2010 HONDA ODYSSEY child restraint

A convenient ref erence to the
sections in this manual.
A quick ref erence to the main
controls in your vehicle.
Explains the purpose of each
instrument panel indicator and gauge,
and how to use the controls on the
dashboard and steering column.ID numbers, dimensions, capacities,
and technical information.
How to order manuals and other
technical literature.
A summary of the inf ormation you
need when you pull up to the f uel
pump.
Important inf ormation about the
proper use and care of your vehicle’s
seat belts, an overview of the
supplemental restraint system, and
valuable inf ormation on how to
protect children with child restraints.
How to operate the heating and
cooling system/climate control
system, the audio system, rear
entertainment and other convenience f eatures.
This section covers several problems
motorists sometimes experience,
and details how to handle them. The maintenance minder shows you
when you need to take your vehicle
to the dealer for maintenance service.
There is also a list of things to check
and instructions on how to check
them. The proper way to start the engine,
shif t the transmission, and park; plus
what you need to know if you’re
planning to tow a trailer. What gasoline to use, how to break-
in your new vehicle, and how to load
luggage and other cargo.
A summary of the warranties
covering your new vehicle, and how
to contact us for any reason. Refer to
your warranty manual f or detailed
inf ormation.
Contents
Your Vehicle at a Glance
Driver and Passenger Saf ety
Instruments and Controls
Features T echnical Inf ormation
Warranty and Customer
Relations
(U.S. and Canada only)
Authorized Manuals
(U.S. only)
Index
Service Inf ormation Summary
T aking Care of the Unexpected Maintenance Driving Bef ore Driving
Overview of Contents
2
——
y
y
(yy
2010 Odyssey

µ
This section gives you important
inf ormation about how to protect
yourself and your passengers. It
shows you how to use seat belts. It
explains how your airbags work. And
it tells you how to properly restrain
inf ants and children in your vehicle.
.........
Important Safety Precautions . 6
.......
Your Vehicle’s Saf ety Features . 7
.......................................
Seat Belts .8
...........................................
Airbags .9
.........
Protecting Adults and Teens . 11
.....
1. Close and Lock the Doors . 11
...........
2. Adjust the Front Seats . 12
............
3. Adjust the Seat-Backs . 13
...
4. Adjust the Head Restraints . 14
5. Fasten and Position the Seat .....................................
Belts .15
6. Maintain a Proper Sitting ................................
Position .18
.....
Advice f or Pregnant Women . 19
...
Additional Safety Precautions . 19Additional Inf ormation About Your
.................................
Seat Belts .21
..
Seat Belt System Components . 21
......................
Lap/Shoulder Belt .22
Automatic Seat Belt .............................
Tensionners .23
...............
Seat Belt Maintenance . 24
Additional Inf ormation About Your .....................................
Airbags . 25
......
Airbag System Components . 25
How Your Front Airbags .........................................
Work .27
...
How Your Side Airbags Work . 31
How Your Side Curtain Airbags .........................................
Work .33
..
How the SRS Indicator Works . 34
How the Side Airbag Of f ......................
Indicator Works .35
How the Passenger Airbag ...............
Of f Indicator Works . 35
.............................
Airbag Service .36
...
Additional Safety Precautions . 37
Protecting Children General ................................
Guidelines .38
All Children Must Be ...............................
Restrained .38 All Children Should Sit in a Back
...........................................
Seat .39
The Passenger’s Front Airbag .........
Can Pose Serious Risks . 39
If You Must Drive with .....................
Several Children .41
If a Child Requires Close ..................................
Attention .41
...
Additional Safety Precautions . 41
Protecting Inf ants and Small ...................................
Children .43
.......................
Protecting Inf ants .43
.........
Protecting Small Children . 44
.....................
Selecting a Child Seat .46
....................
Installing a Child Seat .47
...............................
With LATCH .48
.........
With a Lap/Shoulder Belt . 51
..............................
With a Tether .53
...........
Protecting Larger Children . 56
...............
Checking Seat Belt Fit . 56
..................
Using a Booster Seat . 57
When Can a Larger Child Sit in .........................................
Front .58
...
Additional Safety Precautions . 59
.............
Carbon Monoxide Hazard . 60
...................................
Saf ety Labels .61
Driver and Passenger Saf ety
Driver and Passenger Saf ety
5
——
y
y
(y
y
2010 Odyssey

Your airbag system includes:Two SRS (supplemental restraint
system) f ront airbags. The driver’s
airbag is stored in the center of
the steering wheel; the f ront
passenger’sairbagisstoredinthe
dashboard. Both are marked ‘‘SRS
AIRBAG’’ (see page ).
Two side airbags, one f or the
driver and one f or a f ront
passenger. The airbags are stored
in the outer edges of the seat-
backs. Both are marked ‘‘SIDE
AIRBAG’’ (see page ). Two side curtain airbags, one f or
each side of the vehicle. The
airbags are stored in the ceiling,
above the side windows. The f ront
and rear pillars are marked ‘‘SIDE
CURTAIN AIRBAG’’ (see page
). Sensors that can detect whether
the driver’s seat belt and the f ront
passenger’s seat belt are latched
or unlatched (see page ).
A driver’s seat position sensor that
monitors the distance of the seat
from the front airbag. If the seat is
too f ar f orward, the airbag will
inf late with less f orce (see page
).
Weight sensors that monitor the
weight on the f ront passenger’s
seat. If the weight is about 65 lbs
(29 kg) or less (the weight of an
inf ant or small child), the
passenger’s f ront airbag will be
turned of f (see page ).
Automatic front seat belt
tensioners (see page ).
Sensors that can detect a
moderate to severe front impact,
side impact, or if your vehicle is
about to rollover.
Sensors that can detect whether a
child is in the passenger’s side
airbag path and signal the control
unit to turn the airbag of f (see
page ).
27
23
30
31 33
32 30
21
Additional Inf ormation About Your Airbags
26
——
y
y
(y
y
2010 Odyssey

Whatever type you have, f ollow
the child seat maker’s instructions
f or adjusting or tightening the f it.
Other LATCH-compatible seats have
a f lexible-type connector as shown
above.
Lif t the head restraint (see page
), then route the tether strap
through the legs of the head
restraint, over the seat-back and
through the grab rail.
Attach the tether strap hook to the
anchor, making sure the strap is
not twisted, then tighten the strap
according to the seat maker’s
instructions. If the tether strap is too long and
cannot be tightened f irmly, f ind a
route where the strap can be
tightened securely.
Push and pull the child seat
f orward and f rom side-to-side to
verify that it is secure.
4. 5.
6.
7.
172
CONT INUED
Installing a Child Seat
Driver and Passenger Saf ety
49
ANCHOR TETHER
STRAP HOOK
TETHER STRAP
Flexible type
——
y
y
(yy
2010 Odyssey

With the child seat in the desired
seating position, route the belt
through the child seat according
to the seat maker’s instructions,
then insert the latch plate into the
buckle and remove any slack f rom
the lap portion of the belt.
When not using the LATCH system,
all child seats must be secured to the
vehicle with the lap part of a lap/
shoulder belt.
In addition, the lap/shoulder belts in
all seating positions except the
driver’s have a lockable retractor
that must be activated to secure a
child seat.
If you intend to install a child seat in
the center seating position of the
thirdrow,makesurethedetachable
seat belt is properly installed (see
page ).
Remove the head restraint (see
page ). Make sure the
removed head restraint is secured
in the cargo area. Reinstall the
head restraint when the child seat
is removed.
Followsteps6and7onpage . 1.
4.
5. 4916
172
CONT INUED
Installing a Child Seat
Installing a Child Seat with a L ap/
Shoulder Belt
Driver and Passenger Saf ety
51
TETHER STRAP
HOOK
ANCHOR
——
y

y
(yy
2010 Odyssey

Each second row bucket seat has a
tether anchorage point at the bottom
of the seat-back.Af ter properly securing the child
seat (see page ), lif t the head
restraint, then route the tether
strap over the seat-back and
through the head restraint legs.
A child seat with a tether can be
installed in any seating position in
the second or third row seats.
Since a tether can provide additional
security to the lap/shoulder belt
installation, we recommend using a
tether whenever one is required or
available.
1.51
CONT INUED
Installing a Child Seat with a
TetherSecond Row Inst allat ion
Installing a Child Seat
Driver and Passenger Saf ety
53
TETHER ANCHORAGE POINT TETHER
STRAP
——
y
y
(yy
2010 Odyssey

Remove the head restraint (see
page ). Make sure the
removed head restraint is secured
in the cargo area. Reinstall the
head restraint when the child seat
is removed.
To use the anchor, pull up the
anchor cover.
Slide the anchor cover to open it.
Af ter properly securing the child
seat (see page ), route the
tether strap over the top of the
seat-back.Attach the tether strap hook to the
anchor, making sure the tether
strap is not twisted.
Tighten the strap according to the
seat maker’s instructions.
2.
3. 1.
(Outside seating position) 4. 5.
(Center seating position)
51
172
Installing a Child Seat
Driver and Passenger Saf ety
55
Outside seating position
TETHER STRAP HOOK Center seating position
ANCHOR
TETHER STRAP HOOK
ANCHOR
——
y
y
(yy
2010 Odyssey
