2010 HONDA INSIGHT CD player

The climate control system in your
vehicle provides a comfortable
driving environment in all weather
conditions.
The standard audio system has
many f eatures. This section
describes those f eatures and how to
use them.
Your vehicle has an anti-theft audio
system that requires a code number
to enable it.
The security system helps to dis-
courage vandalism and thef t of your
vehicle................
Climate Control System . 160
Playing the FM/AM Radio (Models without navigation ..................................
system) .166
Playing a Disc (Models without ...................
navigation system) . 173
Disc Player Error Messages (Models without navigation ..................................
system) .180
PlayinganiPod
(Models without ...................
navigation system) . 181
iPod
Error Messages (Models .....
without navigation system) . 187
Playing a USB Flash Memory Device (Models without ...............
navigation system) . 188
USB Flash Memory Device Error Messages (Models without ...............
navigation system) . 197
Playing the AM/FM Radio (Models with navigation ..................................
system) .198
Playing a Disc (Models with ...................
navigation system) . 204Disc Player Error Messages
(Models with navigation ..................................
system) .214
Playing a PC card (Models with ...............
navigation system) . 215
...
PC Card Player Malf unction . 228
PlayinganiPod
(Models with ...................
navigation system) . 229
iPod
Error Messages (Models ...........
with navigation system) . 236
Playing a USB Flash Memory Device (Models with ...............
navigation system) . 237
USB Flash Memory Device Error Messages (Models with ...............
navigation system) . 245
............
AM/FM Radio Reception . 246
..................
Protecting Your Discs . 248
................
Remote Audio Controls . 251
......................
Auxiliary Input Jack .252
.................
Radio Thef t Protection . 253
..........................
Setting the Clock .254
............................
Security System .255
...............................
Cruise Control .256
.......
Bluetooth
HandsFreeLink. 259
Features
Features
159
—
—y

y
)"y
y
2010 Insight

You operate the in-dash disc player
with the same controls used for the
radio. To select the disc player, press
the CD button. You will see ‘‘CD’’ in
the display. The f older or track
numbers are shown in the display.
You can also select the displayed
inf ormation with the TITLE button
(see page ). The system will
continuously play a disc until you
change modes.This audio system can also play
CD-Rs and CD-RWs compressed in
MP3 or WMA f ormats. The numbers
of the f older and track playing are
showninthedisplayonthedisc
player. A disc can support more than
99 folders, and each folder can hold
more than 255 playable f iles. A disc
canholdupto999filesintotal.
When there are more than 99 f olders
in a disc, the audio display only
shows two digits.If a f ile on a WMA disc is protected
by digital rights management
(DRM), the audio unit displays
UNSUPPORTED, and then skips to
the next f ile.
If you have a disc that is a
combination of CD-DA tracks and
MP3/WMA f iles, you can choose the
f ormat to listen by pressing the CD
button.
Video CDs and DVDs will not work
in this unit.
A disc compressed in AAC f ormat
cannot be played in this audio
system.
176
Playing a Disc (Models without navigation system)
To Play a Disc
174
NOTE:
Do not use discs with adhesive labels.
The label can curl up and cause the
disc to jam in the unit.
—
—y

y
)"y
y
2010 Insight

µ
µ
µ
µµ
µ
µ
µ
CONT INUED
The specif ications f or compatible
MP3 f iles are:
Sampling f requency:
32/44.1/48 kHz (MPEG1)
16/22.05/24 kHz (MPEG2)
Bitrate:
32/40/48/56/64/80/96/112/128/
160/192/224/256/320 kbps
(MPEG1)
8/16/24/32/40/48/56/64/80/96/
112/128/160 kbps (MPEG2)
Compatible with variable bitrate
and multi-session
Number of layers
(including ROOT): Over 8 layers Insert a disc about half way into the
disc slot. The drive will pull the disc
intherestof thewaytoplayit.You
operate the disc player with the
same controls used f or the radio.
The number of the current track is
showninthedisplay.Whenplayinga
disc in MP3 or WMA, the numbers
of the current f older and f ile are
shown. The system will continuously
play a disc until you change modes.
You cannot load and play 3-inch
(8-cm)discsinthissystem.
For inf ormation on how to handle
and protect compact discs, see page
.
The specif ications f or compatible
WMA f iles are:
Compatible with variable bitrate
and multi-session Sampling f requency:
32/44.1/48 kHz
Bitrate:
48/64/80/96/128/160/192 kbps
Number of layers
(including ROOT): Over 8 layers
248
Playing a Disc (Models without navigation system)
To Load a Disc
Features
175
—
—y


y
)"y
y
2010 Insight

µ
If youpressandholdtheTITLE
button again, the display shows the
f irst 15 characters again.
If any letter is not available, it is
replaced with ‘‘ . ’’ (dot) in the display.
When the disc has no text data, you
will see ‘‘NO INFO’’ on the display.
You will also see some text data
under these conditions: When you turn on the audio system
next time, the system keeps your
selection with the TITLE button.
When a new f older, f ile, or track is
selected.
When you change the audio mode
to play a disc with text data or in
MP3 or WMA.
When you insert a disc, and the
system begins to play.
When playing a CD-DA with text
data, the album and track name are
showninthedisplay.Withadiscin
MP3 or WMA, the display shows the
f older and f ile name. In MP3/WMA mode, use the
or button to select
f olders in the disc, and use the SEEK
button to change f iles. Each time you
press and release the side, the
player skips f orward to the
beginning of the next track (f iles in
MP3/WMA mode). Press and
release the side to skip
backward to the beginning of the
current track. Press it again to skip
to the beginning of the previous
track.
To move rapidly within a track, press
andholdthe ,orthe button.
You can also operate the track
selection by using the VOL/SELECT
knob. Press the VOL/SELECT knob
and you will see ‘‘SEL’’ in the display.
Turn the knob to switch the track
number. Press the VOL/SELECT
knob or button to set your
selection. To turn it of f , press the button.
You can use the SEEK button while
a disc is playing to change tracks
(f iles in MP3/WMA mode).
CONT INUED
T o Change or Select T racks/Files
SEEK /SK IP
Playing a Disc (Models without navigation system)
Features
177
—
—y


y
)"y
y
2010 Insight

Thechartontherightexplainsthe
error messages you may see in the
display while playing a disc.
If you see an error message in the
display while playing a disc, press
the eject button. After ejecting the
disc, check it for damage or
deformation. If there is no damage,
insert the disc again.
Theaudiosystemwilltrytoplaythe
disc. If there is still a problem, the
error message will reappear. Press
the eject button, and pull out the disc. For the additional information on
damaged discs, see page .
Insert a dif f erent disc. If the new
disc plays, there is a problem with
the f irst disc. If the error message
cycle repeats and you cannot clear it,
take your vehicle to a dealer.Cause
Solution
Error
Message
249
Track/File format not
supported
Mechanical Error
FOCUS Error
TOC Error Current track will be skipped. The next
supported track or file plays automatically.
Press the EJECT button and pull out the disc.
Check the disc for serious damage, signs of
deformation, excessive scratches, and/or dirt
(see page
249). Insert the disc again. If the code
does not disappear, or the disc cannot be
removed, consult your dealer. Do not try to
force the disc out of the player.
Press the EJECT button and pull out the disc.
Check if it is inserted correctly in the disc
player.
Make sure the disc is not scratched or damaged.
For more information, see page 249.
Disc Player Error Messages (Models without navigation system)
180
UNSUPPORTED
BAD DISC
PLEASE CHECK OWNERS
MANUAL
PUSH EJECT
CHECK DISC
—
—y

y
)"y
y
2010 Insight

Do not connect your iPod using a
hub.
DonotkeeptheiPodinthe
vehicle. Direct sunlight and high
heat will damage it.
Do not use an extension cable
between the USB adapter cable
equipped with your vehicle and
your dock connector.
We recommend backing up your
data bef ore playing it.
iPods compatible with your audio
system using the USB adapter cable
are:
UseonlycompatibleiPodswiththe
latest sof tware. iPods that are not
compatible will not work in this audio
unit.
iPod and iTunes are registered
trademarks owned by Apple Inc. The system will only play songs
stored on the iPod with iTunes. This audio system can play the audio
f iles on the iPod
with the same
controls used f or the in-dash disc
player. To play an iPod, connect it to
the USB adapter cable in the console
compartment by using your dock
connector, then press the AUX
button. The ignition switch must be
in the ACCESSORY (I) or ON (II)
position. The iPod will also be
recharged with the ignition switch in
these positions.Sof tware
Ver. 1.2 or more
Ver. 1.0 or more
Ver. 1.2 or more
Ver. 1.1.2 or more
Ver. 1.0 or more
Ver. 1.1.1 or more
Ver. 1.1.1 or more
Model
iPod Classic
5 Gen.
(2005 or later)
iPod Classic
(2007 or later)
iPod nano
iPod nano 2
generation
iPod nano 3
generation
iPod touch
iPhone
th
nd
rd
EX model
To Play an iPod
Playing an iPod(Models without navigation system)
182
NOTE:
—
—y


y
)"y
y
2010 Insight

Î
ÎSome USB f lash memory devices
(such as devices with security lock-
out f eatures, etc.) will not work in
this audio unit.
Do not use a device such as a card
reader or hard drive as the device
or your f iles may be damaged.
Do not connect your USB f lash
memory device using a hub.
Do not use an extension cable to
the USB adapter cable equipped
with your vehicle.
Do not keep a USB f lash memory
device in the vehicle. Direct
sunlight and high heat will damage
it. We recommend backing up your
data bef ore playing a USB f lash
memory device.
Depending on the type and
number of f iles, it may take some
time bef ore they begin to play.
Depending on the sof tware the
f iles were made with, it may not be
possible to play some f iles, or
displaysometextdata.
The recommended USB f lash
memory devices are 256 MB or
higher. Some digital audio players
maybecompatibleaswell.
Only AAC f ormat f iles recorded
with iTunes are playable on this
audio unit.
The audio system reads and plays
the audio f iles on the USB f lash
memory device in MP3, WMA or
AAC f ormats. Depending on the
f ormat, the display shows MP3,
WMA or AAC when a USB flash
memory device is playing. The USB
f lash memory device limit is up to
700 f olders or up to 65535 f iles. This audio system can operate the
audio f iles on a USB f lash memory
device with the same controls used
f or the in-dash disc player. To play a
USB f lash memory device, connect it
to the USB adapter cable in the
console compartment, then press the
AUX button.
:
CONT INUED
EX model
To Play a USB Flash Memory
Device
Playing a USB Flash Memory Device (Models without navigation system)
Features
189
NOTE:
—
—y


y
)"y
y
2010 Insight

You operate the in-dash disc player
with the same controls used for the
radio.This audio system can also play CD-
RsandCD-RWscompressedinMP3
or WMA f ormats. When playing a
disc in MP3, you will see ‘‘MP3’’ on
the screen. In WMA f ormat, ‘‘WMA’’
will appear on the screen. You can
select up to 255 f olders and play up
to 999 tracks. If the disc has a
complex structure, it takes a while to
readthediscbeforethesystem
begins to play it.If you have a disc that is a
combination of CD-DA tracks and
MP3/WMA f iles, you can choose the
f ormat to listen to by pressing and
holding the CD/AUX button.
Video CDs and DVD discs will not
work in this unit.
A disc compressed in AAC f ormat
cannot be played in this audio
system.
CONT INUED
Playing a Disc (Models with navigation system)
To Play a Disc
(In-dash single player)
Features
205
Do not use discs with adhesive labels.
The label can curl up and cause the
disc to jam in the unit.
—
—y

y
)"y
y
2010 Insight
