2010 AUDI A5 COUPE sensor

• ..__P_ a_r _k _ a_s _ s_ i_ s _t ____________________________________________________ _
•
Sensor s in th e bump er
Fig . 17 1 Tru nk l id:
L oca tion of th e r ear
vi ew c amera
Sensors are located in the rear bumpers. If these detect an obstac le,
audible and visual signals warn you . The range at which the sensors
begin to measure is approximately:
To the side 2 ft (0.60 ml
Center rear
5.2 ft (1.60 m)
Distance warning when reversing starts when an obstacle is
detected in the range of the parking assist system. As the distance
decreases, the time interval between the audible tones becomes
shorter.
When the distance is less than 1ft (0.30 ml, the tone becomes continuous . At this point you should stop backing up.
If the distance to an obstacle stays the same, the vo lume of the
distance signal chime is gradually reduced after about 4 seconds
(does not affect the continuous signal tone). Approaching another
obstac le wi ll cause the distance signal to sound again at the normal
volume.
R ea r vi ew camera cover age ar ea
The MMI display shows the area covered by the rear view camera
=>
page 157, fig . 170 G) . Objects that are not in the area covered 0
are not shown on the MMI display. We recommend that you practice parking with the rear view camera
in a traffic -free location or parking lot to become familiar with the
system, the orientation lines, and their function. When doing this,
there should be good ligh t and weather conditions.
In the MMI d isplay, objec ts or vehicles appear closer or further away
if:
• you are driving in reverse gear from a level surface onto an
incline, or a downward slope,
• you are driving in reverse gear toward protruding objects,
• the vehic le is carrying too much load in the rear.
The accuracy of the orientation lines and b lue surfaces diminishes
if:
• the rear view camera does not provide a reliable image, for
example, in poor visibility conditions or if the lens is dirty,
• the image on the screen is not visible due to sun glare and reflec ­
tion.
C aring for the rear vi ew c amera l en s
The rear view camera is located above the rear license plate bracket.
For the parking assist to operate, the lens => fig. 171 must be kept
clean :
• Dampen the lens with a household alcohol -based glass cleaner,
and clean the lens with a dry cloth
~ 0 .
• Remove snow with a hand brush and ice preferably with a de ­
icing spray=>
0 .
& WARNING
• The p arking aid cannot repl ace the driver' s attentio n. The
driv er alo ne is re spon sible for parkin g and similar dri ving m aneu ­
v ers .
• Alway s keep your eyes on the vehicle' s surrounding s, usin g the
r ea r vie w mirror as w ell. ..,.

______________________________________________________ P_ a _ r_k _ a_s _s _ i_s _t __ lfflll
& WARN ING (con tinued)
• Do n ot all ow y ourself to b e di stract ed from tr affic by the r ear
vi ew c amera pictur es.
• If th e po sition and th e installati on an gle of th e camera ha s
chan ged, fo r exa mpl e, after a re ar end colli sion , do not con tinue to
u se the sy ste m for safety re ason s. Have it checked by a qua lifi ed
de alers hip .
0 Note
• Low obstac les already signa led by a warning can disappear from
the system's detection range as they are approached and will not
cont inue to be signaled . Objects such as barrier chains, trailer draw
bars, thin painted vertical po les or fences may not be detected by
the system, posing risk o f damage .
• Never use warm or hot water to remove snow or ice from the
camera lens - danger of crack formation on the lens!
• When cleaning the lens, never use products that are abrasive .•
Appl ies t o veh ic les: with parking s ystem (rear, with rear view ca m era)
Switching on /off
The rear view camera switches on automatically together
with the acoustic park assist when you put the vehicle in
reverse.
Switching on
- Put the vehicle in reve rse gear, the acoustic parking
system with rear view camera is activated automatically.
Activation of the acoustic park ing system is confirmed by
a brief acknowledgement sou nd.
Switching off
- Drive faster than 6 mph ( 10 km/h), or
Controls and equip ­
ment
take t he vehicle out of reve rse gear . The acoustic parking
system is immediate ly deactivated, and t he rear view
camera picture is d eactivated automatica lly after a
period of about 15 seco nds, or
- switch off the ignition .
The delay in deactivating the camera provides an uninterrupted
view behind the vehicle especially when maneuvering in tight
parking spaces and prevents the picture from turning off the every
time you shift out of reverse.
I f the warni ng message appears in the display but not the rear view
camera picture, read and confirm the warn ing message. The
acoustic distance signal is a lways ac tive .
I f you press a function button on the MMI termina l, the rear view
camera picture disappears. The rear view camera picture reappears
the next time you park.
Further information on the warning message and the MMI terminal
can be found in the MMI inst ruction booklet.
[ i ] Tips
• The rear view camera picture is available as soon as the MMI
Display or the MMI is switched on, or the start -up phase is
completed.
• Keep the sensors in the rear bumper and the rear view camera
lens clean and free of snow and ice, so that the parking system can
work properly . Please fo llow the additional notes on=>
page 163. •
I • •

• ..__P_ a_r _k _ a_s _ s_ i_ s _t ____________________________________________________ _
& WARNING
• The rear view camera doe s not show the entire area behind the
vehicle
=> page 157 , fig. 1 70 . Watch out especially for small chil ­
dren and animal s. The rear view camera cannot always detect
them , posing ri sk of an a ccident!
• Please note that objects not tou ching the ground can appear to
be further away than they really are (for example , the bumper of a
parked vehi cle , a trailer h itch , or the rear of a t ruck ). In this case ,
you should not use the help lines to help with parking , which
poses danger of an a ccident !
0 Note
In the MMI d isplay, the d irection of trave l o f the vehicle rear is rep re ­
sented depending on the steering wheel angle. The vehicle front
swings out more than the veh ic le rear. Maintain ple nty of distance
from an obstacle so that your outside mirror or a corner of your
veh icle does not col lide with any obs tacles - danger of accident!
[ i J Tips
The left or r igh t ori entat ion li nes and s urfaces will be displayed,
depending on the turn signa l being used .•
Ap plies to veh ic les: w ith par king sy ste m !rear, with rear vie w camera)
Adjusting the display and warning tones
The d isplay and warning tones are adjusted in the radio
or
MM /*.
Sele ct: [CARI> Parking system .
Display
Fig . 17 6 MMI di spla y:
adjusting the parking
sys tem
• Off -when the parking system is switched off, on ly audible
sig nals a re given .
• On -when the par king system is switched on, the picture from
the rea r view came ra is displayed .
Warning tones
• Rear volume -
rear sensor volume
• Rear frequency -rear sensor frequency
• In-car entertainment fader -when the parking system is
switched on, the volume of the active audio source is lowered.
The newly a dju sted va lue is b riefly heard fr om the sig nal gene rator .
T he settings are automatically stored and assigned to the remote
control k ey.
~

______________________________________________________ P_ a _ r_k _ a_s _s _ i_s _t __ _
& WARNING
• Always make sure that the volume and frequen cy of the
warning tones is adjusted so that you can easily hear the acoustic distan ce signal even if the radio is playing , the air -conditioner
blower is on High or there is a high level of outside noise .
• Che ck the settings whene ver someone else has dri ven the
vehicle before you.
[ i ] Tips
• The wa rni ng ton es can a ls o b e adjuste d directly fro m the rea r
v iew camera image. Simp ly press the [SettingsJ * control button .
• Change d se ttin gs are ac tivated whe n parking ass is t is switched
on again .•
App lies to veh ic les: w ith parking system ( rear , with rea r view camera)
Error messages
If a war nin g to ne is au dible fo r abou t five seconds wh en yo u tu rn on
the ignit ion, there is a malfunc tion in the system . Have the prob lem
co rrected by y our autho rized Aud i deale r.
Kee p the sensors in the rea r bu mper c lean a nd free fro m ice so that
the acoustic park assist system can function prope rly. •
