•Longer, cast aluminum lower control arms
•Longer, forged steel upper control arms
•Front coil springs and rear leaf springs
•Fox Racing 47mm piston internal bypass front shocks
•Fox Racing 47mm pistons, internal bypass, remote reservoir rear
shocks
•Micro-cellular urethane jounce bumpers (front and rear)
•Raptor navigation welcome screen
•17” cast aluminum wheels and 315/70-17 BFGoodrichall-terrain tires
•Full size all-terrain spare tire
•Off-road specific calibrations for engine, transmission and
AdvanceTractraction control system
•Instrument panel cluster graphics
•Steering wheel - unique wrap with on-center marker, thumb pads, and
improved grip contour
•Door trim inserts and center stack trim
•Off-road style floor mats with SVT logo
F-150 SVT Raptor specific features
5
2010 F-150(f12)
Supplement, 1st Printing
USA(fus)

OFF-ROAD MODE
Off-road mode allows you to change the operating characteristics of the
following features to allow for better off-road performance:
•Transmission shifting and response
•Electronic locking differential
•AdvanceTrac(ABS, RSC, Traction Control)
ENABLING OFF-ROAD MODE
With the vehicle traveling less than
5 mph (8 km/h) and your foot off of
the accelerator pedal, press this
button to turn on off-road mode. A
chime will sound and a message will
display indicating that off-road mode
is active. If any of the conditions are
not met, the message center will
display the appropriate messages to guide the driver through the proper
operating procedures. SeeMessage centerin your owner’s guide for
more information.
Press the button again to turn it off.
WARNING:Off-road mode is specifically calibrated for off-road
driving conditions and should never be used on pavement.
With this mode enabled, the operating characteristics of the following
features will be altered:
•Transmission shifting and response–Transmission upshifts are
delayed and occur less frequently. This ensures the best possible
vehicle response and acceleration if the driver needs to briefly lift off
of the throttle to negotiate an obstacle or corner.
•Electronic locking differential (ELD)–If engaged, the ELD will
remain locked until the operator manually disengages it with the
control knob, or disengages off-road mode and exceeds the standard
ELD speed thresholds. SeeElectronic locking differentialin your
owner’s guide for more information.
•AdvanceTrac–When off-road mode is engaged, the AdvanceTrac
settings are altered for optimized off-road performance.
•Tow/haul mode –If tow/haul mode is active, it will be disabled. Also,
you cannot select tow/haul mode when off-road mode is on. As the
SVT Raptor is primarily a performance vehicle, off-road mode takes
priority over tow/haul mode.
Driving
10
2010 F-150(f12)
Supplement, 1st Printing
USA(fus)

ADVANCETRACMODES
The AdvanceTracsystem, when used with off-road mode, provides the
SVT Raptor with alternative AdvanceTraccalibrations which improve
off-road performance.
With off-road mode on, the following changes to AdvanceTracwill
occur:
•Pressing the AdvanceTracbutton once–This places the vehicle
in the off-road sport mode with the ESC, RSC and ABS active. TCS
and ESC are altered to allow for more tire spin and vehicle slip. It also
puts the ABS in a unique off-road mode calibration.
Note:Operating the vehicle in this mode does not guarantee that the
vehicle will not become stuck in sand, snow or mud, etc. It is the
driver’s responsibility to assess off-road situations and determine if the
terrain is passable.
•Pressing and holding the AdvanceTracbutton–This places the
vehicle in the off-road sport mode with the ESC, RSC, and traction
control systems disabled and also puts the ABS in a unique off-road
mode calibration. In addition to the benefits of disabling traction
control as described previously, disabling the RSC system allows for
more “spirited” off-road driving maneuvers.
The ABS off-road mode desensitizes the ABS. This helps on very
rough terrain/adverse driving where the ABS may become too active
and hinder the type of driving required in off-road situations.
Note:When off-road mode is on, pressing the AdvanceTracbutton will
change the ABS to an off-road specific calibration.
For more information on the AdvanceTracand its operation, see
AdvanceTracwith Roll Stability Control™ (RSC) Stability
Enhancement Systemin theDrivingsection of your owner’s guide.
HILL DESCENT MODE
Hill descent allows the driver to set and maintain vehicle speed while
descending steep grades regardless of surface conditions. Refer to the
Message centerin your F-150 owner guide for hill-descent related
messages.
Hill descent control can maintain vehicle speeds on downhill grades
between 2 and 20 mph (3 and 32 km/h). Between 20 and 40 mph (32
and 64 km/h), the system remains armed, but descent speed cannot be
set or maintained. If vehicle speed is above 40 mph (64 km/h), the
system is disabled. After this point, vehicle speed must drop below
40 mph (64 km/h), and the hill descent control button must be pressed
again to engage the feature.
Driving
11
2010 F-150(f12)
Supplement, 1st Printing
USA(fus)

DRIVING YOUR F-150 SVT RAPTOR OFF-ROAD
In addition to providing an excellent on-road driving experience, the
F-150 SVT Raptor excels at all types of off-road driving. The truck has
been designed and equipped to allow you to explore those places where
the road doesn’t take you whether it’s a forest trail or the open desert.
Before going off-roading, consult with your local governmental agencies
to determine designated off-road trails and recreation areas. Also, be
sure to understand any off-road vehicle registration requirements for the
area in which you plan on driving.
Tread Lightlyis an educational program designed to increase public
awareness of land-use regulations and responsibilities in our nation’s
wilderness areas. Ford joins the U.S. Forest Service and Bureau of Land
Management in encouraging you to help preserve our national forest and
other public and private lands by treading lightly.
Before taking your F-150 SVT Raptor off-roading, a basic vehicle
inspection should be done to ensure that the vehicle is in top working
condition.
It is always recommended that at least two vehicles are used while
off-roading. The “buddy system” helps ensure that help is close at hand
should a vehicle become stuck or damaged. It is also wise to take
supplies such as a first aid kit, supply of water, tow strap, cell or satellite
phone with you any time an off-road excursion is planned.
WARNING: Off-roading can be extremely dangerous and carries
inherent risks that may not be preventable even with the best
precautions. Ford strongly recommends driving within your ability and
taking every safety precaution, including those found here and at other
off-road driving organizations such as the Best in the Desert Racing
(www.bitd.com) and SCORE International Off Road Racing.
Basic off-road driving techniques
• Grip the steering wheel with thumbs on the outside of the rim. This
will reduce the risk of injury due to abrupt steering wheel motions
that occur when negotiating rough terrain. Do not grip the steering
wheel with thumbs inside the rim.
• Throttle, brake and steering inputs should be made in a smooth and
controlled manner. Sudden inputs to the controls can cause loss of
traction or “upset” the vehicle, especially while on sloped terrain or
while crossing obstacles such as rocks or logs.
• Look ahead on your route noting upcoming obstacles, surface texture
or color changes or any other factors which may indicate a change in
available traction, and adjust the vehicle speed and route accordingly.
Driving
14
2010 F-150 (f12)
Supplement, 1st Printing
USA (fus)

•Always keep available ground clearance in mind and pick a route that
minimizes the risk of catching the underside of the vehicle on an
obstacle.
• When negotiating low speed obstacles, applying light brake pressure in
conjunction with the throttle will help prevent the vehicle from jerking
and will allow you to negotiate the obstacle in a more controlled
manner. Using 4L will also help with this.
• Use and equip supplemental safety equipment as discussed later in
this chapter.
• Please consult your local off-road group for other helpful tips.
• Off-roading requires a high degree of concentration. Even if your local
law does not prohibit alcohol use while driving off-road, Ford strongly
recommends against drinking if you plan to off-road.
Driving in mud
• Deep mud should be approached with caution especially if you are
driving in an unfamiliar area.
• If possible, test the depth of a mud hole before entering with the
vehicle.
• Keep in mind that obstacles and deep ruts may be hidden beneath the
surface of the mud.
• Proceed in a steady, controlled manner through deep mud while
maintaining momentum.
• If momentum is lost and you feel the vehicle becoming stuck, turning
the steering wheel back and forth (“sawing the wheel”)
14turn in
each direction may give the traction you need to clear the muddy
area.
• In higher speed areas with shallow mud, directional control will be
reduced in the muddy area much like on snow or ice. When
approaching such an area, be sure to slow to a speed which allows you
to maneuver as required by the conditions.
Driving in sand
WARNING: Tires must be returned to normal recommended tire
pressures before driving on pavement or hard surfaces. Failure
to properly maintain your tire pressure could increase the risk of tire
failure, loss of control, vehicle rollover and personal injury.
Driving
15
