2010 CHRYSLER 300 Owners Manual

▫To Resume Speed .................... 160
▫ To Vary The Speed Setting .............. 160
▫ To Accelerate For Passing .............. 161
 Adaptive Cruise Control (ACC)
— If Equipped ........................ 162
▫ Adaptive Cruise Control (ACC) Operation . . 164
▫ Activating Adaptive Cruise Control (ACC) . . 164
▫ To Activate ......................... 165
▫ To Set a Desired ACC Speed ............ 166
▫ To Cancel .......................... 167
▫ ToTurnOff ........................ 168
▫ To Resume Speed .................... 168
▫ To Vary The Speed Setting .............. 168 ▫
Setting The Following Distance In ACC .... 170
▫ Adaptive Cruise Control (ACC) Menu ..... 172
▫ Display Warnings And Maintenance ....... 175
▫ Precautions While Driving With ACC ...... 178
▫ General Information .................. 181
▫ Normal (Fixed Speed) Cruise Control
Mode ............................. 182
 Parksense Rear Park Assist .............. 184
▫ Parksense System Usage Precautions ...... 186
 Overhead Console ..................... 189
▫ Courtesy/Reading Lights .............. 189
▫ Sunglasses Storage ................... 189
88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Garage Door Opener — If Equipped ........ 190
▫ Programming HomeLink .............. 191
▫ Gate Operator/Canadian Programming .... 194
▫ Using HomeLink ................... 194
▫ Reprogramming A Single HomeLink
Button ............................ 195
▫ Security ........................... 195
▫ Troubleshooting Tips .................. 195
▫ General Information .................. 196
 Power Sunroof — If Equipped ............ 196
▫ Opening Sunroof — Express ............ 197
▫ Closing Sunroof — Express ............. 197
▫ Pinch Protect Feature ................. 198 ▫
Pinch Protect Override ................ 198
▫ Venting Sunroof — Express ............. 198
▫ Sunshade Operation .................. 198
▫ Wind Buffeting ...................... 199
▫ Sunroof Maintenance ................. 199
▫ Ignition Off Operation ................. 199
▫ Sunroof Fully Closed .................. 199
 Electrical Power Outlets ................. 200
 Cupholders .......................... 203
▫ Front Seat Cupholders ................. 203
▫ Rear Seat Cupholders ................. 203
 Storage ............................. 204
▫ Console Features .................... 204
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 89

▫CargoArea ........................ 205
 Cargo Area Features ................... 206
▫ Trunk Mat — If Equipped .............. 206
Rear Window Features .................. 206
▫ Rear Window Defroster ................ 206
 Load Leveling System — If Equipped ....... 207
90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

MIRRORS
Inside Day/Night Mirror
A two-point pivot system allows for horizontal and
vertical mirror adjustment. Adjust the mirror to center on
the view through the rear window. The mirror should be
adjusted while set in the day position (toward the wind-
shield).
Headlight glare can be reduced by moving the small
control under the mirror to the night position (toward the
rear of the vehicle).
Adjusting Rearview Mirror
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91

Automatic Dimming Mirror — If Equipped
This mirror automatically adjusts for headlight glare
from vehicles behind you. You can turn the feature on or
off by pressing the button at the base of the mirror. A light
next to the button will illuminate to indicate when the
dimming feature is activated.CAUTION!
To avoid damage to the mirror during cleaning, never
spray any cleaning solution directly onto the mirror.
Apply the solution onto a clean cloth and wipe the
mirror clean.
Outside Mirrors
To receive maximum benefit, adjust the outside mirror(s)
to center on the adjacent lane of traffic and a slight
overlap of the view obtained from the inside mirror.
NOTE:The passenger side convex outside mirror will
give a much wider view to the rear, and especially of the
lane next to your vehicle.
Automatic Dimming Mirror
92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
Vehicles and other objects seen in the passenger side
convex mirror will look smaller and farther away
than they really are. Relying too much on your
passenger side convex mirror could cause you to
collide with another vehicle or other object. Use your
inside mirror when judging the size or distance of a
vehicle seen in the passenger side convex mirror.
Outside Mirrors Folding Feature — If Equipped
Some models have outside mirrors that are hinged. The
hinge allows the mirror to pivot forward and rearward to
resist damage. The hinge has three detent positions: full
forward, full rearward and normal.
Driver’s Automatic Dimming Mirror — If Equipped
The driver’s outside mirror will automatically adjust for
glare from vehicles behind you. This feature is controlled
by the inside automatic dimming mirror and can beturned on or off by pressing the button at the base of the
inside mirror. The mirror will automatically adjust for
headlight glare when the inside mirror adjusts.
NOTE:
This feature is also available on the passenger’s
side when equipped with turn signal and approach
lighting.
Outside Mirrors with Turn Signal and Approach
Lighting — If Equipped
Driver and passenger outside mirrors with turn signal
and approach lighting contain four LEDs, which are
located in the upper outer corner of each mirror.
Three of the LEDs are turn signal indicators, which flash
with the corresponding turn signal lights in the front and
rear of the vehicle. Turning on the Hazard Warning
flashers will also activate these LEDs.
The fourth (uppermost) LED supplies illuminated entry
lighting, which turns on in both mirrors when you use
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93

the Remote Keyless Entry (RKE) transmitter or open any
door. This LED shines outward to illuminate the front
and rear door handles. It also shines downward to
illuminate the area in front of the doors.
The Illuminated Entry lighting fades to off after about
30 seconds or it will fade to off immediately once the
ignition is placed into the RUN position.
NOTE:The approach lighting will not function when
the shift lever is moved out of the PARK position.
Tilt Mirrors in Reverse — If Equipped
Tilt Mirrors in Reverse provides automatic outside mirror
positioning which will aid the driver ’s view of the
ground rearward of the front doors. The outside mirrors
will move slightly downward from the present position
when the vehicle is shifted into REVERSE. The outside
mirrors will then return to the original position when the vehicle is shifted out of the REVERSE position. Each
stored memory setting will have an associated Tilt Mir-
rors in Reverse position.
NOTE:
The Tilt Mirrors in Reverse feature is not en-
abled when delivered from the factory. The Tilt Mirrors in
Reverse feature can be enabled or disabled through the
customer-programmable features in the Electronic Ve-
hicle Information Center (EVIC), Refer to “Electronic
Vehicle Information Center (EVIC)/Customer-
Programmable Features” in “Understanding Your Instru-
ment Panel” for further information.Power Mirrors
The power mirror switch is located on the driver’s door
trim panel, next to the power door lock switch. A rotary
knob selects the left mirror, right mirror or off position.
94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

After selecting a mirror, move the knob in the same
direction you want the mirror to move. Use the center off
position to guard against accidentally moving a mirror
position.NOTE:
For vehicles equipped with Driver Memory
Seat, you can use your Remote Keyless Entry (RKE)
transmitter or the memory switch on the driver’s door
trim panel to return the power mirrors to pre-
programmed positions. Refer to “Driver Memory Seat”
in “Understanding the Features of Your Vehicle” for
further information.
Heated Mirrors — If Equipped
These mirrors are heated to melt frost or ice. This
feature is activated whenever you turn on the rear
window defroster. Refer to “Rear Window Features” in
“Understanding the Features of Your Vehicle” for further
information.
Power Mirror Control
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95
