2010 Acura RL display

µ
µ
´
CONT INUED
TheSH-AWDtorquedistribution
monitor on the multi-inf ormation
display shows you the amount of
torque being sent to the wheels.
Each wheel right f ront (RF), lef t
front(LF),rightrear(RR),andleft
rear (LR) has its own torque
indicator.
The super handling-all wheel drive
(SH-AWD) system is a f ull time all-
wheel-drive system that
automatically controls and transfers
varying amounts of engine torque to
all wheels independently, according
to the driving conditions.
While the SH-AWD system helps to
enhance the vehicle’s driving
stability in all situations, it is still
your responsibility to drive and
corner at reasonable speeds and to
leave a sufficient margin of safety.
When you are in sequential shif t
mode, and the vehicle is stopped,
pull the (right) paddle shifter to
shif t to second gear. You will see
‘‘M2’’ in the display. Starting in
second gear helps to reduce
wheelspin in deep snow or on a
slippery surf ace.
SH-AWD T orque Distribution
Monitor
St art ing in Second Gear
Super Handling-A ll Wheel Drive (SH-A WD)System
Driving
407
TORQUE INDICATOR
TORQUE INDICATOR
TM
——y


y
(y
y
2010 RL

Each torque indicator is displayed as
a bar graph divided into 5 segments.
The number of segments represents
the amount of torque distributed to
each wheel.
When there is only a slight change in
torque distribution while driving,
such as cruising on level roads at the
same speed, the torque distribution
monitor may stop displaying the
amount of torque. This is not a
system problem. The monitor will
show the amount if the system
senses any change in torque
distribution.If the SH-AWD indicator blinks while
driving, it indicates the dif f erential
temperature is too high. You will also
see an ‘‘SH-AWD DIFF TEMP.
HIGH’’ message on the multi-
inf ormation display. If this happens,
pull to the side of the road when it is
saf e, shif t to Park, and let the engine
idle until the indicator goes out. If
the indicator does not go out, take
your vehicle to a dealer to have it
checked.
If the SH-AWD indicator on the
instrument panel stays on, and the
‘‘CHECK SH-AWD SYSTEM’’
message also appears on the multi-
inf ormation display, there is problem
with the SH-AWD system.
Your vehicle still has normal f ront-
wheel drive with vehicle stability
assist (VSA), but does not have the
advantages of SH-AWD. Have your
vehicle checked by a dealer as soon
as possible.
Super Handling-A ll Wheel Drive (SH-A WD)System
408
TM
——y

y
(y
y
2010 RL

The anti-lock brake system (ABS)
helpspreventthewheelsfrom
locking up, and helps you retain
steering control by pumping the
brakes rapidly, much f aster than a
person can do it.If this indicator comes on, the anti-
lock f unction of the braking system
has shut down. The brakes still work
like a conventional system, but
without anti-lock. You should have
your dealer inspect your vehicle as
soon as possible.
You will f eel a pulsation in the brake
pedal when the ABS activates, and
you may hear some noise. This is
normal: it is the ABS rapidly
pumpingthebrakes.Ondry
pavement, you will need to press on
thebrakepedalveryhardbeforethe
ABS activates. However, you may
feel the ABS activate immediately if
you are trying to stop on snow or ice.
Let the ABS work f or you by always
keeping f irm, steady pressure on the
brake pedal. This is sometimes
ref erred to as ‘‘stomp and steer.’’ The electronic brake distribution
(EBD) system, which is part of the
ABS, also balances the f ront-to-rear
braking distribution according to
vehicle loading. When the ABS indicator comes on,
you will also see a ‘‘CHECK ABS
SYSTEM’’ message on the multi-
inf ormation display.
You should never pump the brake pedal.
CONT INUED
ABS Indicator
Anti-lock Brakes (ABS)
Driving
411
——y

y
(y
y
2010 RL

The radar sensor is located under
the Acura emblem in the f ront grille.
If the radar sensor cover is covered
with mud, dirt, dead leaves, wet
snow, etc., or if you put a sticker on
it, the CMBS will automatically shut
of f , and the CMBS indicator on the
instrument panel will come on. You
will also see a ‘‘CHECK CMBS
RADAR SENSOR’’ message on the
multi-inf ormation display f or about 5
seconds.Always keep the radar sensor cover
clean. If it gets dirty, clean it with
water or a mild detergent. Never use
chemical solvents or polishing
powder.Do not allow anything to impact the
radarsensorortheradarsensor
cover. If either of these parts
receives a strong impact, turn off the
system by pressing the CMBS of f
switch, and have your vehicle
checked by a dealer. If the f ront
grille ever needs to be repaired,
consult a dealer f irst.
If the radar sensor cover or the radar
sensor ever needs to be removed,
take your vehicle to a dealer.
There are three bolts on the sides of
the radar sensor. Do not tamper with
these bolts, or you may cause the
system to malf unction.
Radar Sensor
Collision Mitigation Brake System (CMBS)
414
RADAR SENSOR COVER
BOLTS
(Do not tamper)
——y
y
(y
y
2010 RL

The radar sensor may not always
scan as intended. Here are two
examples:Thetiresarenotcorrectly
maintained. Always make sure the
tire pressures are correct (see
page ), and that the tires are
the correct size and in good
condition (see Tires on page ). Your vehicle is tilted because of a
heavy load in the rear or from
modif ications to the suspension.
Do not overload your vehicle (see
Carrying Cargo on page ), and
do not make any modif ications to
the suspension (see Accessories
and Modif ications on page ). 474
474 387
389
Collision Mitigation Brake System (CMBS)
Driving
415
When the CMBS is on, the radar sensor
constantly scans f or vehicles ahead of
you. This means that driving on a road
with a f ew or no vehicles could cause a
CHECK CMBS RADAR SENSOR
message to appear on the multi-
inf ormation display. This is normal
and not a cause f or concern.
——y

y
(yy
2010 RL

If the system senses a likely collision
with a vehicle or object ahead of you,
it alerts you with an audible and a
visual alarm.The audible alarm is a constant
beeping sound; the visual alert is an
amber colored BRAKE message that
f lashes on the multi-inf ormation
display. If these alarms come on,
take the appropriate means to
prevent a collision (apply the brakes,
change lanes, etc.).To turn the CMBS off, press the
CMBS OFF switch on the dashboard
f or about 1 second. When you do this,
a beeper sounds, a CMBS indicator
on the instrument panel comes on,
and a CMBS OFF message appears
on the multi-information display. To
turn the system back on, press the
switch again for about 1 second.
Collision Alarm
CMBS OFF Switch
Collision Mitigation Brake System (CMBS)
416
CMBS OFF SWITCH
——y

y
(y
y
2010 RL

The CMBS will automatically
recover when these conditions are
improved.
Any of the conditions below can
cause the CMBS to shut of f . When
the system shuts off, the CMBS
indicator in the instrument panel
comes on, and a CHECK CMBS
SYSTEM message appears on the
multi-inf ormation display f or about 5
seconds.
An abnormal tire condition is
detected (wrong tire size, f lat tire,
etc.).
Extended of f -road or mountainous
driving.
Driving your vehicle with the
parking brake applied.
Driving your vehicle in bad
weather(rain,fog,snow,etc.).
A dirty emblem on the f ront grille.
When you turn the ignition switch to
the ON (II) position, the CMBS is
turned on if it was on previously.
Automatic Shut Of f
Collision Mitigation Brake System (CMBS)
Driving
417
——y
y
(yy
2010 RL

The CMBS indicator normally comes
on under these conditions:When you manually turn of f the
system.
When the system shuts off
automatically.
When you drive in bad weather
(rain, snow, f og, etc.). When the VSA system indicator
comes on (see page ).
When you turn the ignition switch
to the ON (II) position, the CMBS
indicator should come on f or a f ew
seconds, then go of f . If the
indicator comes on at any other
time and a CHECK CMBS
SYSTEM message appears on the
multi-inf ormation display, there is
a problem with the CMBS. You
can still drive your vehicle, but
CMBS will not be operating. Have
your vehicle checked by a dealer.
If anything covers the f ront grille
(dirt, mud, dry leaves, wet snow,
etc.).
This indicator comes on f or several
seconds when you turn the ignition
switch to the ON (II) position. It also
comesonandstaysonwhenyou
turn the CMBS off by pressing the
CMBS OFF switch.
To turn the CMBS back on, make
sure the vehicle is stopped and the
ignition switch is in the ON (II)
position, then press the CMBS OFF
switch f or about 1 second. 429
CMBS Indicator
Collision Mitigation Brake System (CMBS)
418
CMBS INDICATOR
——y
y
(yy
2010 RL
