2010.5 Peugeot 508 Dag height adjustment

.
9
Familiarisation
Sitting comfortably
Front seats
61
Manual adjustments
1. Head restraint height and angle adjustment. 2. Backrest angle adjustment. 3. Seat cushion height adjustment. 4. Lumbar suppor t adjustment. 5. Seat for wards-backwards adjustment. 6. Cushion adjustment.
Electrical adjustment
1. Angle, seat height and seat for wards-backwards adjustment.
2. Backrest angle adjustment. 3. Lumbar suppor t adjustment.
62

10
Familiarisation
9. Fusebox. 10. Front door window demisting/defrosting vent. 11. Windscreen demisting/defrosting vent. 12. Steering lock and star ting with the key. 13. Star ting using the electronic key. 14. Audio equipment steering wheel controls. 15. Wiper/screenwash/trip computer stalk. 16. Central locking and hazard warning buttons. 17. Multifunction screen.
Instruments and controls
1. Cruise control/speed limiter controls. 2. Headlamp height adjustment. 3. Lighting and direction indicator stalk. 4. Instrument panel. 5. Driver's airbag. Horn. 6. Gear lever. 7. 12 V accessory socket USB por t /auxiliary socket. 8. Bonnet release lever.
18. Central adjustable air vents. 19. Passenger's airbag. 20. Side adjustable air vents. 21. Glove box /Passenger's airbag deactivation. 22. Electric parking brake. 23. Central armrest with storage. 24. Upper and lower storage. 25. Audio system. 26. Heating/air conditioning controls.

12
!
Familiarisation
Sitting comfortably
Head restraint adjustment
64
1. Release the adjustment mechanism. 2. Adjust for height and reach. 3. Lock the adjustment mechanism.
Steering wheel adjustment
70
For reasons of safety, these operations must only be carried out with the vehicle stationary.
Heated seats control
0 : off. 1 : low. 2 : medium. 3 : high.
To lower it, press button A . To raise it, guide the head restraint upwards to the desired position. To incline it, swivel the lower par t backwards or for wards.
64

361
Comfort
Front seats
Manual adjustments
1. Adjustments to the height and angle of the head restraint To raise it, pull upwards. To lower it, hold the button in and press on the head restraint (pushing to go past the stiff point of the button).
2. Adjustment of the backrest angle Operate the control lever and adjust the position of the backrest to the front or to the rear. 3. Adjustment of the seat height Raise or lower the control lever the number of times required to obtain the desired position. 4. Adjustment of the lumbar suppor t This system allows the height and depth of the lumbar suppor t to be adjusted separately.  For wards or backwards to increase or decrease the lumbar suppor t.  Upwards or downwards to raise or lower the lumbar contact zone. 5. For wards-backwards adjustment of the seat position Lift the control bar and slide the seat
for wards or backwards. 6. Adjustment of the seat cushion Pull on the grip to adjust the length of the cushion.

62
i
Comfort
Switch on the ignition or star t the engine if the vehicle has gone into economy mode.
1. Adjustment of the seat cushion angle and height, and for wards-backwards adjustment Raise or lower the front of the control to adjust the seat cushion angle.  Raise or lower the rear of the control to raise or lower the seat.  Simultaneously raise or lower the front and rear of the control in order to raise or lower the entire seat. 2. Adjustment of the backrest angle Move the control for wards or backwards to adjust the backrest angle. 3. Adjustment of lumbar suppor t This function allows you to independently adjust the height and level of lumbar suppor t.
The electric functions of the driver's seat are activ e for about a minute after opening the front door. They are deactivated about a minute afte r switching off the ignition and in economy mode. To reactivate them, switch on the ignition.
Move the control:  For wards or backwards to increase or reduce the lumbar suppor t.  Upwards or downwards to raise or lower the lumbar suppor t zone.

64
!
Comfort
Head restraint height and angle adjustment
 To lower the head restraint, press the lug A and, going beyond the stiff point, guide the head restraint downwards, then release the button at the desired position.  To raise the head restraint, guide it upwards to the desired position.  To adjust the angle of the head restraint, tilt its lower par t for wards or rear wards.  To remove the head restraint, press the two lugs B and pull the head restraint upwards.
 To put the head restraint back in place, engage the head restraint stems in the openings keeping them in line with the seat back. Check that it has engaged by puling it upwards.
The head restraint is fitted with a locking mechanism which prevents it from lowering; this is a safety device in case of impact. The adjustment is correct when the upper edge of the head restraint is level with the top of the head. Never drive with the head restraints
removed; they must be in place and adjusted correctly.
Heated seats control
With the engine running, the front seats can be heated separately.  Use the adjustment dial, placed on the centre console, to switch on and select the level of heating required: 0: Off. 1: Low. 2: Medium. 3: High.

70
!
i!
Comfort
Automatic day/night model
By means of a sensor, which measures the light from the rear of the vehicle, this system automatically and progressively changes between the day and night uses. It has an anti-dazzle system which darkens the mirror glass: this reduces any driver discomfor t caused by the light beams of following vehicles, the sun...
Adjustable mirror providing a central rear ward view. Equipped with an anti-dazzle system, useful in poor light.
Rear view mirror
Manual day/night model
Adjustment
 Adjust the mirror so that the glass is directed correctly in the "day" position.
Day/night position
 Pull the lever to change to the "night" anti-dazzle position.  Push the lever to change to the normal "day" position.
As a safety precaution, the mirrors must be adjusted to reduce the "blind spot".
In order to ensure optimum visibility during your manoeuvres, the mirror lightens automatically when reverse gear is engaged.
Steering wheel adjustment
 When stationar y , lower the control lever ar yto release the steering wheel adjustment mechanism.  Adjust the height and reach to suit your driving position.  Pull the control lever to lock the steering wheel adjustment mechanism.
As a safety precaution, these operations should only be carried out while the vehicle is stationary.

118
i
Driving
Head-up display
System which projects various information onto a smoked strip in the field of vision of the driver so that they do not have to take their eyes off the road. This system operates when the engine is running and the settings are stored when the ignition is switched off.
1. Head-up display on. 2. Head-up display off (long press). 3. Brightness adjustment. 4. Display height adjustment.
Buttons
Once the system has been activated, the following information is grouped together in the head-up display: A. The speed of your vehicle. B. Cruise control/speed limiter information.
Displays during operation
C. Navigation information (according to version).
For more information on the navigation system, refer to the "Audio and telematic" section.
