2010 INFINITI QX56 bluetooth

AV
AV CONTROL UNITAV-145
< ECU DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
Error item Refer to
CAN COMM CIRCUIT [U1000] AV- 4 1
CONTROL UNIT (CAN) [U1010]AV- 4 2
CONTROL UNIT (AV) [U1310]AV- 6 7
Control Unit FLASH-ROM [U1200]AV- 4 3
Gyro NO CONN [U1201]AV- 4 4
CAN CONT [U1216]AV- 4 9
BLUETOOTH CONN [U1217]AV- 5 0
HDD CONN [U1218]AV- 5 1
HDD READ [U1219]AV- 5 2
XM SERIAL COMM [U1220]AV- 5 9
HDD WRITE [U121A]AV- 5 3
HDD COMM [U121B]AV- 5 4
HDD ACCESS [U121C]AV- 5 5
DSP CONN [U121D]AV- 5 6
DSP COMM [U121E]AV- 5 7
INTERNAL COMM [U121F]AV- 5 8
GPS COMM [U1204]AV- 4 5
GPS ROM [U1205]AV- 4 6
GPS RAM [U1206]AV- 4 7
GPS RTC [U1207]AV- 4 8
FRONT DISP CONN [U1243]AV- 6 0
GPS ANTENNA CONN [U1244]AV- 6 2
CAMERA CONT. CONN [U1250]AV- 6 3
XM ANTENNA CONN [U1258]AV- 6 5
• AV COMM CIRCUIT [U1300]
• SWITCHE CONN [U1240]AV- 6 6
• AV COMM CIRCUIT [U1300]
• REAR CAMERA LAN CONN
[U1252] AV- 6 6
Revision: April 20092010 QX56

AV
MICROPHONEAV-187
< ON-VEHICLE REPAIR > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
MICROPHONE
Removal and InstallationINFOID:0000000005146373
REMOVAL
1. Remove the front roof console finisher. Refer to INT-17,
"Removal and Installation".
2. Disconnect the Bluetooth microphone connector (A).
3. Detach the Bluetooth microphone (1) from the front roof console finisher and remove the Bluetooth microphone (1).
INSTALLATION
Installation is in the reverse order of removal.
ALNIA0275ZZALNIA0274ZZ
Revision: April 20092010 QX56
