33Monitoring
Warning lampis onCauseAction/Obser vations
Engine autodiagnosis system
fixed. The emission control system has a
fault.
This lamp should switch off when the engine is star ted.
If it does not switch off, contact a CITROËN dealer urgently.
flashing. The engine management system has a fault. Risk of destruction of the catalytic conver tor. Have it checked by a CITROËN dealer.
Low fuel level fixed. When it first comes on there remains approximately 5 litres of fuel in the tank.
You must refuel as soon as possible to avoid running out of fuel. This warning lamp will come on every time the ignition is switched on, until a sufficient addition of fuel is made. Fuel tank capacity: approximately 50 litres (petrol ) or 48 litres (Diesel). Never continue to drive until you run out of fuel a s this could damage the emission control and injection systems.
Maximum coolant temperature fixed red. The temperature of the cooling system is too high. Stop as soon as it is safe to do so. Wait until the engine has cooled down before topping
up the level, if necessary. If the problem persists, contact a CITROËN dealer.

35Monitoring
Airbags
temporarily. This lamp comes on for a few seconds
when you turn on the ignition,then switches off.
This lamp should switch off when the engine is star ted.
If it does not switch off, contact a CITROËN dealer.
fixed. One of the airbag or seat belt pretensioner systems has a fault. Have it checked by a CITROËN dealer.
Warning lampis onCauseAction/Obser vations
Seat belt not fastened/unfastened
fixed then flashing accompanied by an increasing audible signal.
The driver and/or the front passenger has not fastened or has unfastened their seat belt.
Pull the strap then inser t the tongue in the buckle.
Power steering fixed. The power steering has a fault. Drive carefully at reduced speed. Have it checked by a CITROËN dealer.

39Monitoring
System which informs the driver whetherthe engine oil level is correct or not. This information is indicated for a few seconds when the ignition is switched on, after the ser vice information.
Engine oil level indicator
The level read will only be correct if the vehicle is on level ground and the engine has been off for more than 15 minutes.
Oil level correct
Lack of oil
This is indicated by the flashing of "OIL" , linked with the ser vice warning lamp, accompanied by an audible signal and a message on the multifunction screen. If the lack of oil is confirmed by a check using the dipstick, it is essential that the level is topped up to prevent damage to the engine.
Oil level indicator fault
This is indicated by the flashing of "OIL- -" . Consult a CITROËN dealer.
There are 2 marks on the
dipstick: - A = max; never exceed this level (risk of damage to the
engine), - B = min; top up the level via the oil filler cap, using the
grade of oil suited to your engine.
Dipstick
Refer to the "Checks" section to locate the dipstick and the oil filler cap on your engine.

61Comfort
Recommendations for ventilation and air co nditioning
If after an extended stop in sunshine, the interior temperature is very high, first ventilate the passenger compar tment for a few moments.
Put the air flow control at a setting high enough to quickly change the air in the passenger compar tment. The air conditioning system does not contain chlorine and does not present any danger to the ozone layer.
In order for these systems to be fully effective, follow the operation and maintenance guidelines below:  To obtain an even air distribution, take care not to obstruct the exterior air intake grilles located at the base of the windscreen, the nozzles, the vents and the air outlets, as well as the air extractor located in the boot.  Do not cover the sunshine sensor, located on the d ashboard; this is used for regulation of the digital air conditioning system.  Operate the air conditioning system for at least 5 to 10 minutes, once or twice a month to keep it in per fect working order.  Ensure that the passenger compar tment filter is in g ood condition and have the filter elements replaced regularly (refer to the "Checks" secti on). We recommend the use of a combined passenger compa r tment filter. Thanks to its special active additive, it contributes to the purification of the air breathed by the occupants and the cleanliness of the passenger compar t ment (reduction of allergic symptoms, bad odours and greasy deposits).  To ensure correct operation of the air conditioning system, you are also advised to have it checked regularly as recommended in the Maintenanc e and Warranty Guide.
 If the system does not produce cold air, deactivate it and contact a CITROËN dealer. When towing the maximum load on a steep gradient in high temperatures, switching off the air conditioning increases the available engine power and so improves the towing ability.
The condensation created by the air conditioning results in a discharge of water under the vehicle which is per fectly normal.

75Comfort
Access to the rear seats
 Pull the control upwards to fold the seat back and move the seat for ward. When put back in place, the seat returns to its initial position.
No person or object should prevent the seat slide from returning to its initial position; the return to this position is necessary for longitudinal locking. Check that the seat belt has reeled in correctly so as to not impede access to the rear seats for passengers.
Heated seats control
With the engine running, the front seats can be heated separately.  Use the adjustment dial, placed on the side of each front seat, to switch on and select the level of heating required: 0: Off. 1 : Low. 2 : Medium. 3 : High.
Grab handle
This easy to use handle, located at the top of the side trim: - provides a means of suppor t for the outer rear passengers when moving, - provides a hand hold to ease access to the rear seats, - facilitates exit from the rear seats.

Fuel tank Fuel tank capacity: approximately 50 litres (petrol) or 48 litres (Diesel).
Low fuel level
Filling
A label affixed to the inside of the flap reminds you of the type of fuel to be used depending on your engine. Additions of fuel must be of at least 5 litres,
in order to be taken into account by the fuel gauge.
The key cannot be removed from the lock until the cap is refitted. Opening the filler cap may create a noise caused by an inrush of air. This vacuum is entirely normal, resulting from the sealing of the fuel system.
To fill the tank safely:  the engine must be switched off, open the fuel filler flap,  inser t the key in the cap, then turn it to the left,
 remove the cap and hook it onto the clip located on the inside of the flap,  fill the tank, but do not continue after the 3rd cut- off of the pump ; this could cause malfunctions.
When you have filled the tank:  put the cap back in place,  turn the key to the right, then remove it from the cap,  close the flap.
When the fuel tank minimum level is reached this warning lamp comes on
on the instrument panel. When it first comes on there remains approximately 5 litres of fuel in the tank. You must refuel as soon as possible to avoid running out of fuel. If you run out of fuel (Diesel), refer also to the "Checks" section.
With Stop & Star t, never refuel with the system in STOP mode; you must switch off the ignition with the key.

Deactivation
In exceptional conditions (star ting a vehicle which is bogged down, stuck in snow, on soft ground...), it may be advisable to deactivate the ASR and ESP systems, so that the wheels can
move freely and regain grip.  Press the "ESP OFF" button, located on the left below the steering wheel.
If this warning lamp comes on in the instrument panel and the indicator lamp on the button comes on, this indicates that the ASR and ESP systems are deactivated.
Reactivation
These systems are reactivated automatically each time the ignition is switched back on or from 30 mph (50 km/h) (except 1.6 litreTHP 150 petrol engine).
 Press the "ESP OFF" button again to reactivate them manually.
Operating fault
The ESP/ASR systems offer exceptional safety in normal driving, but this should not encourage the driver to take extra risks or drive at high speed. The correct functioning of these systems depends on obser vation of the manufacturer's recommendations regarding the wheels (tyres and rims), the braking components, the electronic components and the CITROËN assembly and operation procedures. After an impact, have these systems checked by a CITROËN dealer.
If this warning lamp comes on, accompanied by an audible signal and a message on the multifunction screen, this
indicates a malfunction of these systems. Have the systems checked by a CITROËN dealer.

155Driving
The system is reactivated automatically at every new star t using the key.
Reactivation
This system requires a battery with a special specification and technology (reference numbers available from CITROËN dealers). Fitting a battery not listed by CITROËN introduces the risk of malfunction of the system. In the event of a malfunction with the system, the "ECO OFF" switch warning lamp flashes, then comes on continuously. Have it checked by a CITROËN dealer. In the event of a fault in STOP mode, the vehicle may stall. It is then necessary to switch off the ignition and star t the engine again using the key.
Operating fault Maintenance
Before working under the bonnet, deactivate the Stop & Star t system to avoid any risk of injury resulting from automatic operation of START mode.
The Stop & Star t system makes use of advanced technology. Specialist knowledge is needed for any work on the system, which can only be assured
by CITROËN dealers.
Press the "ECO OFF" switch again. The system is active again; this is confirmed
by the switch warning lamp going off, accompanied by a message on the screen.
