2010 Lexus GX460 Scheduled Maintenance Guide /

33
GX460_QG_U (OM60E77U)
Automatic High Beam (If Equipped)
■Activating the Automatic High Beam system
Turn the headlight switch to “AUTO”
position.
Push the lever away from you.
The Automatic High Beam indicator will
come on when the headlights are turned
on automatically to indicate that the sys-
tem is active.
The Automatic High Beam uses an in-vehicle camera sensor to assess the brightness of
streetlights, the lights of oncoming and preceding vehicles, etc., and automatically turns
high beam on or off as necessary.
When all of the following conditions are fulfilled, high beam will be automatically turned on
(after approximately 1 second):
• Vehicle speed is above approximately 20 mph (32 km/h).
• The area ahead of the vehicle is dark.
• There are no oncoming or preceding vehicles with headlights or tail lights turned on.

34
GX460_QG_U (OM60E77U)
Windshield Wipers and Washers
Off
Rain-sensing wiper operation
Low speed wiper operation
High speed wiper operation
Te m p o r a r y o p e r a t i o n
Increases the sensitivity
Decreases the sensitivity
Washer/wiper dual operation
The wipers operate automatically. (After
operating several times, the wipers
operate one more time after a short
delay to prevent dripping.)
Vehicles with the headlight cleaners: If
the headlights are on, the headlight
cleaners will operate once.

35
GX460_QG_U (OM60E77U)
Rear Window Wiper and Washer
Off
Intermittent window wiper
operation
Normal window wiper opera-
tion
Washer/wiper dual operation
Washer/wiper dual operation

36
GX460_QG_U (OM60E77U)
Navigation System (If Equipped)
■Register home
Push the “SETUP” button.
Touch “Navi.”.
To u c h “ H o m e ” .
Touch “Set Home”.
To u c h “A d d r e s s ” .
To u c h “ C i t y ” .
Input a city name and touch “OK”.
Touch the button of the desired city
name from the displayed list.
Input the street name and touch “OK”.
When the desired street name is found,
touch the corresponding button.
Input a house number and touch “OK”.
Touch “Enter”.
To u c h “ O K ” .STEP2
STEP3
STEP5
STEP6

37
GX460_QG_U (OM60E77U)
■Destination input  Search by address
Select by city name
Push the “DEST” button
To u c h “A d d r e s s ” .
To u c h “ C i t y ” .
Input a city name and touch “OK”.
Touch the button of the desired city
name from the displayed list.
Input the street name and touch “OK”.
When the desired street name is found,
touch the corresponding button.
Input a house number and touch “OK”.
To u c h “ G o t o ” .
To u c h “ O K ” .
STEP2
STEP3
STEP4
STEP6

38
GX460_QG_U (OM60E77U)
■Destination input  Search by address
Select by street address
Push the “DEST” button.
To u c h “A d d r e s s ” .
Touch “Street Address”.
Input a house number and touch “OK”.
Input the street name and touch “OK”.
When the desired street name is found,
touch the corresponding button.
Input a city name and touch “OK”.
Touch the button of the desired city
name from the displayed list.
To u c h “ G o t o ” .
To u c h “ O K ” .
-
STEP2
STEP3
STEP4
STEP5

39
GX460_QG_U (OM60E77U)
■Destination input  Search points of interest by name
Push the “DEST” button.
Touch “Point of Interest”.
To u c h “ N a m e ” .
Input the name of the point of interest
and touch “OK”.
Touch the button of the desired destina-
tion.
To u c h “ G o t o ” .
To u c h “ O K ” .STEP2
STEP3
STEP4
STEP5

40
GX460_QG_U (OM60E77U)
■Destination input Search points of interest by category
Push the “DEST” button.
Touch “Point of Interest”.
Touch “Category”.
Touch “Near a Destination”.
Touch the button of the desired destina-
tion and set the search point.
Touch the desired point of interest cate-
gory.
Touch the desired point of interest cate-
gory from the list.
To u c h “ G o t o ” .
To u c h “ O K ” .STEP2
STEP3
STEP4
STEP6
