2010 HONDA INSIGHT Owners Manual

If the passenger’s front airbag
inf lates in a moderate to severe
f rontal collision, the airbag can cause
serious injuries to a child who is
unrestrained, improperly restrained,
sitting too close to the airbag, or out
of position.
A side airbag also poses risks. If any
part of a larger child’s body is in the
path of a deploying side airbag, the
child could receive possibly serious
injuries.Physically, a child must be large
enough f or the lap/shoulder belt to
properly f it (see pages and ). If
the seat belt does not f it properly,
with or without the child sitting on a
booster seat, the child should not sit
in f ront.
To saf ely ride in f ront, a child must
be able to f ollow the rules, including
sitting properly, and wearing the seat
belt properly throughout a ride.If you decide that a child can saf ely
ride up f ront, be sure to:
Caref ully read the owner’s manual,
and make sure you understand all
seat belt instructions and all saf ety
inf ormation.
Move the vehicle seat to the rear-
most position.
Have the child sit up straight, back
against the seat, and feet on or
near the f loor.
Check that the child’s seat belt is
properly and securely positioned.
Of course, children vary widely. And
while age may be one indicator of
when a child can saf ely ride in f ront,
there are other important f actors you
should consider.
The National Highway Traffic Safety
Administration and Transport
Canada recommend that all children
age 12 and under be properly
restrained in a back seat.
Supervise the child. Even mature
children sometimes need to be
reminded to f asten the seat belts
or sit properly.
17 52
When Can a L arger Child Sit in
Front
Physical Size
Maturity
Protecting L arger Children
54
—
—y

y
)"yy
2010 Insight

This could result
in serious neck injuries during a
crash.
This could
cause very serious injuries during
a crash. It also increases the
chance that the child will slide
under the belt in a crash and be
injured.
If they do, they
could be very seriously injured in a
crash. Devices intended to
improve a child’s comf ort or
reposition the shoulder part of a
seat belt can make the belt less
ef f ective and increase the chance
of serious injury in a crash.
Additional Saf ety Precautions
Do not let a child wear a seat belt
across t he neck.
Do not let a child put the shoulderpart of a seat belt behind t he backor under t he arm.
T wo children should never use thesame seat belt . Do not put any accessories on a
seat belt.
Protecting L arger Children
Driver and Passenger Saf ety
55
—
—y

y
)"yy
2010 Insight

Your vehicle’s exhaust contains
carbon monoxide gas. Carbon
monoxide should not enter the
vehicle in normal driving if you
maintain your vehicle properly and
f ollow the inf ormation on this page.High levels of carbon monoxide can
collect rapidly in enclosed areas,
such as a garage. Do not run the
engine with the garage door closed.
Even with the door open, run the
engine only long enough to move the
vehicle out of the garage.If you must sit in your parked vehicle
with the engine running, even in an
unconf ined area, adjust the heating
and cooling system as f ollows:
The vehicle is raised f or an oil
change.
Have the exhaust system inspected
f or leaks whenever:
You notice a change in the sound
of the exhaust.
The vehicle was in a collision that
may have damaged the underside. Select the f resh air mode.
Select the mode.
Set the f an speed to high.
Set the temperature control to a
comfortable setting.
With the hatch open, airflow can pull
exhaust gas into your vehicle’s
interior and create a hazardous
condition. If you must drive with the
hatch open, open all the windows,
and set the climate control system as
shown below.
1.
2.
3.
4.
Carbon Monoxide Hazard
56
Carbon monoxide gas is toxic.
Breathing it can cause
unconsciousness and even kill
you.
Avoid any enclosed areas or
activities that expose you to
carbon monoxide.
—
—y

y
)"y
y
2010 Insight

These labels are in the locations
shown. They warn you of potential
hazards that could cause serious
injury or death. Read these labels
caref ully.
If a label comes of f or becomes hard
to read (except for the U.S.
dashboard label which may be
removed by the owner), contact your
dealer f or a replacement.
CONT INUED
U.S. modelsCanadian models
U.S. models only
Saf ety L abels
Driver and Passenger Saf ety
57
DASHBOARD
RADIATOR CAP SUN VISORS
—
—y

y
)"yy
2010 Insight

U.S. modelsCanadian models
Saf ety L abels
58
DOORJAMBS
—
—y


y
)"yy
2010 Insight

This section gives inf ormation about
the controls and displays that
contribute to the daily operation of
your vehicle. All the essential
controls are within easy reach............................
Control Locations . 60
............................
Instrument Panel . 61
..........
Instrument Panel Indicators . 62
.............................................
Gauges . 72
.............
Multi-Inf ormation Display . 75
Controls Near the Steering .........................................
Wheel .116
Windshield Wipers and .....................................
Washers .117
.......
Turn Signals and Headlights . 118
.........
Daytime Running Lights . 120
......
Instrument Panel Brightness . 121
...............
Hazard Warning Button . 122
...............
Rear Window Def ogger . 123
...................................
Econ Button .124
......
Steering Wheel Adjustments . 125
.............................
Keys and Locks .126
......................
Immobilizer System .127
..............................
Ignition Switch .128
....................................
Door Locks .130
............
Childproof Door Locks . 131
.....................
Remote Transmitter .132
..............................................
Hatch .136
................
Unlocking the Hatch . 137
...............................................
Seats .138
...........
Front Seat Adjustments . 138Driver’s Seat Height
............................
Adjustment .138
........................
Head Restraints .139
.
Folding the Rear Seats Down . 142
......................................
Armrest .143
...........................................
Mirrors .144
..
Adjusting the Power Mirrors . 144
..............
Power Mirror Heaters . 145
............................
Power Windows .146
...............................
Parking Brake .148
.........
Interior Convenience Items . 149
.....................
Cargo Area Cover .150
...............
Under Floor Storages . 152
...
Floor Storage Compartment . 152
.....................
Beverage Holders .153
........
Accessory Power Sockets . 153
.............
Console Compartment . 154
..................................
Glove Box .154
...............................
Center Tray .155
..........................
Center Pockets .155
..................................
Coat Hook .156
..................................
Sun Visors .156
............................
Vanity Mirror .156
...............................
Interior Lights .157
Instruments and Controls
Inst rument s and Cont rols
59
—
—y


y
)"yy
2010 Insight

Î
ÎÎÎ
If equipped
:
Control L ocations
60
POWER WINDOW
SWITCHES
DOOR LOCK TAB
GAUGES
POWER DOOR LOCK
MASTER SWITCH HAZARD WARNING
BUTTON
CLIMATE CONTROL
SYSTEMPARKING BRAKE LEVER
ECON BUTTON
HOOD RELEASE HANDLE PADDLE SHIFTERSUSB ADAPTER CABLE
MULTI-INFORMATION
DISPLAY
(P.287) (P.316) (P.
311 )
(P.
160 )
(P.35
)
PASSENGER AIRBAG
OFF INDICATOR
(P.72)
INSTRUMENT PANEL INDICATORS (P.62)
(P.124)
(P.130)
(P.130)
(P.146)
(P.183,191)(P.
148 )
(P.122)
(P
.72, 75)
AUDIO SYSTEM
(P.166,198)
NAVIGATION SYSTEM
AUTOMATIC
TRANSMISSION (CVT)
Model with navigation system is shown.
—
—y

y
)"yy
2010 Insight

ÎÎ
Î
Î
Î
The U.S. instrument panel is shown. Dif f erences f or the Canadian models are noted in the text.
Instrument Panel
Inst rument s and Cont rols
61
SECURITY SYSTEM INDICATOR LIGHTS ON INDICATOR
SEAT BELT REMINDER
INDICATOR ANTI-LOCK BRAKE SYSTEM
(ABS) INDICATOR
SUPPLEMENTAL RESTRAINT
SYSTEM (SRS) INDICATOR
SYSTEM MESSAGE
INDICATOR
BRAKE SYSTEM INDICATOR
(AMBER)
VSA OFF INDICATOR
MALFUNCTION
INDICATOR LAMP PARKING BRAKE AND
BRAKE SYSTEM
INDICATOR (RED)
DOOR/HATCH OPEN
INDICATOR
SIDE AIRBAG OFF
INDICATOR
VEHICLE STABILITY ASSIST
(VSA) SYSTEM INDICATOR
IMMOBILIZER
SYSTEM INDICATOR
IMA SYSTEM
INDICATOR HIGH BEAM
INDICATOR
ELECTRIC POWER STEERING
INDICATOR
(P.64)
(P.65, 332)
(P .63)
(P.66)
(P.62, 403)
(P.63,402)
: If equipped (P.62)(P.64)
(P.63,
404) (P.65)
(P.68)
(P.68)
(P.
69)
(P.64)
(P.69)
HIGH TEMPERATURE INDICATOR (P
.67)
LOW TEMPERATURE INDICATOR (P.67)
(P.70)
(P .66) CRUISE MAIN INDICATOR (P.69)
CRUISE CONTROL INDICATOR (P.69)
LOW OIL PRESSURE
INDICATOR
(P.62,401)
LOW TIRE PRESSURE/
TPMS INDICATOR
12 VOLT BATTERY
CHARGING SYSTEM
INDICATOR (P.70)
ECON MODE INDICATOR (P.71)
(P.70)
AUTO IDLE STOP INDICATOR
LOW FUEL INDICATOR
(P.65,
332)
(P.66, 321, 322)
—
