153
1-7. Safety information
1
Before driving
GX460_U.S.A. (OM60E69U)
Installation with LATCH systemFold the seatback forward. Then
return the seatback and secure it
at the first lock position (most
upright position). ( P. 6 8 )
Anchor bracket (for top tether
strap)
Anchor brackets are provided
for each second seats.
STEP1

154
1-7. Safety information
GX460_U.S.A. (OM60E69U)Ty p e A
Flip the cover (vehicles with third
seats), and latch the hooks of lower
straps onto the LATCH anchors. If
the child restraint has a top tether
strap, the top tether strap should
be latched onto the top tether
strap anchor. ( P. 161)
For owners in Canada: 
The symbol on a child restraint sys-
tem indicates the presence of a
lower anchorage system.
Ty p e B Flip the cover (vehicles with third
seats), and latch the buckles onto
the LATCH anchors. If the child
restraint has a top tether strap, the
top tether strap should be latched
onto the top tether strap anchor.
( P. 161)
For owners in Canada: 
The symbol on a child restraint sys-
tem indicates the presence of a
lower anchorage system.
Canada only
STEP2
Canada only
STEP2

155
1-7. Safety information
1
Before driving
GX460_U.S.A. (OM60E69U)
Installing child restraints using a seat belt (child restraint lock function
belt)
■ Rear facing Infant seat/convertible seat
Fold the seatback forward. Then
return the seatback and secure it
at the first lock position (most
upright position). ( P. 6 8 )
Place the child restraint system on
the rear seat facing the rear of the
vehicle.
Run the seat belt through the child
restraint system and insert the
plate into the bu ckle. Make sure
that the belt is not twisted.
STEP1
STEP2
STEP3

156
1-7. Safety information
GX460_U.S.A. (OM60E69U)Fully extend the shoulder belt and
allow it to retract to put it in lock
mode. In lock mode, the belt can-
not be extended.
While pushing the child restraint
system down into the rear seat,
allow the shoulder belt to retract
until the child restraint system is
securely in place.
After the shoulder belt has
retracted to a point where there is
no slack in the belt, pull the belt to
check that it cannot be extended.
STEP4
STEP5

157
1-7. Safety information
1
Before driving
GX460_U.S.A. (OM60E69U)■
Forward facing Convertible seat
Fold the seatback forward. Then
return the seatback and secure it
at the first lock position (most
upright position). ( P. 6 8 )
Place the child restraint system on
the seat facing the front of the vehi-
cle.
Run the seat belt through the child
restraint system and insert the
plate into the bu ckle. Make sure
that the belt is not twisted.
STEP1
STEP2
STEP3

158
1-7. Safety information
GX460_U.S.A. (OM60E69U)Fully extend the shoulder belt and
allow it to retract to put it in lock
mode. In lock mode, the belt can-
not be extended.
While pushing the child restraint
system into the re
ar seat, allow the
shoulder belt to retract until the
child restraint system is securely in
place.
After the shoulder belt has
retracted to a point where there is
no slack in the belt, pull the belt to
check that it cannot be extended.
If the child restraint has a to p tether strap, the top tether strap
should be latched onto the top tether strap anchor. ( P. 161)
STEP4
STEP5
STEP6

159
1-7. Safety information
1
Before driving
GX460_U.S.A. (OM60E69U)■
Booster seat
Fold the seatback forward. Then
return the seatback and secure it
at the first lock position (most
upright position). ( P. 6 8 )
Place the child restraint system on
the seat facing the front of the vehi-
cle.
STEP1
STEP2

160
1-7. Safety information
GX460_U.S.A. (OM60E69U)Sit the child in the child restraint
system. Fit the seat belt to the child
restraint system according to the
manufacturer’s instructions and
insert the plate into the buckle.
Make sure that the belt is not
twisted.
Check that the shoulder belt is cor-
rectly positioned over the child’s
shoulder, and that the lap belt is as
low as possible. (
P. 8 6 )
Removing a child restraint installed with a seat belt
Push the buckle release button
and fully retract the seat belt.
STEP3
