Page 97 of 257

Auxiliary socket
The auxiliary socket is located in the " AUX "box on the centre console. It permits the connection of a por table device, such as a digital audio player of the iPod ® type, to listen to your music files using the vehicle's speakers.
USB Player
For more information on the use of this equipment, refer to the MyWay or Audio system
par t of the "Audio and Telematics" section.
When it is in use, the por table device charges automatically.
The USB por t is located in the "AUX" box on the centre console. It permits the connection of a por table device, such as a digital audio player of the iPod ®
generation 5 and later type or USB memory stick type. It reads the audio file formats (mp3, ogg, wma, wav...) which are transmitted to your audio equipment and played via the vehicle's speakers. You can manage these files using the steering mounted controls or the audio equipment control panel and display them on the multifunction screen.
For more information on the use of this equipment, refer to the Audio system par t of the "Audio and Telematics" section.
12 V accessory
socket
To connect a 12 V accessory (max power: 120 W), lift the cover and connect a suitable adaptor.
The management of the files is done using your por table device.
Page 98 of 257
Fittings
Mats
Removable carpet protection.
When fitting the mat for the first time, on the driver's side use only the fixings provided in the wallet attached. The other mats are simply placed on the carpet.
Fitting Removal
To remove the mat on the driver's side: move the seat as far back as possible,
unclip the fixings, remove the mat.
Refitting
To refit the mat on the driver's side: position the mat correctly, refit the fixings by pressing, check that the mat is secured correctly.
To avoid any risk of jamming of the pedals: - only use mats which are suited to the fixings already present in the vehicle; it is imperative that these are used, - never fit one mat on top of another.
Page 99 of 257
1. Rear parcel shelf (see the following page for details) 2. Retaining strap3. Location for Hi- Fi amplifier4. Stowing rings5. Storage box (version equipped with a temporar y puncture repair kit) (see the following page for details) or Tool box (version equipped with a spare wheel) (refer to section "Practical Information - § Changing a wheel")
B o o t fi t t i n g s
Page 100 of 257
