Let the vehicle sit f or a minute.
Open the hood, and check the oil
level (see page ). An engine
very low on oil can lose pressure
during cornering and other driving
maneuvers.
If necessary, add oil to bring the
level back to the full mark on the
dipstick (see page ).
Start the engine, and watch the oil
pressure indicator. If it does not go
out within 10 seconds, turn of f the
engine. There is a mechanical
problem that needs to be repaired
bef ore you can continue driving
(seeon page
).
This indicator should never come on
when the engine is running. If it
starts flashing or stays on, the oil
pressure has dropped very low or
lost pressure. Serious engine
damage is possible, and you should
take immediate action.
You will also see a ‘‘CHECK
ENGINE OIL LEVEL’’ message on
the multi-information display (see
page ). If the charging system indicator
comes on brightly when the engine
is running, the battery is not being
charged.
You will also see a ‘‘CHECK
CHARGING SYSTEM’’ message on
the multi-information display (see
page ).
Immediately turn of f all electrical
accessories. Try not to use other
electrically operated controls such as
the power windows. Keep the engine
running; starting the engine will
discharge the battery rapidly.
Go to a service station or garage
where you can get technical
assistance.
Saf ely pull of f the road and shut
of f the engine. Turn on the hazard
warning lights.
1.
2.
3.
4. 88
88 371
426
486
On Touring models On Touring models
Emergency T owing
L ow Oil Pressure
Indicator
Charging System
Indicator
L ow Oil Pressure Indicator, Charging System Indicator
T aking Care of t he Unexpect ed
477
Running the engine with low oil
pressure can cause serious mechanical
damage almost immediately. Turn of f
the engine as soon as you can saf ely get
the vehicle stopped.
——
y

y
(yy
2010 Odyssey

If the indicator comes on repeatedly,
even though it may turn of f as you
continue driving, have your vehicle
checked by your dealer as soon as
possible.The indicator may also come on with
the ‘‘D’’ indicator.
You will also see a ‘‘CHECK
EMISSION SYSTEM’’ message on
the multi-information display (see
page ).
Your vehicle has certain ‘‘readiness
codes’’ that are part of the on-board
diagnostics f or the emissions
systems. In some states, part of the
emissions testing is to make sure
these codes are set. If they are not
set, the test cannot be completed.To check if they are set, turn the
ignition switch to the ON (II)
position without starting the engine.
The malf unction indicator lamp will
come on f or 20 seconds. If it then
goes of f , the readiness codes are set.
If it blinks 5 times, the readiness
codes are not set. If possible, do not
take your vehicle for a state
emissions test until the readiness
codes are set. Ref er to
f or more inf ormation (see
page ).
If your vehicle’s battery has been
disconnected or gone dead, these
codes are erased. It can take several
days of driving under various
conditions to set the codes again.
If this indicator comes on while
driving, it means one of the engine’s
emissions control systems may have
a problem. Even though you may
f eel no dif f erence in your vehicle’s
perf ormance, continued operation
may cause serious damage.
88
504
On Touring models
Malf unction Indicator L amp, Readiness Codes
Readiness Codes Emissions
Testing
Malf unction Indicator
Lamp
478
If you keep driving with the
malf unction indicator lamp on, you can
damage your vehicle’s emissions
controls and engine. Those repairs may
not be covered by your vehicle’s
warranties.
——
y
y
(yy
2010 Odyssey

The brake system
indicator normally
comesonwhenyou
turn the ignition switch to the ON
(II) position, and as a reminder to
check the parking brake. It will stay
on if you do not f ully release the
parking brake.
If the brake system indicator comes
on while driving, the brake f luid level
is probably low. Press lightly on the
brake pedal to see if it f eels normal.
If it does, check the brake f luid level
thenexttimeyoustopataservice
station (see page ). Slow down by shif ting to a lower
gear, and pull to the side of the road
when it is saf e. Because of the long
distance needed to stop, it is
hazardous to drive the vehicle. You
should have it towed and repaired as
soon as possible (see
on page ).
If the f luid level is low, take your
vehicle to a dealer, and have the
brake system inspected f or leaks or
worn brake pads.
However, if the brake pedal does not
f eel normal, you should take
immediate action. A problem in one
part of the system’s dual circuit
design will still give you braking at
two wheels. You will f eel the brake
pedal go down much f arther bef ore
the vehicle begins to slow down, and
you will have to press harder on the
pedal.
If the ABS indicator and the VSA
indicator come on with the brake
system indicator, have the vehicle
inspected by your dealer
immediately. If you must drive the vehicle a short
distance in this condition, drive
slowly and caref ully.
You will also see a ‘‘CHECK BRAKE
SYSTEM’’ message on the multi-
inf ormation display (see page ).
You will also see a ‘‘BRAKE FLUID
LOW’’ message on the multi-
inf ormation display (see page ).
88 88
435 486
On Touring models
On Touring models
Brake System Indicator
Emergency
Towing
T aking Care of t he Unexpect ed
479
U.S. Canada
——
y
y
(yy
2010 Odyssey

If the replacement fuse of the
same rating blows in a short time,
there is probably a serious
electrical problem with your
vehicle. Leave the blown fuse in
that circuit, and have your vehicle
checked by a qualif ied technician.
If you cannot drive the vehicle
without f ixing the problem, and you
do not have a spare fuse, take a fuse
of the same rating or a lower rating
f rom one of the other circuits. Make
sureyoucandowithoutthatcircuit
temporarily (such as the accessory
power socket or radio).
If you replace the blown f use with a
spare f use that has a lower rating, it
might blow out again. This does not
indicate anything wrong. Replace the
f use with one of the correct rating as
soon as you can.
Look f or a blown wire inside the
fuse.If itisblown,replacethefuse
withoneof thesparefusesof the
same rating or lower. If the driver’s power window f use is
removed, the AUTO f unction of the
driver’s window will be disabled. You
should reset the AUTO f eature, (see
page ).
If the radio f use is removed, the
audio system will disable itself . The
nexttimeyouturnontheradioyou
will see ‘‘CODE’’ in the f requency
display. Use the preset buttons to
enter the f ive-digit code (see page
).
5. 6.
187
284
On EX, EX-L and Touring models
Fuses
482
BLOWN
Replacing a f use with one that has a
higher rating greatly increases the
chances of damaging the electrical
system. If you do not have a
replacement f use with the proper
rating f or the circuit, install one with
a lower rating.
——
y
y
(yy
2010 Odyssey

µ
Always check the TPMS malf unction
telltale af ter replacing one or more
tires or wheels on your vehicle to
ensure that the replacement or
alternate tires and wheels allow the
TPMS to continue to f unction
properly.
TPMS malf unctions may occur f or a
variety of reasons, including the
installation of replacement or
alternate tires or wheels on the
vehicle that prevent the TPMS f rom
f unctioning properly. When the malf unction indicator is
illuminated,
the system may not be able to detect
or signal low tire pressure as
intended. Your vehicle has also been equipped
with a TPMS malf unction indicator
to indicate when the system is not
operating properly. The TPMS
malf unction indicator is provided by
a separate telltale, which displays the
symbol ‘‘TPMS’’ when illuminated.Except Touring models
Tire Pressure Monitoring System (TPMS) Required Federal Explanation
Technical Inf ormation
499
——
y

y
(yy
2010 Odyssey

Locks.....
Anti-thef t Steering Column . 144
............................
Fuel Fill Door .369
..................................
Glove Box .201
..................
Lockout Prevention . 151
...............................
Power Door .151
.............................
Sliding Doors .161
......................................
Tailgate .157
........................
Low Coolant Level .372
.........................
Low Fuel Indicator .74
...
Low Oil Pressure Indicator . 67, 477
.........................
Lower Anchors .48, 50
..........................
Lower Glove Box .201
...
Lubricant Specif ications Chart . 492
...........
Luggage, Storing (Cargo) . 378...................
Neutral Gear Position . 387
..................
New Vehicle Break-in . 368
...................
NOTICE, Explanation of . i
...............
Numbers, Identif ication . 490
...
Octane Requirement, Gasoline . 368
...................................
Odometer .78, 85
.........................
Odometer, Trip .78, 86
Oil ........................
Change, How to .428
......................
Change, When to .415
......................
Checking Engine .371
..............
Pressure Indicator . 67,477 Selecting Proper Viscosity
......................................
Chart .427
.........
ON (Ignition Key Position) . 144
Onboard Ref ueling Vapor ....................................
Recovery .501
............................
Outside Mirrors .191
....................
Overheating, Engine .475
.......
Owner Maintenance Checks . 423
.........................
Oxygenated Fuels .368
............
Panel Brightness Control . 139
........................
Park Gear Position .387
...........................................
Parking .390
...............................
Parking Brake .192
Parking Brake and Brake .................
System Indicator . 69,479
...............................
Parking Lights .136
................
Parking Sensor System . 361
..
Parking Over Things that Burn . 390
....
Passenger Airbag Of f Indicator . 35
.............................
PGM-FI System .502
........................
Power Door Locks .151
..................................
Maintenance .413
........................................
Minder .415
.........................
Minder Indicator .76
...
Owner Maintenance Checks . 423
..........................................
Saf ety .414
.
Malf unction Indicator Lamp . 67,478
...................
Manual Sliding Doors . 161
...............................
Meters, Gauges .77 ........................
Mirrors, Adjusting .190
.................................
Modif ications .376
...............
Modif ying Your Vehicle . 377
.......................................
Moonroof .189
Moving the Second Row Bucket .............................................
Seat .175
.............
Multi-Inf ormation Display . 81
