SYSTEM DESCRIPTION
TCS Function
INFOID:0000000005612145
• Spinning of the drive wheels is detected by the A BS/TCS/VDC control unit using inputs from the wheel
speed sensors. If wheel spin occurs, the drive wheel right and left brake fluid pressure control and engine
fuel cut are conducted while the throttle value is restricted to reduce the engine torque and decrease the
amount of wheel spin. In addition, the throttle openi ng is controlled to achieve the optimum engine torque.
• Depending on road condition, the vehicle may have a sluggish feel. This is normal, because optimum trac- tion has the highest priority during TCS operation.
• TCS may be activated during sudden vehicle acceleration, wide open throttle acceleration, sudden transmis- sion shifts or when the vehicle is driven on a road with a varying surface friction coefficient.
• The SLIP indicator lamp flashes to inform the driver of TCS operation.
VDC FunctionINFOID:0000000005612146
• In addition to the ABS/TCS function, the driver steering amount and brake operation amount are detected
from the steering angle sensor, and the vehicle's drivi ng status (amount of under steering/over steering) is
determined using inputs from the yaw rate/side/decel G sensor, wheel speed sensors, etc. and this informa-
tion is used to improve vehicle stability by cont rolling the braking and engine torque application to the
wheels.
• The SLIP indicator lamp flashes to inform the driver of VDC operation.
• During VDC operation, the vehicle body and brake pedal may vibrate lightly and a mechanical noise may be
heard. This is normal.
• The ABS warning lamp, VDC OFF indicator lamp and SLIP indicator lamp may turn on when the vehicle is
subject to strong shaking or large vibration, such as when the vehicle is on a turn table or a ship while the
engine is running or steep slope. In this case, rest art the engine on a normal road and if the ABS warning
lamp, VDC OFF indicator lamp and SLIP indicator lamp turn off, there is no problem.
Wheel SensorsINFOID:0000000005612147
The front sensor units consist of a gear-shaped sensor rotor and a
sensor element. The element contains a magnet around which a coil
is wound. The front wheel sensors are installed on the front of the
wheel knuckles. As the wheel rotates, the sensor generates a
square-wave signal. The frequency in creases as the wheel speed
increases.
The rear sensor units consist of w heel hubs with a series of internal
magnets and a sensor element. The rear wheel sensors are installed
on the inner side of the wheel knuckles. As the wheel rotates, the
sensor generates a square-wave signal. The frequency increases as
the wheel speed increases.
Fail-Safe FunctionINFOID:0000000005612148
ABS/EBD SYSTEM
In case of an electrical malfunction with the ABS, t he ABS warning lamp, VDC OFF indicator lamp and SLIP
indicator lamp will turn on. In case of an electrical malfunction with the EBD system, the BRAKE warning lamp,
ABS warning lamp, VDC OFF indicator lamp and SLIP indicator lamp will turn on.
LBR333
WFIA0033E
Revision: January 20102010 Versa

TROUBLE DIAGNOSISBRC-57
< SERVICE INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
• If there is damage to the connection flare nut or ABS actuator and electric unit (control unit) screw, replace the damaged part and recheck for leaks.
• When there is fluid leaking or seeping from a fluid connection, use a clean cloth to wipe off the fluid and
recheck for leaks. If fluid is still seeping out, replace the damaged part. If the fluid is leaking at the ABS
actuator and electric unit (control unit), replace the ABS actuator and electric unit (control unit) assem-
bly.
CAUTION:
The ABS actuator and electric unit (control unit) cannot be disassembl\
ed and must be replaced
as an assembly.
3. Check the brake pads for excessive wear.
POWER SYSTEM TERMINAL LOOSENESS AND BATTERY INSPECTION
Make sure the battery positive cable, negative cabl e and ground connection are not loose. In addition, make
sure the battery is sufficiently charged.
ABS WARNING LAMP, SLIP INDICATOR LAMP AND VDC OFF INDICATOR LAMP INSPECTION
1. Make sure ABS warning lamp, SLIP indicator lamp and VDC OFF indicator lamp (when VDC OFF switch
is off), turn on for approximately 2 seconds when the igni tion switch is turned ON. If they do not, check the
VDC OFF indicator lamp and then VDC OFF switch. Refer to BRC-79, "
Component Inspection". Check
CAN communications. If there are no errors with VDC OFF switch and CAN communication system,
check combination meter. Refer to DI-32, "
Component Inspection".
2. Make sure the lamps turn off approximately 2 seconds after the ignition switch is turned ON. If the lamp does not turn off, conduct self-diagnosis.
3. With the engine running, make sure VDC OFF indicator lamp turns on and off when VDC OFF switch is turned on and off. If the indicator lamp status does not correspond to switch operation, check the VDC
OFF switch system. Refer to BRC-79, "
Component Inspection".
4. Make sure ABS warning lamp, SLIP indicator lamp and VDC OFF indicator lamp turn off approximately 2 seconds after the engine is started. If ABS warning la mp, SLIP indicator lamp or VDC OFF indicator lamp
have not turned off 10 seconds after the engine has been started, conduct self-diagnosis of the ABS actu-
ator and electric unit (control unit).
5. After conducting the self-diagnosis, be sure to erase the error memory. Refer to BRC-60, "
CONSULT-III
Function (ABS)".
Warning Lamp and Indicator TimingINFOID:0000000005612156
×: ON –: OFF
Control Unit Input/Out put Signal StandardINFOID:0000000005612157
REFERENCE VALUE FROM CONSULT-III
CAUTION:
The display shows the control unit calculation data, so a normal value might be displayed even in the
event the output circuit (harness) is open or short circuited.
Condition ABS
warning lamp VDC OFF
indicator lamp SLIP
indicator lamp Remarks
When the ignition switch is OFF ––– –
After the ignition switch is turned
ON
For approx. 2 seconds ×××
–
Ignition switch ON
Approx. 2 seconds later ––– –
When the VDC OFF switch turns
ON (VDC function OFF). –
×––
ABS/TCS/VDC malfunction ×××
–
×× –When the ABS/TCS/VDC control
unit is malfunctioning (power sup-
ply or ground malfunction).
When the VDC is malfunctioning. –×× –
Revision: January 20102010 Versa

BRC-58
< SERVICE INFORMATION >[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Monitor item
Display content Data monitor
Note: Error inspection
checklist
Condition Reference value in
normal operation
FR LH SENSOR
FR RH SENSOR
RR LH SENSOR
RR RH SENSOR Wheel speedVehicle stopped
0 [km/h (mph)]
BRC-67, "
Wheel Sensor
System Inspection"Vehicle running (Note 1) Almost in accor-
dance with speed-
ometer display
(within
±10%)
FR RH IN SOL
FR RH OUT SOL
FR LH IN SOL
FR LH OUT SOL
RR RH IN SOL
RR RH OUT SOL
RR LH IN SOL
RR LH OUT SOL Solenoid valve opera-
tionActuator (solenoid) is active
(“ACTIVE TEST” with CON-
SULT-III) or actuator relay is in-
active (in fail-safe mode).
On
BRC-72, "
Solenoid and
VDC Change-Over Valve
System Inspection"When actuator (solenoid) is not
active and actuator relay is ac-
tive (ignition switch ON). Off
STOP LAMP SW Brake pedal operation Brake pedal depressed On
BRC-74, "
Stop Lamp
Switch System Inspec-
tion"Brake pedal releasedOff
MOTOR RELAY Operation status of mo-
tor and motor relayIgnition switch ON or engine
running (ABS not operated)
Off
BRC-73, "
Actuator Motor,
Motor Relay, and Circuit
Inspection"
Ignition switch ON or engine
running (ABS operated) On
ACTUATOR RLY Actuator relay opera-
tion statusVehicle stopped (Ignition
switch ON)
Off
Vehicle stopped (Engine run-
ning) On
ABS WARN LAMP ABS warning lamp ON
condition (Note 2)ABS warning lamp ON On
BRC-83, "
ABS Warning
Lamp Does Not Come On
When Ignition Switch Is
Turned On"ABS warning lamp OFF Off
OFF LAMP VDC OFF indicator
lamp status (Note 2) When VDC OFF indicator
lamp is ON
On
BRC-79, "
CAN Commu-
nication System Inspec-
tion"When VDC OFF indicator
lamp is OFF Off
OFF SW VDC OFF switch
ON/OFF status VDC OFF switch ON
(When VDC OFF indicator
lamp is ON)
On
BRC-79, "
Component In-
spection"VDC OFF switch OFF
(When VDC OFF indicator
lamp is OFF) Off
SLIP LAMP SLIP indicator lamp
status (Note 2)When SLIP indicator lamp is
ON
On
BRC-79, "
CAN Commu-
nication System Inspec-
tion"When SLIP indicator lamp is
OFF Off
BATTERY VOLT Battery voltage sup-
plied to ABS actuator
and electric unit (con-
trol unit)Ignition switch ON
10 to 16VBRC-75, "
ABS/TCS/VDC
Control Unit Power and
Ground Systems Inspec-
tion"
GEAR
Manual mode gear po-
sition determined by
TCMIgnition switch ON 1
2
3
4
5—
YAW RATE SEN Yaw rate detected by
yaw rate/side G sensorVehicle stopped
Approx. 0 d/sBRC-70, "
Yaw Rate/Side/
Decel G Sensor System
Inspection"Vehicle turning –75 to 75 d/s
Revision: January 20102010 Versa

BRC-60
< SERVICE INFORMATION >[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Note 1: Confirm tire pressure is normal.
Note 2: On and Off timing for warning lamp and indicator lamp.
CONSULT-III Function (ABS)INFOID:0000000005612158
CONSULT-III can display each diagnostic item us
ing the diagnostic test modes shown following.
SELF-DIAGNOSIS
Description
If an error is detected in the system, the ABS warning lamp will turn on. In this case, perform self-diagnosis as
follows:
Operation Procedure
1. Turn ignition switch OFF.
2. Connect CONSULT-III To the data link connector.
3. Turn ignition switch ON.
4. Start engine and drive at approximately 30 km/h (19 MPH) for approximately 1 minute.
5. After stopping the vehicle, with the engine running, t ouch “ABS”, “SELF-DIAG RESULTS” in order on the
CONSULT-III screen.
USV[FL-RR]
USV[FR-RL]
HSV[FL-RR]
HSV[FR-RL] VDC switch-over valve
statusWhen actuator (switch-over
valve) is active (“ACTIVE
TEST” with CONSULT-III) or
actuator relay is inactive (when
in fail-safe mode).
On
BRC-72, "
Solenoid and
VDC Change-Over Valve
System Inspection"
When actuator (switch-over
valve) is not active and actua-
tor relay is active (ignition
switch ON). Off
V/R OUPUT Solenoid valve relay
activatedWhen solenoid valve relay is
active (ignition switch OFF)
On
When solenoid valve relay is
not active (in fail-safe mode) Off
M/R OUTPUT Actuator motor and mo-
tor relay activatedWhen actuator motor and mo-
tor relay are active (“ACTIVE
TEST” with CONSULT-III)
On
BRC-73, "
Actuator Motor,
Motor Relay, and Circuit
Inspection"When actuator motor and mo-
tor relay are inactive Off
ENGINE RPM With engine running With engine stopped
0 rpm
BRC-68, "
Engine System
Inspection"Engine running Almost in accor-
dance with ta-
chometer display
Monitor item
Display content Data monitor
Note: Error inspection
checklist
Condition Reference value in
normal operation
ABS diagnostic mo de Description
WORK SUPPORT Supports inspection and adjustment
s. Commands are transmitted to the ABS actuator and electric unit
(control unit) for setting the status suitable for required operation, input/output signals are received from
the ABS actuator and electric unit (control unit) and received data is displayed.
SELF DIAGNOSTIC RESULT Displays ABS ac tuator and electric unit (control unit) self-diagnosis results.
DATA MONITOR Displays ABS actuator and electric unit (control unit) input/output data in real time.
CAN DIAG SUPPORT MNTR The result of transmit/receive diagnosis of CAN communication can be read. ACTIVE TEST Operation of electrical loads can be checked by sending drive signal to them.
FUNCTION TEST Conducted by CONS ULT-III instead of a technician to determine whether each system is "OK" or "NG".
ECU IDENTIFICATION ABS actuator and electric unit (control unit) part number can be read.
Revision: January 20102010 Versa

TROUBLE DIAGNOSISBRC-61
< SERVICE INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
6. The self-diagnostic results are displayed. • When “NO DTC IS DETECTED” is displayed, check the ABS warning lamp, SLIP indicator lamp and
VDC OFF indicator lamp.
7. Conduct the appropriate inspection from the display item list, and repair or replace the malfunctioning
component.
8. Start engine and drive at approximately 30 km /h (19 MPH) for approximately 1 minute.
CAUTION:
• When a wheel sensor “short-circuit” is detected, if the vehicle is not driven at 30 km/h (19 MPH)
for at least 1 minute, the ABS warn ing lamp will not turn off even if the malfunction is repaired.
9. Turn ignition switch OFF to prepare for erasing the memory.
10. Start the engine and touch “ABS”, “SELF-DIAG RESULTS”, “ERASE” in order on the CONSULT-III screen to erase the error memory.
If “ABS” is not indicated, go to GI-36, "
CONSULT-III Data Link Connector (DLC) Circuit".
CAUTION:
If the error memory is not erased, re -conduct the operation from step 5.
11. For the final inspection, drive at approximately 30 km/h (19 MPH) for approximately 1 minute and confirm
that the ABS warning lamp, SLIP indicator lamp, and VDC OFF indicator lamp are off.
Display Item List
Self-diagnostic item Malfunction detecting condition Check system
RR RH SENSOR 1
[C1101] Circuit of rear RH wheel sensor is open.
BRC-67, "
Wheel Sensor
System Inspection"
(Note 1)
RR LH SENSOR 1
[C1102]
Circuit of rear LH wheel sensor is open.
FR RH SENSOR 1
[C1103] Circuit of front RH wheel sensor is open.
FR LH SENSOR 1
[C1104] Circuit of front LH wheel sensor is open.
RR RH SENSOR 2
[C1105] Circuit of rear RH wheel sensor is shorted, or sensor power volt-
age is unusua
l. ABS actuator and electric unit (control unit) cannot
identify sensor pulses, because of large gap between wheel sen-
sor and sensor rotor.
RR LH SENSOR 2
[C1106] Circuit of rear LH wheel sensor is shorted, or sensor power volt-
age is unusua
l. ABS actuator and electric unit (control unit) cannot
identify sensor pulses, because of large gap between wheel sen-
sor and sensor rotor.
FR RH SENSOR 2
[C1107] Circuit of front RH wheel sensor is shorted, or sensor power volt-
age is unusua
l. ABS actuator and electric unit (control unit) cannot
identify sensor pulses, because of large gap between wheel sen-
sor and sensor rotor.
FR LH SENSOR 2
[C1108] Circuit of front LH wheel sensor is shorted, or sensor power volt-
age is unusua
l. ABS actuator and electric unit (control unit) cannot
identify sensor pulses, because of large gap between wheel sen-
sor and sensor rotor.
BATTERY VOLTAGE
[ABNORMAL]
[C1109] ABS actuator and electric unit (con
trol unit) power voltage is too
low. BRC-75, "
ABS/TCS/VDC
Control Unit
Power and
Ground Systems Inspec-
tion"
CONTROLLER FAILURE
[ C 111 0 ] Internal malfunction of ABS actuat
or and electric unit (control
unit). BRC-68, "ABS/TCS/VDC
Control Unit Inspection"
PUMP MOTOR
[ C 1111 ]During actuator motor operation with ON, when actuator motor
turns OFF or when control line fo
r actuator motor relay is open. BRC-73, "Actuator Mo-
tor, Motor Relay, and Cir-
cuit Inspection"During actuator motor operation with OFF, when actuator motor
turns ON or when control line for relay is shorted to ground.
Revision: January 20102010 Versa

BRC-64
< SERVICE INFORMATION >[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
FR LH OUT SOL
(On/Off)—
×× Front LH OUT ABS solenoid (On/Off) status is dis-
played.
RR RH IN SOL
(On/Off) —
×× Rear RH IN ABS solenoid (On/Off) status is dis-
played.
RR RH OUT SOL
(On/Off) —
×× Rear RH OUT ABS solenoid (On/Off) status is dis-
played.
RR LH IN SOL
(On/Off) —
×× Rear LH IN ABS solenoid (On/Off) status is dis-
played.
RR LH OUT SOL
(On/Off) —
×× Rear LH OUT ABS solenoid (On/Off) status is dis-
played.
STOP LAMP SW
(On/Off) ×××
Stop lamp switch (On/Off) status is displayed.
MOTOR RELAY
(On/Off) —
×× ABS motor relay signal (On/Off) status is dis-
played.
ACTUATOR RLY
(On/Off) —
×× ABS actuator relay signal (On/Off) status is dis-
played.
ABS WARN LAMP
(On/Off) —
×× ABS warning lamp (On/Off) status is displayed.
OFF LAMP
(On/Off) —
×× VDC OFF lamp (On/Off) status is displayed.
OFF SW
(On/Off) ×××
VDC OFF switch (On/Off) status is displayed.
SLIP LAMP
(On/Off) —
×× SLIP indicator lamp (On/Off) status is displayed.
BATTERY VOLT
(V) ××× Voltage (V) supplied to ABS actuator and electric
unit (control unit) is displayed.
GEAR
(1, 2, 3, 4) ××× A/T gear position (1, 2, 3, 4) determined by TCM
is displayed.
YAW RATE SEN
(d/s) ×××
Yaw rate (d/s) detected by yaw rate sensor is dis-
played.
ACCEL POS SIG
(%) ×
— ×Throttle valve open/close (%) status judged by
CAN communication signal is displayed.
SIDE G-SENSOR
(m/s
2) ×
— ×Lateral acceleration (m/s
2) detected by side G
sensor is displayed.
STR ANGLE SIG
(deg) ×
— ×Steering angle (deg) detected by steering angle
sensor is displayed.
PRESS SENSOR
(bar) ×
— ×Brake fluid pressure detected by pressure sensor
is displayed.
EBD SIGNAL
(On/Off) ——
×EBD operation (On/Off) status is displayed.
ABS SIGNAL
(On/Off) ——
×ABS operation (On/Off) status is displayed.
TCS SIGNAL
(On/Off) ——
×TCS operation (On/Off) status is displayed.
VDC SIGNAL
(On/Off) ——
×VDC operation (On/Off) status is displayed.
EBD FAIL SIG
(On/Off) ——
×EBD fail signal (On/Off) status is displayed.
ABS FAIL SIG
(On/Off) ——
×ABS fail signal (On/Off) status is displayed.
TCS FAIL SIG
(On/Off) ——
×TCS fail signal (On/Off) status is displayed.
VDC FAIL SIG
(On/Off) ——
×VDC fail signal (On/Off) status is displayed.
Revision: January 20102010 Versa

TROUBLE DIAGNOSISBRC-65
< SERVICE INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
× : Applicable
–: Not applicable
ACTIVE TEST
CAUTION:
• Do not perform active test while driving vehicle.
• Make sure to completely bleed air from brake system.
• The active test cannot be performed with the AB S warning lamp, VDC indicator lamp, SLIP indicator
lamp or brake warning lamp on.
• ABS warning lamp, VDC OFF indicator lamp, SLIP indicator lamp and brake warning lamp are on
during active test.
NOTE:
• When active test is performed while depressing the pedal, the pedal depression amount will change. This is normal. (Only solenoid valve and ABS motor)
• “TEST IS STOPPED” is displayed 10 seconds after operation start.
• After “TEST IS STOPPED” is displayed, to perform test again, touch BACK.
Test Item
SOLENOID VALVE
• When performing an active test of the ABS function, select “MAIN SIGNALS” for each test item.
• For ABS solenoid valve, touch “Up”, “Keep”, and “Dow n” on the display screen. For ABS solenoid valve
(ACT), touch “Up”, “ACT UP ”, “ACT KEEP” and confirm that solenoid valves operate as shown in the table
below.
CRANKING SIG
(On/Off) ——
×Cranking condition (On/Off) status is displayed.
FLUID LEV SW
(On/Off) ×
— ×Brake fluid level switch (On/Off) status is dis-
played.
PARK BRAKE SW
(On/Off) ×
— ×Parking brake switch (On/Off) status is displayed.
USV[FL-RR]
(On/Off) ——
×Primary side USV solenoid valve (On/Off) status is
displayed.
USV[FR-RL]
(On/Off) ——
×Secondary side USV solenoid valve (On/Off) sta-
tus is displayed.
HSV[FL-RR]
(On/Off) ——
×Primary side HSV solenoid valve (On/Off) status is
displayed.
HSV[FR-RL]
(On/Off) ——
×Secondary side HSV solenoid valve (On/Off) sta-
tus is displayed.
V/R OUTPUT
(On/Off) ——
×Valve relay operation signal (On/Off) status is dis-
played.
M/R OUTPUT
(On/Off) ——
×Motor relay operation signal (On/Off) status is dis-
played.
ENGINE RPM
(rpm) ×
— ×Engine speed judged by CAN communication sig-
nal is displayed.
Operation ABS solenoid va
lve ABS solenoid valve (ACT)
Up Keep Down Up ACT UP ACT KEEP
FR RH SOL FR RH IN SOL Off On On — —
—
FR RH OUT SOL Off Off On* — — —
USV [FR-RL] Off Off On* — — —
HSV [FR-RL] Off Off On* — — —
FR LH SOL FR LH IN SOL Off On On — —
—
FR LH OUT SOL Off Off On* — — —
USV [FL-RR] Off Off On* — — —
HSV [FL-RR] Off Off On* — — —
Revision: January 20102010 Versa

TROUBLE DIAGNOSES FOR SYMPTOMSBRC-81
< SERVICE INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
TROUBLE DIAGNOSES FOR SYMPTOMS
ABS Works FrequentlyINFOID:0000000005612173
1.CHECK WARNING LAMP ACTIVATION
Make sure warning lamp remains off while driving.
OK or NG
OK >> GO TO 2.
NG >> Carry out self-diagnosis. Refer to BRC-60, "
CONSULT-III Function (ABS)".
2.CHECK WHEEL SENSORS
Check the following.
• Wheel sensor mounting for looseness
• Wheel sensors for physical damage
• Wheel sensor connectors for terminal damage or loose connections
OK or NG
OK >> GO TO 3.
NG >> Repair as necessary.
3.CHECK WHEEL BEARINGS
Check wheel bearing axial end play. Refer to FA X - 6 , "
On-Vehicle Inspection and Service" or RAX-6, "On-Vehi-
cle Inspection and Service".
OK or NG
OK >> GO TO 4.
NG >> Repair as necessary.
4.CHECK BRAKE FLUID PRESSURE
Check brake fluid pressure distribution.
Refer to BR-9, "
On Board Inspection".
Is brake fluid pressure distribution normal?
YES >> Inspection End.
NO >> Perform Basic Inspection. Refer to BRC-56, "
Basic Inspection".
Unexpected Pedal ActionINFOID:0000000005612174
1.CHECK WARNING LAMP ACTIVATION
Make sure warning lamp remains off while driving.
OK or NG
OK >> GO TO 2.
NG >> Carry out self-diagnosis. Refer to BRC-60, "
CONSULT-III Function (ABS)".
2.CHECK BRAKE PEDAL STROKE
Check brake pedal stroke.
Is pedal stroke excessive?
YES >> Perform Basic Inspection. Refer to BRC-56, "Basic
Inspection".
NO >> GO TO 3.
SBR540A
Revision: January 20102010 Versa
