2010 Hyundai Accent CD player

1
FEATURES OF YOUR HYUNDAI123123123CARE OF DISCSStorage
When not in use, place your discs in
their individual cases and store them in
a cool place away from the sun, heat,
and dust.Do not grip or pull out the disc with your
hand while the disc is being pulled into
the unit by the self loading mechanism.
Keep Your Discs Clean
B850A02F-AAT
Proper Handling
Handle your disc as shown. Do not drop
the disc. Hold the disc so you will not leave fingerprints on the surface. If the
surface is scratched, it may cause the
pickup to skip signal tracks. Do not
affix tape, paper, or gummed labels on the disc. Do not write on the disc.
Damaged Disc
Do not attempt to play damaged, warped or cracked discs. These could severely
damage the playback mechanism. Fingerprints, dust, or soil on the surface
of a disc could cause the pickup to skip
signal tracks. Wipe the surface clean
with a clean soft cloth.If the surface is heavily soiled, dampena clean soft cloth in a solution of mild
neutral detergent to wipe it clean.
B850A01L
B850A02LCARE OF CASSETTE TAPES
B860A01A-AAT
Proper care of your cassette tapes will extend the tape life and increase yourlistening enjoyment. Always protect
your tapes and cassette cases from
direct sunlight, severely cold and dusty
conditions.
When not in use, cassettes shouldalways be stored in the original protec-
tive cassette case. When the vehicle is
very hot or cold, allow the interior tem-
perature to become more comfortable before listening to your cassettes.
oNever leave a cassette inserted in the player when not being played.
This could damage the tape player
unit and the cassette tape.B860A01L

1FEATURES OF YOUR HYUNDAI124
oThe playback head, capstan andpinch rollers will develop a coating of
tape residue that can result in dete-
rioration of sound quality, such as a
wavering sound. They should be
cleaned monthly using a commer- cially available head cleaning tape or
special solution available from audio
specialty shops. Follow the supplier's directions carefully and never oil any
part of the tape player unit.
oAlways be sure that the tape is tightly
wound on its reel before inserting inthe player. Rotate a pencil in the drive sprockets to wind up any slack.
oBe sure that the cassette label is not loose or peeling off or tape ejection
may be difficult.
oNever touch or soil the actual audio tape surfaces.
oKeep all magnetized objects, such
as electric motors, speakers or trans-
formers away from your cassette tapes and tape player unit.
oStore cassettes in a cool, dry place
with the open side facing down toprevent dust from setting in the cas-
sette body.
oWe strongly recommend against the
use of tapes longer than C-60 (60
minutes total). Tapes such as C-120
or C-180 are very thin and do not
perform as well in the automotive
environment. oAvoid repeated fast / reverse usage
to replay one given tune or tape
section. This can cause poor tape
winding to occur, and eventually cause excessive internal drag and
poor audio quality in the cassette. If
this occurs, it can sometimes be
corrected by fast winding the tape
from end to end several times. If this does not correct the problem, do not
continue to use the tape in your
vehicle.
HLC216
Head
Cotton
applicator
B860A01MC
B860A02L

1
FEATURES OF YOUR HYUNDAI125125125
NOTE:
Look at a tape before you insert it. If the tape is loose, tighten it byturning one of the hubs with a pencil
or your finger.
If the label is peeling off, do not put it in the drive mechanism.
Do not leave tapes sitting where they
are exposed to hot, warm, or high humidity, such as on top of the dash- board or in the player.
If a tape is exposed to excessively
hot or cold, let it reach a moderate temperature before putting it in the
player.B860A03LANTENNA
B870D02MC-GAT
MICRO ANTENNA
Your car uses the micro antenna to
receive both AM and FM broadcast
signals.
This antenna is a removable type. OMC025111-1CAUTION:
oBefore entering an automatic car wash, remove by turning the an-
tenna counterclockwise to preventdamage to the micro antenna. To
install the antenna, turn the an-
tenna clockwise.
oBe sure to remove the micro an-
tenna before entering a garage
with a low height or installing a
car cover.!

1FEATURES OF YOUR HYUNDAI
126AUDIO SYSTEM
M420A01MC-GAT STEREO RADIO PLAYER OPERATION (M420) (If Installed)
M420A01MC1. POWER ON-OFF, VOLUME Control
Knob
2. BAND Select Button
3. TUNE/MODE Select Knob
4. AUTO SEEK Select Button
5. Best Station Memory (BSM) Button
6. PRESET Station Select Buttons

1FEATURES OF YOUR HYUNDAI
130
M420D01MC-GAT 1. TAPE PROGRAM Button This allows you to play the reverse side of the tape by merely pressing theprogram button. The PLAY and an ar- row will appear in the display to show tape direction. 2. TAPE EJECT Button
o When the button is pressed with acassette loaded, the cassette will eject.
o When the button is pressed during
FF/REW mode, the cassette willeject.
3. DOLBY Button If you get background noise during tape PLAY, you can reduce this consider- ably by merely pressing the DOLBYbutton. If you want to cancel the DOLBY feature, press the button again. 4. REPEAT (RPT) Button
o To repeat the track you are currently
listening to, press the RPT button. To cancel , press again.
o If you do not release RPT operation
when the track ends, it will automati-cally be replayed. This process will be continued until you push the button again.
5. AUTO MUSIC Search (AMS) Button
Press the button to find the startingpoint of each song in a prerecordedmusic tape. The quiet space between songs (must have at least a 4 sec. gap) can be identified by the AUTO MUSICSearch button.
o Pressing the will play the begin- ning of the next music segment.
o Pressing the will start replay at
the beginning of the music just lis- tened to.
o To stop FF or REW action, press the
button again. 6. FF/REW Button
o Fast forward tape winding starts
when the button is pressed during PLAY or REW mode.
o PLAY starts when the button is
pressed again during FF mode.
o Tape rewinding starts when the button is pressed during PLAY
or FF mode.
o PLAY starts when the button pressed again during REW mode.
! CAUTION:
o Do not insert anything like coins into the player slot as damage to the unit may occur.
o Do not place beverages close to the audio system. The playbackmechanism may be damaged ifyou spill them.
o Do not strike or allow anything to
impact the audio system, damageto the system mechanisms could occur.

1
FEATURES OF YOUR HYUNDAI
131131131131
H446A01MC-GAT STEREO RADIO PLAYER OPERATION (H446) (If Installed)
1. POWER ON-OFF, VOLUMEControl Knob
2. BAND Select Button
3. BEST STATION MEMORY (BSM)
Button
4. EQ Button
5. AUTO SEEK Select Button
6. TUNE (MANUAL), AUDIO Select
Knob
7. PRESET STATION Select Buttons
H446A01MC

1FEATURES OF YOUR HYUNDAI
134
H446C01MC-GAT COMPACT DISC PLAYER OPERATION (H446) (If Installed) - Compatiable with MP3/WMA
1. CD/AUX Select Button
2. TRACK UP/DOWN Button
3. FF/REW Button
4. REPEAT (RPT) Button
5. RANDOM (RDM) Button
6. PAUSE (II) Button
7. SCROLL (SCR) Button
8. EQ Button
9. CD EJECT Button 10. CD SCAN Button11. FILE SEARCH Knob (TUNE Select Knob) 12. DIRECTORY SEARCH Button
H446C01MC

1
FEATURES OF YOUR HYUNDAI
135135135135
H446D01MC-GAT 1. CD Select Button
o Insert the CD with the label facing upward.
o Insert the CD to start CD playback, during radio operation.
o If you press the CD button while a disc is in the CD deck, the CD player will begin playing even if the radio player is being used.
o The CD player can be used when the ignition switch is in either the “ON” or“ACC” position.
o Push the CD button to start CD playback without pushing power ON-OFF control knob. (Only when a CDis in the deck.)
NOTE :
o Do not stick paper or tape etc., on the label side or the recording side of any discs, as it may cause a malfunction.
o The unit can play a multi-session CD-R (recordable CD) and CD-RW(rewritable CD) that consists ofmore than two sessions. Please refer to the manual of CD-R/CD-RW recorder or CD-R/CD-RWsoftware for more information on finalization process.
o Depending on the recording sta-
tus, some CD-Rs/CD-RWs may notbe played on this unit.
o Playback of MP3 and WMA file
formats are supported. Load toplay time for these formats may be longer due to the compressednature of these discs.
AUX Select Button Listening to the external player con- nected to AUX-IN
o Connect the external player to AUX- IN.
o Press CD/AUX button to turn to AUX-
IN.
o You can enjoy the music played in the external player through the auto mobile speaker. NOTE :
o If the AUX device is not connected,
you cannot switch to AUX-IN mode.
o When the AUX device is discon- nected while in AUX-IN mode, the unit automatically switches its mode to last selected mode (CDmode or RADIO mode).
o The quality of sound may be de-
fected or distorted when the unit'sEQ control and AUX device's EQ control are both enabled (not flat). When you want to use the unit'sEQ control feature, disable the AUX device's EQ control feature, and vice versa.
o When using a portable audio de- vice connected to the power out-let, noise may occur during play-back. If this happens, use the power source of the portable audio de- vice.
