2010 MAZDA MODEL CX-7 display

16
RoutingAddress
Book
Getting Started
Navigation Set Up
Open the
[Navigation
Setup]
nArrival TimeThe time which is displayed until reaching the destination or a
way point can be set as an estimated arrival time or the
remaining time.
Select to display the estimated arrival time, or to
display the remaining time.
nAverage SpeedSet the average speed for each road to be driven.
(This function sets the standard speed (average vehicle speed
for each route) used for calculating the estimated arrival time
when calculating the route time.)
nEdit Memory PointUsed to edit the memory point or Home setting.( page 36, 38)
nDelete Previous PointUsed to delete the previously set destination.
nOperation GuideUsed to switch the operating guide display.
Operation Guide
2%:8:9)FSSO4EKI1SRHE].ERYEV]41

17
Getting Started
Navigation Set Up
Open the
[Navigation
Setup]
nAuto Complete TextWhen entering text, the system displays possible candidates of
words which may match the one you are trying to input. If the
system narrows down the candidate to one, the word is
automatically displayed.
Used to switch the auto complete text.
nAdjust Current PositionUsed to adjust the vehicle position if it deviates from the Map
screen.
nRestore DefaultsRestores the default settings.
2%:8:9)FSSO4EKI1SRHE].ERYEV]41

18
RoutingAddress
Book
Getting Started
Screen Names and Functions
Screens Before Setting Route
(1) Map Orientation
( page 15)
(2) Clock(3) Temperature
Displays the ambient temperature.
(4) Vehicle marker
Shows the current position and
direction of your vehicle.(5) Scale display
Displays the scale of the map.
(6) Current Road Name
Shows the name of the road you are
currently driving on.
(7) Operation Guide
Displays the operational guidance.
( page 16)
Screens During Route Guidance
(1) The traveled distance to the
destination and the estimated arrival
time/remaining travel time
Displays the remaining time to the
destination.
Estimated arrival time to the destination
or the estimated remaining driving time
can be displayed by selecting either of
them. ( page 16)(2) Route display
Shows the provided route as a thick
blue line.
(3) Turn Arrow display
Shows the direction to turn at the next
junction and the distance to the junction.
(4) Next Guided Street Name display
(4)
(2)
(6)
(3)(5)
(1)(7)
(3)(1) (2)
(4)
2%:8:9)FSSO4EKI*VMHE](IGIQFIV41

19
Getting Started
The screen map can be scaled to 14 different sizes.
nBrightness/Contrast
Brightness and contrast of the navigation screen can be adjusted.
1. Press the INFO switch to display the SETTINGS screen.
2. Select PREFERENCES and press the Enter (up/down) switch.
3. Select SCREEN ADJUSTMENT and press the Enter (up/down) switch.
4. Select BRIGHTNESS/CONTRAST and press the Enter (up/down) switch.
5. Select BRIGHTNESS or CONTRAST using the left or right switch.
6. Adjust the tone by operating the Enter (up/down) switch upward/downward.
7. After setting, press the Enter (up/down) switch to finish the setting.
nDaytime/Night screen
When the headlights are on, daytime mode can also be selected (if a brighter screen is
needed at night). This selection can only be done when the headlights are on.
lThe screen can be returned to the daytime screen while the headlights or running lights are
on by pushing the dashboard illumination knob. You will hear a beep sound and the
illumination dimmer will be canceled. With each press of the dashboard illumination knob,
the dashboard illumination will change from dim to full bright and back to dim again.
Adjusting the Map Scale
1
Press the Enter (up/down) switch up or down while the Map screen is
displayed to zoom in/out of the Map screen.
Screen Adjustments
Scale bar
2%:8:9)FSSO4EKI*VMHE](IGIQFIV41

20
RoutingAddress
Book
Getting Started
Character Entry
Street
Name, City
Name, and
Other
Input
Select the first several
characters on the
screen. (Step 1)Select your target
in the list.
(Step 2)
1.Press the Enter (up/down)
switch up or down, select the
letter, and press the Enter (up/
down) switch.
Pressing the Enter (up/down)
switch with the cursor set to Del
erases one letter.
2.Set the cursor to Done and press
the Enter (up/down) switch. The
area names, Point names, city
names, or Street names which
include the letters currently
being input are displayed.l
If a desired name is not in the
list, go back to Step 1, and try
fewer characters.
: The input character can be
deleted.
: The list appears.
: You can change the type of text.
lExamples
Street: CANAL Street: 52ND
Enter by selecting characters: Enter by selecting characters:
The name list including the
input spelling is displayed.
Street: MAIN STREET
Enter by selecting characters:
CA 5 2
MA
2%:8:9)FSSO4EKI*VMHE](IGIQFIV41

21
Getting Started
Register Home
Before Stepsselect select
( page 22)
(
page 26)
(
page 28)
(
page 26)
(
page 30)
(
page 30)
Open the
[Home] Menu
Ye s
Note
The Home registration screen is not displayed if home registration is already finished.
2%:8:9)FSSO4EKI*VMHE](IGIQFIV41

25
Before
UseGetting
started
Routing
lFor Character Entry, please refer to page 20.
nput the city name.
Select the city
name from the
list.Input the
street name.Select the
street name
from the list.
Input the
House
Number.
Select
Notes
lOnce the destination is set, or is displayed for the following
destination settings.
lTo add to the destinations, select and follow the same procedure as that
of the first destination setting.
lTo re-set the destinations, select and follow the same procedure as that
of the first destination setting.
lThe number of points which can be set as destinations are limited to two.Add toReplace
Add to
Replace
2%:8:9)FSSO4EKI*VMHE](IGIQFIV41

26
Before
UseGetting
started
Routing
Set Destination
Before Steps select
Previous
Home
Memory
Point
Openthe[Set
Destination]
Menu Select
The previously set destinations are displayed.
Select the
desired
Memory
Point.
Name:Displays the list in alphabetical
order.
Date:Displays the list in registration/edit
date order.
Notes
l Once the ddestination
lTo add to tthe first de
lTo r e - s e t t
the first delThe numb
SelectA home
address is
already
registered in
the Destination
setting.
A home address
is not registered
in the Destination
setting yet.
( page 21)
Select
Registered memory points and registered
Home can be set in the Destination setting.
Select the
desired
Memory
Point.
Name:Displays the list in alphabetical order.
Date: Displays the list in registration/edit date order.
Icon:
Displays the list of the registered location icons.
