2010 JAGUAR XFR coolant

- Megafuse fixing nuts
Engine junction box
- Megafuse
- Megafuse fixing nuts
- Fuses
- Engine control module relay Were any circuits or wiring short circuit to ground, short circuit to power, open circuit, high resistance or any
connectors damaged from water ingress, pin damage and/or corrosion?
Yes
Rectify as required
No
Proceed to the next step. A9 'Cooling fan validation procedure' A9: COOLING FAN VALIDATION PROCEDURE 1 Ensure the hood is closed 2 Allow vehicle to idle 3 Switch ON air conditioning and set to lowest temperature and highest fan speed 4 Allow vehicle to reach operating temperature (approximately 90 degrees C). Using the manufacturer approved diagnostic system monitor datalogger signals – Engine Coolant Temperature (0XF405) -and -
Electric Fan PWM Control - Commanded (0X03F9) - as the engine coolant temperature reaches
operating temperature the fan speed should also increase between the values of 9 and 90% Did the cooling fan rotate at increasing speed as engine coolant temperature increased?
Yes
Return vehicle to customer
No
Contact dealer technical support DTC Index

For a list of diagnostic trouble codes (DTCs) that could be logged on this vehicle, please refer to Section 100-00.
REFER to: Electronic Engine Controls (303-14D Electronic Engine Controls - V8 S/C 5.0L Petrol, Diagnosis and Testing). www.JagDocs.com

Published: 11-May-2011
Engine Cooling - V8 5.0L Petrol/V8 S/C 5.0L Petrol - Cooling System Draining
and Vacuum Filling
General Procedures

Draining

1. Refer to: Radiator Splash Shield (501-02 Front End Body Panels, Removal and Installation).


2. WARNING: Release the cooling system pressure by slowly
turning the coolant expansion tank cap a quarter of a turn.
Cover the expansion tank cap with a thick cloth to prevent
the possibility of scalding. Failure to follow this instruction
may result in personal injury.
CAUTIONS:


Since injury such as scalding could be caused by
escaping steam or coolant, make sure the vehicle cooling
system is cool prior to carrying out this procedure


Be prepared to collect escaping coolant.



3. WARNING: Do not work on or under a vehicle supported only by a jack.
Always support the vehicle on safety stands.
Raise and support the vehicle.


4. CAUTION: Be prepared to collect escaping coolant.

5. Torque: 2 Nm 6. CAUTION: Be prepared to collect escaping coolant.

NOTE: Only carry out the following step if the coolant
is to be drained from the engine.












7. NOTE: This step is only required if previously
removed.

Torque: 50 Nm












Filling

1. Refer to: Radiator Splash Shield (501-02 Front End Body Panels, Removal and Installation).

2. Lower the vehicle.

3. CAUTION: Anti-freeze concentration must be maintained at 50%.

Install the cooling system vacuum refill adaptor to the expansion
tank.
Install the vacuum filler gauge to the cooling system vacuum
refill adaptor.
Install the venturi tube assembly to the vacuum filler gauge.

4. NOTES:


Make sure the coolant supply valve is in the closed position on the
vacuum filler gauge assembly.


The coolant vacuum fill tool needs an air pressure of 6 to 8 bar (87
to 116 psi) to operate correctly.


Small diameter or long airlines may restrict airflow to the coolant
vacuum fill tool.

Connect a regulated compressed air supply to the venturi tube
assembly.

5. Position the evacuated air hose into a container.

6. Open the air supply valve.


7. NOTE: Make sure the coolant supply hose is positioned into a container
of fifty percent mixture of Jaguar Premium Cooling System Fluid or
equivalent, meeting Jaguar specification WSS M97B44-D and fifty
percent water. Make sure no air can enter the coolant supply hose.

Open the coolant supply valve for 2 seconds to prime the coolant supply
hose.

8. Apply air pressure progressively until the arrow on the vacuum filler
gauge reaches the green segment.

9. Disconnect the compressed air supply line.


10. NOTE: Close the coolant supply valve when the coolant expansion
tank MAX mark is reached or coolant movement has ceased.

Open the coolant supply valve and allow the coolant to be drawn into
the system.

11. Remove the vacuum filler gauge and cooling system vacuum refill
adaptor assembly.

12.














13.
Set the heater controls to maximum.


14. CAUTION: Observe the engine temperature gauge. If the engine
starts to over-heat switch off immediately and allow to cool. Failure to
follow this instruction may cause damage to the vehicle
Start the engine and idle until hot air is emited at the face registers.

15. Switch the heater off.

16. Raise the engine speed to 2000 RPM for eight minutes.


17. CAUTION: Switch off the engine and allow the coolant temperature
to go cold.
Switch the engine off.

18. Visually check the engine and cooling system for signs of coolant
leakage.


19. WARNING: When releasing the cooling system pressure, cover the
coolant expansion tank cap with a thick cloth.
CAUTIONS:


Since injury such as scalding could be caused by escaping steam or
coolant, make sure the vehicle cooling system is cool prior to carrying
out this procedure


Make sure the coolant level remains above the "COLD FILL RANGE"
lower level mark.


NOTE: When the cooling system is warm, the coolant will be
approximately 10mm above the upper level mark on the expansion tank
with the cap removed.
Check and top-up the coolant if required.

Published: 14-Feb-2013
Engine Cooling - V8 5.0L Petrol/V8 S/C 5.0L Petrol - Cooling System Partial Draining, Filling and Bleeding V8 S/C 5.0L Petrol
General Procedures

Draining

1. WARNING: Make sure to support the vehicle with axle stands.
Raise and support the vehicle.

2. Refer to: Radiator Splash Shield (501-02 Front End Body Panels, Removal and Installation).

3. WARNINGS:


Release the cooling system pressure by slowly turning
the coolant expansion tank cap a quarter of a turn. Cover
the expansion tank cap with a thick cloth to prevent the
possibility of scalding. Failure to follow this instruction may
result in personal injury.


Be prepared to collect escaping fluid.


CAUTION: Since injury such as scalding could be
caused by escaping steam or coolant, make sure the vehicle
cooling system is cool prior to carrying out this procedure.



4. CAUTION: Be prepared to collect escaping fluids. www.JagDocs.com

Filling

1. Refer to: Radiator Splash Shield (501-02 Front End Body Panels, Removal and Installation).

2. Lower the vehicle.

3.
4. CAUTION: Anti-freeze concentration must be maintained at 50%.

Fill the cooling system, keeping coolant to the upper level mark of the
expansion tank until a steady stream of coolant is seen running from the
coolant hose bleed point.

5.
Continue to fill the coolant until the maximum level
is reached.


















6. Set the heater controls to maximum.

7. Start engine and increase speed to 2000 rpm for 2 minutes.

8.
Continue to top-up with coolant with engine idling until hot air is
emitted from face vents.
When hot air is emitted from the vents, switch the heater off. Go
to Step 10.

9. If no hot air is emitted, turn the engine off for 10 seconds and the start
the engine and return to Step 7.


10. CAUTION: Correct installation of the Coolant
expansion tank cap can be obtained by tightening the cap
until an audible click is heard.

Continue to fill the coolant until the maximum level is
reached.









11. Switch the heater off.

12. Raise the engine speed to 2000 rpm for eight minutes.

13. Switch the engine off and allow to cool.

14. Visually check the engine and cooling system for signs of coolant
leakage.
