Page 210 of 330
8195
Practical information
Engine compartment fuses
Access to the fuses
Unclip the cover. Change the fuse (see corresponding paragraph).
When you have finished, close the cover carefully to ensure correct sealing of the fusebox.
Fuse N° Rating (A) Functions
F2015 Front /rear screenwash pump.
F2120 Headlamp wash pump.
F2215 Horn.
F2315 Right-hand main beam headlamp.
F2415 Left-hand main beam headlamp.
F275 Left hand lamp mask.
F285 Right hand lamp mask. The fusebox is placed in the engine compar tment near the battery.
Page 215 of 330
8199
Practical information
System which manages the duration of use of cer tain functions to conser ve a sufficient level of charge in the battery. After the engine has stopped, you can still use functions such as the audio and telematics system, windscreen wipers, dipped beam headlamps, cour tesy lamps, etc. for a maximum combined duration of thir ty minutes.
Energy economy mode
Switching to economy
mode
A message then appears in the instrument panel screen indicating that the vehicle has switched to economy mode and the active functions are put on standby.
If a telephone call is being made at this time,
it will be maintained for around 10 minutes with the Bluetooth hands-free system of your Peugeot Connect Sound or Peugeot Connect Navigation.
Exiting economy mode
These functions are reactivated automatically next time the vehicle is driven. In order to resume the use of these functions immediately, star t the engine and let it run: - for less than ten minutes, to use
the equipment for approximately five minutes, - for more than ten minutes, to use the equipment for up to approximately thir ty minutes. Let the engine run for the duration specified to ensure that the battery charge is sufficient. Do not repeatedly and continuously restar t the engine in order to charge the battery. A flat battery prevents the engine from star ting (refer to the "Battery" section).
Page 226 of 330
210
Checks
checking the levels of the various fluids and for replacing cer tain components.
Petrol engines
1. Power steering reser voir. 2. Screenwash and headlamp wash reser voir. 3. Coolant reser voir. 4. Brake fluid reser voir. 5. Battery/Fuses. 6. Fusebox. 7. Air filter. 8. Engine oil dipstick. 9. Engine oil filler cap.
1.6 16V VTi 120 hp
1.6 16V THP 155 hp
Page 227 of 330
9211
Checks
The various caps and covers allow access for checking the levels of the various fluids, for replacing cer tain components and for priming the fuel system.
* According to engine.
Diesel engines
1. Power steering reser voir. 2. Screenwash and headlamp wash reser voir. 3. Coolant reser voir. 4. Brake fluid reser voir. 5. Battery/Fuses. 6. Fusebox. 7. Air filter. 8. Engine oil dipstick. 9. Engine oil filler cap. 10. Priming pump * . 11. Bleed screw * . 1.6 Turbo HDi 110 hp
2.0 Turbo HDi 140 hp
Page 228 of 330
212
Checks
checking the levels of the various fluids, for replacing cer tain components and for priming the fuel system.
* According to engine.
Diesel engines
1. Power steering reser voir. 2. Screenwash and headlamp wash reser voir. 3. Coolant reser voir. 4. Brake fluid reser voir. 5. Battery/Fuses. 6. Fusebox. 7. Air filter. 8. Engine oil dipstick. 9. Engine oil filler cap. 10. Priming pump * . 11. Bleed screw * . 2.0 Turbo HDi 163 hp
2.2 Turbo HDi 200 hp
Page 230 of 330
214
Checks
The coolant level should be close to the "MA X" mark but should never exceed it. When the engine is warm, the temperature of the coolant is regulated by the fan. This can operate with the ignition off. On vehicles which are fitted with a par ticle emission filter, the fan may operate after the vehicle has been switched off, even if the engine is cold.
In addition, as the cooling system is pressurised, wait at least one hour after switching off the engine before carrying out any work. To avoid any risk of scalding, unscrew the cap
by two turns to allow the pressure to drop. When the pressure has dropped, remove the cap and top up the level.
Changing the coolant
The coolant does not have to be changed.
F l u i d s p e c i fi c a t i o n
The coolant must conform to the manufacturer's recommendations. F l u i d s p e c i fi c a t i o n
For optimum cleaning and to avoid freezing, this fluid must not be topped up with or replaced with plain water.
Screenwash and headlamp
wash fluid
In the case of vehicles fitted with headlamp washers, the low fluid level is indicated by an audible signal and a message in the instrument panel screen. Top up the reser voir when you stop the vehicle.
Page 289 of 330
275
11
1
2
3a
3b
1
2
3
4
CONFIGURATION
Press SETUP to display the " C o n fi g u r a t i o n " menu.
Select " Adjust luminosity " a n d c o n fi r m t o a d j u s t t h e s c r e e n b r i g h t n e s s .
Press " OK " t o s a v e t h e c h a n g e s .
T h e s e t t i n g s f o r d a y a n d n i g h t a r e independent.
Select " Choose colour " a n d c o n fi r m t o Choose colourselect the screen colour harmony and the map presentation mode:
- day mode,
- n i g h t m o d e ,
- a u t o m a t i c d a y / n i g h t m o d e , a c c o r d i n g t o w h e t h e r t h e headlamps are on.
SETTING THE DATE AND TIME
Select " Set date and time " and c o n fi r m .
S e l e c t t h e s e t t i n g t o a d j u s t .
C o n fi r m b y p r e s s i n g OK , then adjust t h e s e t t i n g a n d c o n fi r m a g a i n t o s a v e t h e m o d i fi c a t i o n .
Select " D i s p l a y c o n fi g u r a t i o n " and c o n fi r m .
Press SETUP to display the " C o n fi g u r a t i o n " menu.
Select " D i s p l a y c o n fi g u r a t i o n " and c o n fi r m .
A d j u s t t h e s e t t i n g s o n e b y o n e .
Then select " OK " on the screen and c o n fi r m t o s a v e t h e s e t t i n g s .
DISPLAY CONFIGURATION
Select " Synchronize the minutes with GPS " s o t h a t s e t t i n g t h e minutes is done automatically by satellite reception.
