PRECAUTION
PRECAUTIONS
Precaution for Supplemental
Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000005152909
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and w hether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the “SRS AIR BAG” and “SEAT BELT” of this
Service Manual.
WARNING:
• To avoid rendering the SRS inoper ative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintentional act ivation of the system. For removal of Spiral Cable and Air Bag
Module, see the “SRS AIR BAG”.
• Do not use electrical test equipm ent on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the
ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s)
with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly
causing serious injury.
• When using air or electric power tools or hammers, always switch the ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service.
Precautions for Trouble DiagnosisINFOID:0000000005146455
CAUTION:
• Never apply 7.0 V or more to the measurement terminal.
• Use a tester with open terminal voltage of 7.0 V or less.
• Turn the ignition switch OFF and disconnect th e battery cable from the negative terminal when
checking the harness.
Precautions for Harness RepairINFOID:0000000005146456
• Solder the repaired area and wrap tape around the soldered area.
NOTE:
A fray of twisted lines must be within 110 mm (4.33 in).
SKIB8766E
Revision: April 20092010 QX56

LAN
CAN COMMUNICATION SYSTEMLAN-45
< FUNCTION DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
Engine speed signal
T RRR R R R R R
Engine status signal TR
Fuel consumption monitor signal TR
RT
ICC steering switch signal TR
Malfunction indicator lamp signal T R
Wide open throttle position signal T R
A/T CHECK indicato r lamp signal T R
A/T fluid temperature sensor signal T R
A/T position indicator lamp signal TR RR
A/T self-diagnosis signal R T
Current gear position signal TR R
Input speed signal R TR
Output shaft revolution signal R TR R
P range signal TR R RR
ICC sensor signal T R
Buzzer output signal TR
TR
ICC OD cancel request signal R RT
ICC operation signal R RT
ICC system display signal TR
System setting signal TRT
RTR
A/C switch/indicator signal TR
RT
A/C switch signal RT R
Blower fan motor switch signal RT
Day time running light request signal TR R
Door lock/unlock status signal TR
Door switch signal R R TR R R
Front fog light request signal TR
Front wiper request signal RT R
High beam request signal TR R
Horn chirp signal TR
Ignition switch signal RTR R
Key fob door unlock signal RT
Key fob ID signal RT
Key switch signal RT
Low beam request signal TR
Position light request signal TR R
Rear window defogger switch signal T RR
Sleep wake up signal RT R R
Theft warning horn request signal TR
Signal name/Connecting unit
ECM
TCM
LASER ICC
ADP AV
BCM
HVAC I-KEY M&A
STRG 4WD
ABS
IPDM-E
Revision: April 20092010 QX56

LAN-46
< FUNCTION DIAGNOSIS >[CAN]
CAN COMMUNICATION SYSTEM
NOTE:
CAN data of the air bag diagnosis sensor unit is not us
ed by usual service work, thus it is omitted.
Tire pressure data signal R T
Tire pressure signal R TR
Turn indicator signal TR
Buzzer output signal TR
Door lock/unlock request signal RT
Hazard request signal RT
Hazard warning lamp request signal RT
Ignition knob switch signal RT
KEY warning signal TR
LOCK warning signal TR
Panic alarm request signal RT
Power window open request signal RT
1st position switch signal R T
4th position switch signal R T
Distance to empty signal RT
Fuel level low warning signal RT
Fuel level sensor signal R T
Parking brake switch signal RT
Seat belt buckle switch signal RT
Stop lamp switch signal R T
Tow mode switch signal R T
Vehicle speed signal RRR RRR R T
RRRT
Steering angle sensor signal TR
ABS malfunction signal RT
ABS warning lamp signal RT
Brake pressure sensor signal RT
Brake warning lamp signal RT
SLIP indicator lamp signal RT
TCS malfunction signal RT
VDC malfunction signal RT
VDC OFF indicator lamp signal RRT
VDC operation signal RT
Front wiper stop position signal RT
High beam status signal R T
Hood switch signal RT
Low beam status signal R T
Rear window defogger control signal R RT
Signal name/Connecting unit
ECM
TCM
LASER ICC
ADP
AV
BCM
HVAC I-KEY M&A
STRG 4WDABS
IPDM-E
Revision: April 20092010 QX56

LAN-48
< FUNCTION DIAGNOSIS >[CAN]
TROUBLE DIAGNOSIS
Driver Seat Control Unit
0: Error at present, 1 – 39: Error in the past (Number m
eans the number of times the ignition switch is turned OFF →ON)
*: 39 or higher number is fixed at 39 until the self-diagnosis result is erased.
AV Control Unit
0: Error at present, 1 – 39: Error in the past (Number m eans the number of times the ignition switch is turned OFF →ON)
*: 39 or higher number is fixed at 39 until the self-diagnosis result is erased.
BCM
ITEM CAN DIAG SUP-
PORT MNTR DescriptionNormal Error
PRSNT
ICC INITIAL DIAG Status of CAN controller
OKNG
TRANSMIT DIAG Signal transmission status
UNKWN
ECM
Signal receiving status from the ECM
VDC/TCS/ABS Signal receiving status from the ABS actuator and electric unit (con-
trol unit)
TCM Signal receiving status from the TCM
METER/M&A Not used even though indicated
LANE KEEP
ECM (l)
ICC SENSOR Signal receiving status from the ICC sensor OK UNKWN
STRG
Not used even though indicated
METER/M&A (l)
ERROR (l)
LANE DETEC-
TOR
TCM (l)
BCM/SEC Signal receiving status from the BCM
OK UNKWN
ITEMCAN DIAG SUP-
PORT MNTR Description Normal
Error
PRSNT PAST PRSNT PAST
ADP TRANSMIT DIAG
Not used even though indicated
METER/M&A Signal receiving status from the combina-
tion meter
OKOK
or
1 – 39
*UNKWN 0
BCM/SEC Signal receiving status from the BCM
TCM Signal receiving status from the TCM
ITEMCAN DIAG SUP-
PORT MNTR Description Normal
Error
PRSNT PAST PRSNT PAST
AV TRANSMIT DIAG Signal transmission status
OKOK
or
1 – 39
*UNKWN 0
ECM
Signal receiving status from the ECM
METER/M&A Signal receiving status from the combina-
tion meter
BCM/SEC Signal receiving status from the BCM
HVAC Signal receiving status from the A/C auto
amp.
STRG Not used even though indicated
IPDM E/R Signal receiving status from the IPDM E/R OK OK
or
1 – 39
*UNKWN 0
TIRE-P Not used even though indicated
Revision: April 20092010 QX56

LAN-50
< FUNCTION DIAGNOSIS >[CAN]
TROUBLE DIAGNOSIS
0: Error at present, 1 – 39: Error in the past (Number m
eans the number of times the ignition switch is turned OFF →ON)
*: 39 or higher number is fixed at 39 until the self-diagnosis result is erased.
Transfer Control Unit
0: Error at present, 1 – 39: Error in the past (Number m eans the number of times the ignition switch is turned OFF →ON)
*: 39 or higher number is fixed at 39 until the self-diagnosis result is erased.
ABS Actuator and Electric Unit (Control Unit)
CAUTION:ITEM
CAN DIAG SUP-
PORT MNTR Description Normal
Error
PRSNT PAST PRSNT PAST
M&A TRANSMIT DIAG Signal transmission status
OKOK
or
1 – 39
*UNKWN 0
ECM
Signal receiving status from the ECM
TCM Signal receiving status from the TCM
BCM/SEC Signal receiving status from the BCM
VDC/TCS/ABS Signal receiving stat
us from the ABS actua-
tor and electric unit (control unit)
IPDM E/R Signal receiving status from the IPDM E/R
DISPLAY Not used even though indicated
I-KEY Signal receiving status from the Intelligent
Key unit
OKOK
or
1 – 39
*UNKWN 0
EPS Not used even though indicated
AWD/4WD
e4WD
ICC Signal receiving status from the ICC unit OK OK
or
1 – 39
*UNKWN 0
LANE CAMERA Not used even though indicated
TIRE-P
ITEM CAN DIAG SUP-
PORT MNTR Description Normal
Error
PRSNT PAST PRSNT PAST
4WD TRANSMIT DIAG Signal transmission status
OKOK
or
1 – 39
*UNKWN 0
ECM
Signal receiving status from the ECM
VDC/TCS/ABS Signal receiving stat
us from the ABS actua-
tor and electric unit (control unit)
TCM Signal receiving status from the TCM
STRG Signal receiving status from the steering an-
gle sensor
ITEMCAN DIAG SUP-
PORT MNTR DescriptionNormal Error
PRSNT
ABS INITIAL DIAG Status of CAN controller
OKNG
Caution
TRANSMIT DIAG Signal transmission status
UNKWN
ECM Signal receiving status from the ECM
TCM Signal receiving status from the TCM
METER/M&A Not used even though indicated
STRG Signal receiving status from the steering angle sensor
OK UNKWN
ICC Signal receiving status from the ICC unit
AWD/4WD Signal receiving status from the transfer control unit
Revision: April 20092010 QX56

LAN-52
< COMPONENT DIAGNOSIS >[CAN]
CAN COMMUNICATION SYSTEM
COMPONENT DIAGNOSIS
CAN COMMUNICATION SYSTEM
Component Parts LocationINFOID:0000000005146466
1. ECM E16
2. IPDM E/R E122 3. ICC sensor E42
4. AV control unit M45 5. Combination meter M246. ABS actuator and electric unit (con-
trol unit) E125
7. Intelligent Key unit M70 8. BCM M189. Data link connector M22
10. Steering angle sensor M17 11. Driver seat control unit B202 12. ICC unit B13
13. Air bag diagnosis sensor unit M35 14. A/T assembly F9 15. A/C auto amp. M50
16. Transfer control unit E142
AWMIA0011ZZ
Revision: April 20092010 QX56

LAN-60
< COMPONENT DIAGNOSIS >[CAN]
MALFUNCTION AREA CHART
MALFUNCTION AREA CHART
Main LineINFOID:0000000005146468
Branch LineINFOID:0000000005146469
Short CircuitINFOID:0000000005146470
Malfunction area
Reference
Main line between TCM and driver seat control unit LAN-61, "
Diagnosis Procedure"
Main line between TCM and ICC sensorLAN-63, "Diagnosis Procedure"
Main line between ICC sensor and ICC unitLAN-64, "Diagnosis Procedure"
Main line between ICC unit and driver seat control unitLAN-65, "Diagnosis Procedure"
Main line between driver seat control unit and AV control unitLAN-66, "Diagnosis Procedure"
Main line between AV control unit and data link connectorLAN-67, "Diagnosis Procedure"
Main line between data link connector and combination meterLAN-68, "Diagnosis Procedure"
Main line between combination meter and ABS actuator and
electric unit (control unit)LAN-69, "Diagnosis Procedure"
Main line between combination meter and transfer control unit
LAN-70, "Diagnosis Procedure"
Main line between transfer control unit and ABS actuator and
electric unit (control unit)LAN-71, "Diagnosis Procedure"
Malfunction area
Reference
ECM branch line circuit LAN-72, "
Diagnosis Procedure"
TCM branch line circuitLAN-73, "Diagnosis Procedure"
ICC sensor branch line circuitLAN-74, "Diagnosis Procedure"
ICC unit branch line circuitLAN-75, "Diagnosis Procedure"
Driver seat control unit branch line circuitLAN-76, "Diagnosis Procedure"
AV control unit branch line circuitLAN-77, "Diagnosis Procedure"
BCM branch line circuitLAN-78, "Diagnosis Procedure"
Data link connector branch line circuitLAN-79, "Diagnosis Procedure"
A/C auto amp. branch line circuitLAN-80, "Diagnosis Procedure"
Intelligent Key unit branch line circuitLAN-81, "Diagnosis Procedure"
Combination meter branch line circuitLAN-82, "Diagnosis Procedure"
Steering angle sensor branch line circuitLAN-83, "Diagnosis Procedure"
Transfer control unit branch line circuitLAN-84, "Diagnosis Procedure"
ABS actuator and electric unit (control unit) branch line circuit LAN-85, "Diagnosis Procedure"
IPDM E/R branch line circuit LAN-86, "Diagnosis Procedure"
Malfunction area Reference
CAN communication circuit LAN-87, "
Diagnosis Procedure"
Revision: April 20092010 QX56

LAN
MAIN LINE BETWEEN TCM AND LASER CIRCUITLAN-63
< COMPONENT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
MAIN LINE BETWEEN TC
M AND LASER CIRCUIT
Diagnosis ProcedureINFOID:0000000005146472
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the following terminals and connectors for damage, bend and loose connection (connector side
and harness side).
- Harness connector F14
- Harness connector E5
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the harness connectors F14 and E5.
2. Check the continuity between the harness connector terminals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair the main line between the A/T assembly and the harness connector F14.
3.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the connector of ICC sensor.
2. Check the continuity between the harness connector and the ICC sensor harness connector.
Is the inspection result normal?
YES (Present error)>>Check the following items again. • Decision of CAN system type.
• Not received CONSULT-III data [SELF-DIAG RESULTS, CAN DIAG SUPPORT MNTR (“ECU
list” included)].
• Procedure for detecting root cause.
YES (Past error)>>Error was detected in the main line between the A/T assembly and the ICC sensor.
NO >> Repair the main line between the harness connector E5 and the ICC sensor.
Connector No. Terminal No. Continuity
F14 35E
xis te d
14 15Existed
Harness connector ICC sensor harness connector
Continuity
Connector No. Terminal No.Connector No. Terminal No.
E5 5
E42 2
Existed
15 3Existed
Revision: April 20092010 QX56
