2010.5 Citroen DS4 key

Locking
 Press button A to lock the vehicle. The red indicator lamp in the button comes on.
Central locking control
System which provides full manual locking or unlocking of the doors from the inside.
If one of the doors is open, central locking from the inside does not take place.
Unlocking
 Press button A again to unlock the vehicle. The red indicator lamp in the button goes off.
If the vehicle is locked from the outside, button A is inactive.  In this case, use the remote control or the key to unlock the vehicle or pull an interior door handle to open a door.

Triggering of the alarm
This is indicated by sounding of the siren and flashing of the direction indicators for thir ty seconds. The monitoring functions remain active until the alarm has been triggered eleven times in succession. When the vehicle is unlocked using the remote control, rapid flashing of the indicator lamp in the button informs you that the alarm was triggered during your absence. When the ignition is switched on, this flashing stops immediately. Automatic activation *
2 minutes after the last door or the boot is closed, the system is activated automatically.  To avoid triggering the alarm on entering the vehicle, first press the unlocking button on the remote control.
Failure of the remote control
To deactivate the monitoring functions:
Locking the vehicle without
activating the alarm
 Lock or deadlock the vehicle using the key in the driver's door lock.
 Unlock the vehicle using the key in the driver's door lock.  Open the door; the alarm is triggered.  Switch on the ignition; the alarm stops. The indicator lamp in the button goes off.
Operating fault
When the ignition is switched on, fixed illumination of the indicator lamp in the button indicates a fault with the system. Have it checked by a CITROËN dealer or a qualified workshop.
* According to country.

111Access
Doors
Opening
From outside
 After unlocking the vehicle completely using the remote control or the key, pull the
door handle.
From inside
 Pull the front door control to open the door; this unlocks the vehicle completely.  Pull the rear door control to open the door; this unlocks only the door opened.
Closing
When a door is not closed correctly:
- when the engine is running , this warning lamp comes on, accompanied by a message in the multifunction screen for a few seconds,
- when the vehicle is moving (speed higher than 6 mph (10 km/h)), this warning lamp comes on, accompanied by an audible signal and a message in the multifunction screen for a few seconds.
When the selective unlocking is
activated, the first press of the remote control unlocking button permits unlocking of the driver's door only.
With the selective unlocking activated: - the driver’s door control unlocks the driver’s door only. - the passenger’s door control unlocks the other doors and the boot. The interior door controls do not operate when the vehicle is deadlocked.

To lock or unlock the doors manually in the
event of a malfunction of the central locking system or battery failure.
Emergency control
Locking the driver's door
 Inser t the key in the lock, then turn it to the rear.
Unlocking the driver's door
 Inser t the key in the lock, then turn it to the front.
Locking the front and rear passenger doors
 On the rear doors, check that the child lock is not activated.  Remove the black cap, located on the edge of the door, using the key.  Inser t the key in the socket without forcing it, then without turning it, move the latch sideways towards the inside of the door.  Remove the key and refit the cap.
Unlocking the front and rear passenger doors
 Pull the interior door opening control.

113Access
Boot
Unlocking the boot
 Press this button to unlock the boot. As a safety measure, this action does
not unlock the doors.
Closing
 Lower the boot lid using the interior grab handle.
If the tailgate is not closed correctly:
- when the engine is running , this warning lamp comes on, accompanied by a message in the multifunction screen for a few seconds,
- when the vehicle is moving (speed above 6 mph (10 km/h)), this warning lamp comes on, accompanied by an audible signal and a message in the multifunction screen for a few seconds.
System for mechanical unlocking of the boot in the event of a battery or central locking malfunction.
Tailgate release
Unlocking
 Fold back the rear seats to gain access to the lock from inside the boot.  Inser t a small screwdriver into hole Aof the lock to unlock the tailgate.  After unlocking the boot or the vehicle using the remote control or the key, press the opening control, then raise the tailgate.
Opening
When the selective unlocking is activated, the boot can be opened at the second press of the unlocking button on the remote control.

115Access
Safety anti-pinch
When the window rises and meets an obstacle, it stops and par tially lowers again.
Reinitialisation
If a window does not rise automatically, its operation must be reinitialised:  pull the control until the window stops,  release the control and pull it again until the window closes fully,  continue to hold the control for approximately one second after the window has closed,  press the control to lower the window automatically to the low position,  when the window has reached the low position, press the control again for approximately one second. The safety anti-pinch function is not operational during these operations.
If the window cannot be closed (for example, in the presence of ice), once the window has lowered:  press and hold the control until the window opens fully,  then pull the control immediately and hold it until the window closes,  continue to hold the control for approximately one second after the window has closed. The safety anti-pinch function is not
operational during these operations.
Always remove the key from the ignition when leaving the vehicle, even for a shor t time. If an obstacle is encountered during operation of the electric windows, you must reverse the movement of the window. To do this, press the control concerned. When the driver operates the passenger's electric window control, they must ensure that nothing is preventing the windows closing correctly. The driver must ensure that the passengers use the electric windows correctly. Be aware of children when operating the windows.

Fuel tank Capacity of the tank: approximately 60 litres.
Low fuel level
Refuelling
Additions of fuel must be of at least 5 litres to be registered by the fuel gauge. Opening the filler cap may result in an inrush of air. This vacuum is entirely normal and results
from the sealing of the fuel system.
 Press control A until the automatic opening of the fuel flap is heard. This control remains active for a few minutes after switching off the ignition. If necessary, switch the ignition on again to reactivate it.  Take care to select the pump that delivers the correct fuel for your vehicle.
 Introduce the nozzle so as to push in the metal non-return flap B.  Make sure that the nozzle is pushed in as far as possible before star ting to refuel (risk of blowback).  Maintain this position while refuelling.  Push the fuel flap to close it. If you are filling your tank to the top, do not persist after the third cut- off; this could cause your vehicle to malfunction.
When the low fuel level in the tank is reached, this warning lamp on
the instrument panel comes on, accompanied by an audible warning and a message in the screen. When it first comes on, around 6 litres of fuel remain in the tank. You must refuel as soon as possible to avoid running out.
With Stop & Star t, never refuel with the system in STOP mode; you must switch off the ignition with the key.

1. Front cour tesy lamp
2. Front map reading lamps3. Rear cour tesy lamp4. Rear map reading lamps
Courtesy lamps
In this position, the cour tesy lamp comes on gradually:
Front and rear courtesy lamps
- when the vehicle is unlocked, - when the key is removed from the ignition, - on opening a door, - when the remote control locking button is used to locate your vehicle.
It switches off gradually: - when the vehicle is locked, - when the ignition is switched on, - 30 seconds after the last door is closed.
Permanently off.
Permanent lighting.
In permanent lighting mode, the lighting time varies according to the circumstances: - with the ignition off, approximately ten minutes, - in energy economy mode, approximately thir ty seconds, - with the engine running, unlimited. When the cour tesy lamp is in the "permanent lighting" position, the rear cour tesy lamp also comes on, except if it is in the "permanently off " position. To switch off the rear cour tesy lamp, put it in the the "permanently off " position.
Front and rear map reading
lamps
 With the ignition on, press the corresponding switch.
Take care not to put anything in contact with the cour tesy lamps.
