAP SYS PRES SEN EC-848
P04520452 EVAP SYS PRES SEN EC-851
P04530453 EVAP SYS PRES SEN EC-858
P04550455 EVAP GROSS LEAK EC-866
P04560456 EVAP VERY SML LEAK EC-873
P04600460 FUEL LEV SEN SLOSH EC-881
P04610461 FUEL LEVEL SENSOR EC-883
P04620462 FUEL LEVL SEN/CIRC EC-885
P04630463 FUEL LEVL SEN/CIRC EC-885
DTC*1
Items
(CONSULT-III screen terms) Reference
CONSULT-III
GST*
2ECM*3
P0500 0500 VEH SPEED SEN/CIRC EC-887
P05060506 ISC SYSTEM EC-889
P05070507 ISC SYSTEM EC-891
P06050605 ECM EC-893
P06070607 ECM EC-895
P06430643 SENSOR POWER/CIRC EC-896
Revision: January 20102010 Versa

EC-506
< SERVICE INFORMATION >[MR18DE]
INDEX FOR DTC
*3: In Diagnostic Test
Mode II (Self-diagnostic results), this number is controlled by NISSAN.
P0705-P0734INFOID:0000000005532368
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012/ISO 15031-6.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
*3: When erasing this DTC, al ways use CONSULT-III or GST.
P0740-P0840INFOID:0000000005532369
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012/ISO 15031-6.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
DTC*1
Items
(CONSULT-III screen terms) Reference
CONSULT-III
GST*
2ECM*3
P0705 0705 T/M RANGE SENSOR A AT- 9 0 (A/T)
CVT-62
(CVT)
P0710 0710
FLUID TEMP SENSOR A*
4AT- 9 5 (A/T)
CVT-67
(CVT)
P0715 0715 INPUT SPEED SENSOR AC CVT-72
P07200720 OUTPUT SPEED SENSOR AT- 1 0 0 (A/T)
CVT-76
(CVT)
P0725 0725 ENGINE SPEED AT- 1 0 5
P07310731
1GR INCORRECT RATIO*4AT- 1 0 9
P0732 0732
2GR INCORRECT RATIO*4AT- 11 2
P0733 0733
3GR INCORRECT RATIO*4AT- 11 5
P0734 0734
4GR INCORRECT RATIO*4AT- 11 8
DTC*1
Items
(CONSULT-III screen terms) Reference
CONSULT-III
GST*
2ECM*3
P0740 0740 TORQUE CONVERTERC AT- 1 2 3 (A/T)
CVT-84
(CVT)
P0744 0744 TORQUE CONVERTER AT- 1 2 8
(A/T)
CVT-89
(CVT)
P0745 0745 PC SOLENOID A AT- 1 3 3
(A/T)
CVT-91
(CVT)
P0746 0746 PC SOLENOID A CVT-96
P07500750 SHIFT SOLENOID A AT- 1 3 8
P07550755 SHIFT SOLENOID B AT- 1 4 3
P07760776 PC SOLENOID B CVT-98
P07780778 PC SOLENOID B CVT-100
P08400840 FLUID PRESS SEN/SW A CVT-105
Revision: January 20102010 Versa
