2010.5 Citroen DS4 sensor

Lighting dimmer fixed. The lighting dimmer is making an adjustment. You can adjust the level of illumination of the instruments between 1 and 16.
Passenger's airbag system fixed in the seat belt and passenger’s front airbag warning lamps display.
The control switch, located in the glove box, has been placed in the "ON" position.The passenger's front airbag is activated. In this case, do not install a "rear facing" child seat.
Move the control switch to the "OFF" position to deactivate the passenger's front airbag. In this case, you can install a "rear facing" child seat.
Automatic wiping fixed. The wiper control is pushed downwards. Automatic front wiping is activated.
Warning lampis onCauseAction/Obser vations
Stop & Star t
fixed. The Stop & Star t system has put the engine in STOP mode at a vehicle stop (traffic lights, traffic jam, or other...).
The warning lamp goes off and the engine restar ts automatically in START mode, as soon as you want to move off.
flashes for a few seconds, then goes off.
STOP mode is temporarily unavailable. or START mode is invoked automatically.
Refer to "Driving - § Stop & Star t" for special cases with STOP mode and START mode.
Parking space sensors fixed. The parking space sensors function is selected. To star t measurement, operate the direction indica tor on the side of the space to be measured, and do not exceed 12 mph (20 km/h). A message is displayed once the measurement has been completed.

Monochrome screen C
This displays the following information: - time, - date, - ambient temperature (this flashes if there is a risk of ice), - openings check (if a doors or the boot is open), - parking sensor information, - current audio source, - telephone or Bluetooth system information, - trip computer (refer to the end of the section). Warning messages (e.g.: "Emission control system faulty") or information messages (e.g.: "Automatic switching on of the headlamps activated") may appear temporarily. These can be cleared by pressing the "ESC" button.
Displays in the screen
From the control panel of your audio system, you can press:  button A to chooses between the display of audio information in full screen or the shared display of audio and trip computer
information,  the "MENU" button for access to the main menu ,  the "  " or "  " buttons to scroll through the items on the screen,  the "  " or "  " buttons to change a setting value,  the "OK" button to confirm, or  the "ESC" button to abandon the operation in progress.
Controls
 Press the "MENU" button for access to the main menu : - "Multimedia", - "Telephone", - "Trip computer", - "Bluetooth connection", - "Personalisation-configuration",  Press the "  " or "  " button to select the menu required, then confirm by pressing the "OK" button.
Main menu

Colour screen and map
It displays the following information automatically and directly: - time, - date, - altitude, - ambient temperature (the value displayed flashes if there is a risk of ice),
- parking sensor information, - audio functions, - directory and telephone information,
- satellite navigation system information.
Displays in the screen
From the navigation system control panel, to select one of the applications:  press the dedicated "R ADIO" , "MUSIC" , "NAV" , "TR AFFIC" , "PHONE" or "SETUP" button for access to the corresponding menu,  turn the wheel A to select a function, an item in a list,  press button B to confirm the selection, or
 press the "ESC" button to abandon the current operation and return to the previous display.
Controls
For more information on these applications, refer to the "Audio and Telematics" section.

77Comfort
Recommendations for ventilation and air con ditioning
If after an extended stop in sunshine, the interior temperature is very high, first ventilate the passenger compar tment for a few moments.
Put the air flow control at a setting high enough to quickly change the air in the passenger compar tment. The air conditioning system does not contain chlorine and does not present any danger to the ozone layer.
In order for these systems to be fully effective, follow the operation and maintenance guidelines below:  To obtain an even air distribution, take care not to obstruct the exterior air intake grilles located at the base of the windscreen, the nozzles, the vents and the air outlets, as well as the air extractor located in the boot.  Do not cover the sunshine sensor, located on the d ashboard; this is used for regulation of the digital air conditioning system.  Operate the air conditioning system for at least 5 to 10 minutes, once or twice a month to keep it in per fect working order.  Ensure that the passenger compar tment filter is in g ood condition and have the filter elements replaced regularly (refer to the "Checks" secti on). We recommend the use of a combined passenger compa r tment filter. Thanks to its special active additive, it contributes to the purification of the air breathed by the occupants and the cleanliness of the passenger compar t ment (reduction of allergic symptoms, bad odours and greasy deposits).  To ensure correct operation of the air conditioning system, you are also advised to have it checked regularly as recommended in the Maintenanc e and Warranty Guide.
 If the system does not produce cold air, switch it off and contact a CITROËN dealer or a qualified workshop. When towing the maximum load on a steep gradient in high temperatures, switching off the
air conditioning increases the available engine power and so improves the towing ability.
The condensation created by the air conditioning results in a discharge of water under the vehicle which is per fectly normal.

Rear view mirror
Adjustable mirror providing a central rear ward view. Equipped with an anti-dazzle system, which darkens t he mirror glass: this reduces the nuisance to the driver caused by the headlamps from following vehic les, low sun...
Manual day/night model
Adjustment
 Adjust the mirror so that the glass is directed correctly in the "day" position.
Day/night position
 Pull the lever to change to the "night" anti-dazzle position.  Push the lever to change to the normal "day" position.
By means of a sensor, which measures the light from the rear of the vehicle, this system automatically and progressively changes between the day and night uses.
Automatic day/night model
In order to ensure optimum visibility during your manoeuvres, the mirror lightens automatically when reverse gear is engaged.
As a safety measure, the mirrors should be adjusted to reduce the "blind spot".

C. Foglamp selection ring. The foglamps operate with the dipped and main beam headlamps.
Rotate and release the ring C :  for wards a first time to switch on the front foglamps,  for wards a second time to switch on the rear foglamps,  rear wards a first time to switch off the rear foglamps,  rear wards a second time to switch off the front foglamps.
Model with front and rear foglamps
In good or rainy weather, by both day and night, the front foglamps and the rear foglamps are prohibited. In these situations, the power of their beams may dazzle other drivers. They should only be used in fog or falling snow. In these weather conditions, you should switch on the foglamps and dipped beam headlamps manually, as the sunshine sensor may detect sufficient light. Do not forget to switch off the front and rear foglamps when they are no longer necessary.
front and rear foglamps
When the headlamps switch off with automatic illumination of headlamps (AUTO model) or when the dipped beam headlamps are switched off manually, the foglamps and sidelamps remain on.  Turn the ring rear wards to switch off the foglamps, the sidelamps will then switch off.

127Visibility
Operating fault
In the event of a malfunction of the sunshine sensor, the lighting comes on, this warning lamp is displayed in the instrument panel and/or a message appears in the screen, accompanied by an audible signal. Contact a CITROËN dealer or a qualified workshop.
In fog or snow, the sunshine sensor may detect sufficient light. In this case, the lighting will not come on automatically. Do not cover the sunshine sensor, coupled with the rain sensor and located in the centre of the windscreen
behind the rear view mirror; the associated functions would no longer be controlled.
Exterior welcome lighting
The remote switching on of the lighting and side spotlamps makes your approach to the vehicle easier in poor light. It is activated depending on the light level detected by the sunshine sensor.
Switching on
Switching off
The exterior welcome lighting switches off automatically after a set time, when the ignition is switched on or on locking the vehicle.
Programming
 Press the open padlock on the remote control.
The dipped beam headlamps and the sidelamps come on, as well as the side spotlamps, located under the door mirrors; your vehicle is also unlocked.
The lighting duration is selected via the vehicle configuration menu.

127Visibility
Operating fault
In the event of a malfunction of the sunshine sensor, the lighting comes on, this warning lamp is displayed in the instrument panel and/or a message appears in the screen, accompanied by an audible signal. Contact a CITROËN dealer or a qualified workshop.
In fog or snow, the sunshine sensor may detect sufficient light. In this case, the lighting will not come on automatically. Do not cover the sunshine sensor, coupled with the rain sensor and located in the centre of the windscreen
behind the rear view mirror; the associated functions would no longer be controlled.
Exterior welcome lighting
The remote switching on of the lighting and side spotlamps makes your approach to the vehicle easier in poor light. It is activated depending on the light level detected by the sunshine sensor.
Switching on
Switching off
The exterior welcome lighting switches off automatically after a set time, when the ignition is switched on or on locking the vehicle.
Programming
 Press the open padlock on the remote control.
The dipped beam headlamps and the sidelamps come on, as well as the side spotlamps, located under the door mirrors; your vehicle is also unlocked.
The lighting duration is selected via the vehicle configuration menu.
