If you use the RKE transmitter to enter the vehicle andthe remote recall memory feature is on, automaticseat and mirror movement will occur. See “MEMORYSEAT RECALL” underDIC Vehicle Customizationon page 4-80for more information.
To stop recall movement of the memory feature at anytime, press one of the power seat controls, memorybuttons, power tilt wheel control, or power mirrorbuttons.
If something has blocked the driver seat and/or thesteering column while recalling a memory position, thedriver seat and/or the steering column recall maystop. If this happens remove the obstruction, then pressthe appropriate control for the area that is not recallingfor two seconds. Try recalling the memory position againby pressing the appropriate memory button. If thememory position is still not recalling, see yourdealer/retailer for service.
Easy Exit Recall
The control for this feature is located on the driver doorpanel between buttons 1 and 2.
With the vehicle in P (Park), the exit position can berecalled by pressing the exit button. You will heara single beep. The driver seat will move back, and if thevehicle has the power tilt wheel and telescopic steeringfeature, the power telescopic steering column willmove up and forward.
If the easy exit seat feature is on in the DIC, automaticseat and power telescopic steering column movementwill occur when the key is removed from the ignition.See “EASY EXIT RECALL” underDIC VehicleCustomization on page 4-80for more information.
Further programming for automatic seat and steeringwheel movement can be done using the DriverInformation Center (DIC). You can select or not selectthe following:
•The easy exit recall feature
•The memory seat recall feature
For programming information, seeDIC VehicleCustomization on page 4-80.
2-7

4. Buckle, position, and release the safety belt asdescribed earlier in this section. Make sure thatthe shoulder belt crosses the shoulder.
To remove and store the comfort guide, squeeze thebelt edges together so that the safety belt can beremoved from the guide. Slide the guide into its storagepocket on the side of the seatback.
Safety Belt Use During Pregnancy
Safety belts work for everyone, including pregnantwomen. Like all occupants, they are more likely to beseriously injured if they do not wear safety belts.
A pregnant woman should wear a lap-shoulder belt, andthe lap portion should be worn as low as possible,below the rounding, throughout the pregnancy.
The best way to protect the fetus is to protect themother. When a safety belt is worn properly, it is morelikely that the fetus will not be hurt in a crash. Forpregnant women, as for anyone, the key to makingsafety belts effective is wearing them properly.
2-31

Keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3Remote Keyless Entry (RKE) System . . . . . . . . . . . . . . . .3-4Remote Keyless Entry (RKE) SystemOperation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4Remote Vehicle Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-7
Doors and Locks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-9Door Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-9Central Door Unlocking System . . . . . . . . . . . . . . . . . . . . . .3-10Power Door Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-10Programmable Automatic Door Locks . . . . . . . . . . . . . .3-10Rear Door Security Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-10Lockout Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-11Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-12
Windows. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-14Power Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-15Sun Visors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-17
Theft-Deterrent Systems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-18Valet Lockout Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-18Content Theft-Deterrent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-19PASS-Key®III+ Electronic Immobilizer . . . . . . . . . . . . .3-21PASS-Key®III+ Electronic ImmobilizerOperation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-21
Starting and Operating Your Vehicle. . . . . . . . . . . . . . . .3-22New Vehicle Break-In . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-22Ignition Positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-23Retained Accessory Power (RAP) . . . . . . . . . . . . . . . . . . .3-24Starting the Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-24Engine Coolant Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-26Automatic Transmission Operation . . . . . . . . . . . . . . . . . . .3-27Performance Shifting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-29Parking Brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-30Shifting Into Park . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-31Shifting Out of Park . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-32Parking Over Things That Burn . . . . . . . . . . . . . . . . . . . . . . .3-33Engine Exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-34Running the Vehicle While Parked . . . . . . . . . . . . . . . . . .3-35
Mirrors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-36Automatic Dimming Rearview Mirror . . . . . . . . . . . . . . . .3-36Compass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-36Outside Power Foldaway Mirrors . . . . . . . . . . . . . . . . . . . . .3-37Outside Automatic Dimming Mirror . . . . . . . . . . . . . . . . . .3-38Park Tilt Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-39Outside Convex Mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-39Outside Heated Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-39
Section 3 Features and Controls
3-1

Keys
{WARNING:
Leaving children in a vehicle with the ignition key
is dangerous for many reasons, children or others
could be badly injured or even killed. They could
operate the power windows or other controls or
even make the vehicle move. The windows will
function with the keys in the ignition and children
could be seriously injured or killed if caught in the
path of a closing window. Do not leave the keys in
a vehicle with children.
The master key is used for the driver door, ignition, andglove box.
The valet key is used for the driver door and ignition.
Notice:If you ever lock your keys in the vehicle,you may have to damage the vehicle to get in.Be sure you have spare keys.
In an emergency, contact Roadside Assistance.SeeRoadside Service on page 8-7.
3-3

Remote Keyless Entry (RKE)
System
SeeRadio Frequency Statement on page 8-20forinformation regarding Part 15 of the FederalCommunications Commission (FCC) Rules andRSS-210/211 of Industry and Science Canada.
Changes or modifications to this system by other thanan authorized service facility could void authorization touse this equipment.
If there is a decrease in the RKE operating range, try this:
•Check the distance. The transmitter may be too far
from the vehicle. Stand closer during rainy or snowyweather.
•Check the location. Other vehicles or objects may be
blocking the signal. Take a few steps to the left orright, hold the transmitter higher, and try again.
•Check the transmitter’s battery. See “Battery
Replacement” later in this section.
•If the transmitter is still not working correctly, see
your dealer/retailer or a qualified technician forservice.
Remote Keyless Entry (RKE)
System Operation
The Remote Keyless Entry (RKE) transmitter functionswork up to 60 m (195 feet) away from the vehicle.
There are other conditions which can affect theperformance of the transmitter. SeeRemote KeylessEntry (RKE) System on page 3-4.
/(Remote Vehicle Start):Press to start the engine
from outside the vehicle using the RKE transmitter.SeeRemote Vehicle Start on page 3-7for additionalinformation.
With Remote Start(Without Remote StartSimilar)
3-4

Programming Transmitters to the
Vehicle
Only RKE transmitters programmed to the vehicle willwork. If a transmitter is lost or stolen, a replacement canbe purchased and programmed through yourdealer/retailer. When the replacement transmitter isprogrammed to the vehicle, all remaining transmittersmust also be programmed. Any lost or stolentransmitters no longer work once the new transmitter isprogrammed. Each vehicle can have up to eighttransmitters programmed to it. See RELEARN REMOTEKEY underDIC Operation and Displays on page 4-62.
Battery Replacement
Replace the battery if the REPLACE BATTERY INREMOTE KEY message displays in the DIC. See“REPLACE BATTERY IN REMOTE KEY” underDICWarnings and Messages on page 4-67for additionalinformation.
Notice:When replacing the battery, do not touchany of the circuitry on the transmitter. Staticfrom your body could damage the transmitter.
To replace the battery:
1. Separate the transmitter with a flat, thin objectinserted into the notch, located above themetal base.
2. Remove the old battery. Do not use a metal object.
3. Insert the new battery, positive side facing up.Replace with a CR2032 or equivalent battery.
4. Reassemble the transmitter.
3-6

Remote Vehicle Start
The remote vehicle starting feature allows you to startthe engine from outside of the vehicle. It also startsup the vehicle’s automatic climate control system. Whenthe remote start system is active, the climate controlsystem will heat and cool the inside of the vehicleaccording to the previous settings of the system beforeturning the vehicle off. The rear window defoggerwill be turned on by the climate control system when itis cold outside. If the vehicle has heated seats, theywill also turn on when it is cold outside. SeeHeated andVentilated Seats on page 2-5for additional information.Cooled seats are not activated during a remote start.Normal operation of the climate control system willreturn after the key is turned to ON/RUN. SeeDualClimate Control System on page 4-36.
Laws in some communities may restrict the use ofremote starters. For example, some laws may require aperson using remote start to have the vehicle in viewwhen doing so. Check local regulations for anyrequirements on remote starting of vehicles.
Do not use the remote start feature if your vehicle is lowon fuel. Your vehicle may run out of fuel.
If your vehicle has the remote start feature, the RKEtransmitter functions will have an increased rangeof operation. However, the range may be less while thevehicle is running.
There are other conditions which can affect theperformance of the transmitter, seeRemote KeylessEntry (RKE) System Operation on page 3-4foradditional information.
/(Remote Start):This button will be on the
RKE transmitter if you have remote start.
To start the vehicle using the remote start feature:
1. Aim the transmitter at the vehicle.
2. Press and release the transmitter’s lock button,then immediately press and hold the transmitter’sremote start button until the turn signal lightsflash or if the vehicle’s lights are not visible, pressand hold the remote start button for at leastfour seconds. Pressing the remote start buttonagain after the vehicle has started will turn off theignition.
When the vehicle starts, the parking lamps will turnon and remain on while the vehicle is running.The vehicle’s doors will be locked.
3. If it is the first remote start since the vehicle has beendriven, repeat these steps, while the engine is stillrunning, to extend the engine running time by10 minutes. Remote start can be extended one time.
3-7

After entering the vehicle during a remote start, insertand turn the key to ON/RUN to drive the vehicle.
If the vehicle is left running it will automatically shut offafter 10 minutes unless a time extension has been done.
To manually shut off a remote start:
•Aim the RKE transmitter at the vehicle and press
the remote start button until the parking lampsturn off.
•Turn on the hazard warning flashers.
•Turn the ignition switch on and then off.
The remote vehicle start feature provides two separatestarts, each with 10 minutes of engine running, or itprovides one start with 10 minutes of engine running thatmay be extended 10 more minutes. If you press andrelease the transmitter lock button and then press andhold the remote start button on the RKE transmitteragain before the first 10 minutes of engine running timehas expired, 10 minutes are added to the remainingminutes. For example, if the lock button and thenthe remote start buttons are pressed again afterfive minutes of the engine run time, 10 minutes areadded and you now have 15 minutes of engine running.The added ten minutes are considered a secondremote vehicle start.
Once two remote starts or a single start with a timeextension have been used, the vehicle must be startedwith the ignition key before you can use the remotestart feature again.
The remote vehicle start feature will not operate if thekey is in the ignition, the hood is not closed, or if there isan emission control system malfunction.
The engine will turn off during a remote vehicle start ifthe coolant temperature gets too high, or the oil pressureis too low.
Your vehicle was shipped from the factory with theremote vehicle start system enabled. The system maybe disabled through the Driver Information Center (DIC).See “REMOTE START” underDIC VehicleCustomization on page 4-80for additional information.
SeeEngine Exhaust on page 3-34for important safetyinformation when using remote start in a closed garage.
Remote Start Ready
If your vehicle does not have the remote vehicle startfeature, it may have the remote start ready feature.This feature allows your dealer/retailer to add themanufacturer’s remote vehicle start feature. See yourdealer/retailer if you would like to add the manufacturer’sremote vehicle start feature to your vehicle.
3-8
