165Checks
Bonnet
Protects the components of the engine and provides ac cess for checking levels.
Opening
Open the front left door. Pull the interior release lever A , located at the bottom of the door aper ture.
Push the exterior safety catch B to the left and raise the bonnet. Unclip the bonnet stay C from its housing, holding it by its foam protection. Fix the stay in the notch to hold the bonnet open.
The location of the interior release lever prevents opening of the bonnet while
the front left door is closed.
When the engine is hot, handle the exterior safety catch and the stay with care.
Before doing anything under the bonnet, switch off the Stop & Star t
system to avoid any risk of injury resulting from an automatic change to START mode.
Page 140 of 253
Closing
Running out of fuel
(Diesel)
If your vehicle is fitted with an HDI engine, the fuel system must be primed if you run out of fuel. This system consists of a priming pump and a transparent pipe under the bonnet.
Fill the fuel tank with at least five litres of Diesel. Open the bonnet. Depending on version, unclip the cover to gain access to the priming pump. Squeeze and release the priming pump until resistance is felt (could be from the first application) and fuel appears in the transparent pipe with the green connector. Operate the star ter until the engine star ts. Depending on version, put the cover back in position and clip it in place. Close the bonnet.
If the engine does not star t at the first attempt, do not try again. Operate the priming pump again, then the star ter.
Take the stay out of the suppor t notch. Clip the stay in its housing. Lower the bonnet and release it at the end of its travel. Pull on the bonnet to check that it is fully latched.
Page 141 of 253
Closing
Running out of fuel
(Diesel)
If your vehicle is fitted with an HDI engine, the fuel system must be primed if you run out of fuel. This system consists of a priming pump and a transparent pipe under the bonnet.
Fill the fuel tank with at least five litres of Diesel. Open the bonnet. Depending on version, unclip the cover to gain access to the priming pump. Squeeze and release the priming pump until resistance is felt (could be from the first application) and fuel appears in the transparent pipe with the green connector. Operate the star ter until the engine star ts. Depending on version, put the cover back in position and clip it in place. Close the bonnet.
If the engine does not star t at the first attempt, do not try again. Operate the priming pump again, then the star ter.
Take the stay out of the suppor t notch. Clip the stay in its housing. Lower the bonnet and release it at the end of its travel. Pull on the bonnet to check that it is fully latched.
Page 142 of 253
167Checks
Petrol engines
1. Screenwash fluid reser voir. 2. Coolant header tank. 3. Air filter.
4. Brake fluid reser voir. 5. Battery. 6. Fusebox. 7. Engine oil dipstick. 8. Engine oil filler cap.
Page 144 of 253
169Checks
Checking levels
Check all of these levels regularly and top them up if necessary, unless other wise indicated. If a level drops significantly, have the corresponding system checked by a CITROËN dealer.
Oil level
Engine oil change
Refer to the Maintenance and Warranty Guide for details of the inter val for this operation.
In order to maintain the reliability of the engine and emission control system, the use of additives in the engine oil is prohibited.
Oil grade
The oil must be suitable for your engine and conform to the manufacturer's recommendations.
Brake fluid level
C h a n g i n g t h e fl u i d
Refer to the Maintenance and Warranty Guide for details of the inter val for this operation.
F l u i d s p e c i fi c a t i o n
The brake fluid must conform to the manufacturer's recommendations and meet the DOT4 standard.
The brake fluid level should be close to the "MA X" mark. If it is not, check the brake pad wear.
The reading will only be correct if the vehicle is on level ground and the engine has been off for more than 15 minutes. The check is carried out either when the ignition is switched on using the oil level indicator on the instrument panel, or using the dipstick.
Page 145 of 253
Changing the coolant
The coolant does not have to be changed.
F l u i d s p e c i fi c a t i o n
The coolant must conform to the manufacturer's recommendations.
Screenwash fluid level
F l u i d s p e c i fi c a t i o n
For optimum cleaning and to avoid freezing, this fluid must not be topped up or replaced with water.
Take care when carrying out checks under the bonnet as some par ts of the engine can be very hot (risk of burns).
Coolant level
Top up the level when necessary.
The coolant level should be close to the "MA X" mark but should never exceed it. When the engine is warm, the temperature of the coolant is regulated by the fan. This can operate with the ignition off. On vehicles which are fitted with a par ticle emission filter, the fan may operate after the vehicle has been switched off, even if the engine is cold.
In addition, as the cooling system is pressurised, wait at least one hour after switching off the engine before carrying out any work. To avoid any risk of scalding, unscrew the cap
by two turns to allow the pressure to drop. When the pressure has dropped, remove the cap and top up the level.
Page 146 of 253
171Checks
Diesel additive level
(Diesel engine with particle
emission filter)
A low additive level is indicated by lighting of the ser vice warning lamp, accompanied by an audible warning and a message on the multifunction screen.
Topping up
This additive must be topped up by a CITROËN
dealer without delay.
Used products
Avoid prolonged contact of used oil or fluids with the skin. Most of these fluids are harmful to health or indeed very corrosive.
Do not discard used oil or fluids into sewers or onto the ground. Take used oil to a CITROËN dealer (France) or an authorised waste disposal site.
Page 147 of 253
Checks
Battery Air filter and passenger compartment filter
Oil filter
Particle emission filter (Diesel)
Following prolonged operation of the vehicle at very low speed or at idle, you may, in exceptional circumstances,
notice the emission of water vapour at the exhaust on acceleration. This does not affect the behaviour of the vehicle or the environment.
Unless other wise indicated, check these components in accordance with the Maintenance and Warranty Guide and according to your engine. Other wise, have them checked by a CITROËN dealer.
The battery does not require any maintenance. However, check that the terminals are clean and correctly tightened, particularly in summer and winter. When carrying out work on the battery, refer to the "Practical information" section for details of the precautions to be taken before disconnecting the battery and following its reconnection.
Refer to the Maintenance and Warranty Guide for details of the replacement inter vals for these components. Depending on the environment (e.g. dusty atmosphere) and the use of the vehicle (e.g. city driving), replace them twice as often if necessar y (refer to the "Engines" section). A clogged passenger compar tment filter may have an adverse effect on the per formance of the air conditioning system and generate undesirable odours.
Replace the oil filter each time the engine oil is changed.
Refer to the Maintenance and Warranty Guide for details of the replacement inter val for this component.
The presence of this label, in par ticular with the Stop & Star t system, indicates the use of a specific 12 V lead-acid battery with special technology and specification, for which the involvement of a CITROËN dealer is required when replacing or disconnecting the battery. Failure to obser ve this recommendation may cause premature wear of the battery.
It is imperative that the maintenance of the par ticle emission filter is carried out by a CITROËN dealer.
