2010 Lexus GX460 Using The Bluetooth Audio System /

464
3-3. Using the Bluetooth® audio system
GX460_U.S.A. (OM60E69U)
Menu list of the Bluetooth® audio system
■ Normal operation
First menuSecond
menuThird menuOperation detail
“Setup”
“BT•A 
Setup”
“Pair Audio”Registering a portable player
“Connect”Selecting a portable player to
be used
“Change Name”Changing the registered name
of a portable player
“List Audios”Listing the registered portable
players
“Set Passkey”Changing the passkey
“Delete Audio”Deleting a registered portable
player
“System
Setup”
“Guidance Vol”Setting voice guidance volume
“Device Name”Displaying the Bluetooth®
device address and name
“Initialize”Initializing the system

465
3-3. Using the Bluetooth® audio system
3
Interior features
GX460_U.S.A. (OM60E69U)
■When using a voice command
For numbers, say a combination of single digits from zero to nine.
Say the command correctly and clearly.
■Situations that the system may not recognize your voice
●When driving on rough roads
●When driving at high speeds
●When air is blowing out of the vents onto the microphone
●When the air conditioning fan emits a loud noise
■Operations that cannot be performed while driving
●Operating the system with the “TUNE/SEL” knob
●Registering a portable player to the system
■Changing the passkey
P. 4 74

466
3-3. Using the Bluetooth® audio system
GX460_U.S.A. (OM60E69U)
Operating a Bluetooth® enabled portable player
Random playbackRepeat play
Playback/ 
pause Selecting an album
Search play
Playback
Selecting a track
Display text message
Po w e r Vo l u m e
BT•A menu knob

467
3-3. Using the Bluetooth® audio system
3
Interior features
GX460_U.S.A. (OM60E69U)
Selecting an albumTo select the desired album, press the 5 ( ) or 6 ( ) button.
Selecting tracks
Press “ ” or “ ” on the “SEEK•TRACK” button to select the desired track.
Playing and pausing tracks
To play or pause a track, press the 3 ( ) button.
Fast-forwarding and rewinding tracksTo fast-forward or rewind, press and hold “ ” or “ ” on the
“SEEK•TRACK” button until you hear a beep.
Random playback
Press the 1 (RAND) button.
To cancel, press the 1 (RAND) button again.
Repeat playPress the 2 (RPT) button.
To cancel, press the 2 (RPT) button again.

468
3-3. Using the Bluetooth® audio system
GX460_U.S.A. (OM60E69U)
Scanning tracksPress the “SCAN” button.
To cancel, press the “SCAN” button again.
Switching the displayPress the “TEXT” button.
Each time the button is pressed, the display changes in the following order:
Elapsed time  Album title  Tr a c k t i t l e  Artist name
Using the steering wheel audio switches
 P. 4 5 2
■Bluetooth® audio system functions
Depending on the portable player that is connected to the system, certain functions
may not be available.
■Display
 P. 4 2 0
■Error messages
“Memory Error”: This indicates a problem in the system.

469
3-3. Using the Bluetooth® audio system
3
Interior features
GX460_U.S.A. (OM60E69U)
Setting up a Bluetooth® enabled portable player
Registering a portable player in the Bluetooth® audio system allows the
system to function. The following functions can be used for registered por-
table players:
■ Functions and operation procedures
Pattern A
To enter the menu for each function , follow the steps below using a
voice command or the “TUNE/SEL” knob:
●Registering a portable player 
1. “Setup”  2. “Bluetooth Audio Setup (BT•A Setup)”  
3. “Pair Audio Player (Pair Audio)”
● Selecting a portable player to be used 
1. “Setup”  2. “Bluetooth Audio Setup (BT•A Setup)”  
3. “Connect Audio Player (Connect)”
● Changing the registered name of a portable player 
1. “Setup”  2. “Bluetooth Audio Setup (BT•A Setup)”  
3. “Change Name”
● Listing the registered portable players 
1. “Setup”  2. “Bluetooth Audio Setup (BT•A Setup)”  
3. “List Audio Players (List Audios)”
● Changing the passkey 
1. “Setup”  2. “Bluetooth Audio Setup (BT•A Setup)”  
3. “Set Passkey”
● Deleting a registered portable player 
1. “Setup”  2. “Bluetooth Audio Setup (BT•A Setup)”  
3. “Delete Audio Player (Delete Audio)”

470
3-3. Using the Bluetooth® audio system
GX460_U.S.A. (OM60E69U)
Pattern BPress the “TUNE/SEL” knob to select “BT•A MENU”.
Press the talk switch or select “BT•A Setup” using the “TUNE/
SEL” knob.
Select one of the following fu nctions using a voice command
or the “TUNE/SEL” knob.
● Registering a portable player 
“Pair Audio Player (Pair Audio)”
● Selecting a portable player to be used 
“Connect Audio Player (Connect)”
● Changing the registered name 
“Change Name”
● Listing the registered portable players 
“List Audio Players (List Audios)”
● Changing the passkey 
“Set Passkey”
● Deleting a registered portable player 
“Delete Audio Player (Delete Audio)”
STEP1
STEP2
STEP3

471
3-3. Using the Bluetooth® audio system
3
Interior features
GX460_U.S.A. (OM60E69U)
Registering a portable playerSelect “Pair Audio Player (Pair Audio)” using a voice command or the
“TUNE/SEL” knob, and perform the proc edure for registering a portable
player. ( P. 4 6 2 )
Selecting a portable player to be used
Select “Connect Audio Player (Connect)” using a voice com-
mand or the “TUNE/SEL” knob.
Pattern A
Select the portable player to be used by either of the following
methods, and select “Confirm” by using a voice command or the
“TUNE/SEL” knob:
a. Press the talk switch and say the name of the desired portable
player.
b. Press the talk switch and sa y “List Audio Players”. When the
name of the desired portable pl ayer is read aloud, press the
talk switch.
Pattern B Select the portable player to be used using the “TUNE/SEL”
knob.
STEP1
STEP2
STEP2
