2009 SKODA YETI service

Breakdown assistance
228
– Align the lifting jack* so that its claw grasps the web of the lower sill at the height
of the marking on the plasti
c cover and the base plate
is resting flat with its
complete surface ag
ainst firm ground.
– Turn the lifting jack* up further until
the wheel is just cl
ear of the ground.
Ground below the lifting jack which is soft and slippery
can cause the vehicle to slip
off the jack. It is therefore always necessary
to place the lifting jack* on a solid surface
or use a wide and stable base. Use a non-sl
ip base (e.g. a rubber foot mat) if the
surface is smooth
, such as cobbled stones, a tiled floor, etc.
WARNING
•
Always raise the vehicle with the doors closed - risk of injury!
•
Take suitable measures to prevent the base of the lifting jack from slipping
off - risk of injury!•
Not positioning the lifting jack at the specified points can result in damage
to the vehicle. The jack can also slip off if it does not have sufficient grip - risk of injury!•
It is important to support the vehicle with suitable supporting blocks if you
wish to work under the lifted vehicle - risk of injury!Securing wheels against being stolen* You need a special adapter for sl
ackening the safety wheel bolts.
– Pull off the full wheel trim/cap from the wheel hub or cap from the safety wheel
bolt.
– Insert the adapter with its toothed side into the inner toothing of the head of
the safety wheel bolt
⇒fig. 188
.
– Insert the wheel wrench fully onto the adapter .– Slacken the wheel bolt, or tighten it firmly
⇒page 227.
– Reinstall the full wheel trim/wheel cap after removing the adapter or place the cap
onto the safety wheel bolt.
– Have the
tightening torque
checked
with a torque wrench as soon as possible.
Steel and light alloy wheels must be tightened to a tightening torque of
120 Nm
.
The safety wheel bolts on vehicles fitted with them (one safety wheel bolt per wheel) can only be loosened or tighten
up by using the adapter provided.
It is meaningful to note th
e code number hammered into the rear side of the adapter
or the rear side of the safety wheel bolts.
You can obtain a replacement adapter from
an authorised Škoda Service Partner, if necessary, by quoting this number. We recommend that you always carry the ad
apter for the wheel bolts with you in the
vehicle. It should be stow
ed in the vehicle tool kit.
Caution
Damage can occur to the adapter and safety wh
eel bolt if the safety wheel bolt is tight-
ened up too much.
Note
The set of safety wheel bolts can be obta
ined from an authorised Škoda Service
Par tner.
AAAB
Fig. 188 Safety wheel bolt with adapter
ABAA
AB
sgg.6.book Page 228 Thursday, September 24, 2009 2:32 PM

Breakdown assistance
229
Using the system
Safety
Driving Tips
General Maintenance
Breakdown assistance
Technical Data
Jump-startingInitial stepsYou can use the battery of another vehicle fo
r jump-starting yours if the engine does
not start because the battery on your vehicle
is flat. You will requ
ire jump-start cables
for this purpose. Both batteries must have a rated voltage of 12 V. The
capacity
(Ah) of the battery
supplying the power must not be significantly less than the capacity of the discharged battery in your vehicle. Jump-start cables Only use jump-start cables which have an
adequately large cross-section and insu-
lated terminal clamps. Plea
se pay attention to the manufacturer's instructions.
Positive cable -
colour coding in the
majority of cases red.
Negative cable -
colour coding in the
majority of cases black.
WARNING
•
A discharged battery may already freeze
at temperatures just below 0°C. In
case of frozen battery carry out no jump-starting - risk of explosion!•
Please pay attention to the warning instructions relating to working in the
engine compartment
⇒page 204, “Working in the engine compartment”.
Note
•
There must not be any contact between
the two vehicles otherwise current may
flow as soon as the negati
ve terminals are connected.
•
The discharged battery must be properly
connected to the system of the vehicle.
•
Switch off any mobile phone, pay attention
to the instructions for use of the mobile
phone in such a situation.•
We recommend purchasing jump-start cabl
es from Škoda Service Partners as a
Škoda original accessory or from retailers who sell branded batteries.
Start engineIt is important to connect the jump-start cables in the correct order.Connecting positive terminals– Attach one end to the positive terminal
⇒fig. 189
of the discharged battery
.
– Attach the other end to the positive te
rminal of the battery supplying the power
.
Connecting negative term
inal and engine block
– Attach one end to the negative termin
al of the battery supplying the power .
– Attach the other end to a solid metal
part which is connected firmly to the
engine block, or to the engine block itself.
Starting the engine– Start the engine of the vehicle providing
current and run the engine at idling speed.
– Now start the engine of the vehicle with the discharged battery. – Interrupt the attempt at starting an engine after 10 seconds if it does not start right
away and wait for about 30 seconds before repeating the attempt.
– Disconnect the cables on the engine in exactly the
reverse order
they were
connected up.
Fig. 189 Jump-starting using the battery from another vehicle: A - flat vehicle battery, B - battery providing current
A1
AA
A2
AB
A3
AB
A4
sgg.6.book Page 229 Thursday, September 24, 2009 2:32 PM

Technical Data
243
Using the system
Safety
Driving Tips
General Maintenance
Breakdown assistance
Technical Data
Te c h n i c a l D a t aTechnical DataGeneral informationThe details given in the official vehicle regi
stration documents always take precedence
over the details in the Owner's Manual. Please refer to the official vehicle registration documents or consult a specialist garage
concerning the engine with which your
vehicle is equipped.Used abbreviations
PerformancesThe listed performance values were de
termined without performance-reducing
equipment, e.g. air
conditioning system.
WeightThe loading capacity is reduced in line with the range of the special equipment. The unloaden weight contains a fuel tank topped
up to 90%. A driver with a weight of 75
kg is also includ
ed in the value.
Identification detailsVehicle data sticker The vehicle data sticker
⇒fig. 206
is located on the floor of the luggage compartment
and is also stated in the Service schedule. The vehicle data sticker co
ntains the following data:
Vehicle identification number (VIN) Vehicle type
Abbreviation
Importance
kW
Kilowatt, measuring unit for the engine output
rpm
Engine revolutions per minute
Nm
Newton meter, measuring
unit for the engine torque
g/km
discharged quantity of carbon dioxide in grams per driven kilometer
RON
Research octane number, meas
uring unit for the knocking
resistance of petrol
TSI
Petrol engine with a turbocharger and a direct fuel injection system
TDI CR
Diesel engine with turbocharger and injection system Com- mon Rail
M5 / M6
5-speed/6-speed manual gearbox
DQ6/DQ7
6 speed-/7 speed automatic gearbox DSG
DPF
Diesel particle filter
Fig. 206 Vehicle data sticker
A1A2
sgg.6.book Page 243 Thursday, September 24, 2009 2:32 PM

Technical Data
246
Engine oil specificationsThe grade of engine oil should be se
lected in accordance with precise
specifications.The engine of your vehicle has been factory-
filled with a high-grade oil which you can
use throughout the year - except in extreme climatic regions. You can mix various oils together with each other when refilling with oil. This does not, however, apply for models with flexible service intervals (QG1). Engine oils are, of course, undergoing co
ntinuous further deve
lopment. Thus the
information stated in this Owner's Manual is
only correct at the time of publication.
Specialist garages are informed by Škoda
Auto about current changes. We recommend
having this oil change undertaken by a specialist garage. The specifications (VW standards) stated in the following must be indicated separately or together with other specifications on the bottle. Engine oil specifications for models
with flexible service intervals (QG1)
Engine oil specifications for vehicles with fixed service intervals (QG2)
If the oils specified above are not available, oils according to ACEA A2 or ACEA A3 can be used once for refilling. If the oils specified above are not available,
oils according to ACEA B3 or ACEA B4 can
be used once for refilling.
Caution
Only the above-mentioned oils may be used on vehicles with flexible service intervals (QG1). We recommend always refilling with oi
l of the same specification since this will
maintain the properties of the oil. In exce
ptional cases, you must top up only once
engine oil complying with Specification VW 50
2 00 (only for petrol engines) or Specifi-
cation VW 505 01 (only for diesel engines) to maximum 0.5 litres. You must not use other engine oils - risk of engine damage!
Note
•
Before a long drive we recommend that
you purchase and carry with you engine
oil which complies with the specification for your vehicle. Consequently, you will always have the correct engine oil for refilling.•
We recommend using a preservative from the Škoda original accessories offered
by your Škoda dealer.•
For further information - see Service shedule.
Petrol engines
Engine oil specifications
1.2 ltr./77 kW TSI - EU5
VW 504 00
1.8 ltr./118 (112) kW TSI - EU5
VW 504 00
Diesel engines
Engine oil specifications
2.0 ltr./81 kW TDI CR DPF - EU5
VW 507 00
2.0 ltr./103 kW TDI CR DPF - EU5
VW 507 00
2.0 ltr./125 kW TDI CR DPF - EU5
VW 507 00
Petrol engines
Engine oil specifications
1.2 ltr./77 kW TSI - EU5
VW 502 00
1.8 ltr./118 kW TSI - EU5
VW 502 00
Diesel engines
Engine oil specifications
2.0 ltr./81 kW TDI CR DPF - EU5
VW 507 00
2.0 ltr./103 kW TDI CR DPF - EU5
VW 507 00
2.0 ltr./125 kW TDI CR DPF - EU5
VW 507 00
sgg.6.book Page 246 Thursday, September 24, 2009 2:32 PM

Index263
Using the system
Safety
Driving Tips
General Maintenance
Breakdown assistance
Technical Data
RRadiator fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 209
Rear armrest . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Rear fog light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Warning light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Rear interior lighting . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Rear seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Rear window
heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Rear window heater . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Rear-view mirror
Exterior mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Interior mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Recharge battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 212
Refuelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Synchronisation . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Removing seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Replacing fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233
Replacing the wiper blades . . . . . . . . . . . . . . . . . . . . 65
Roof aerial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193
Roof luggage rack system . . . . . . . . . . . . . . . . . . . . . . 84
Running in the car . . . . . . . . . . . . . . . . . . . . . . . . . . . 173SSafe securing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Safety information
Engine compartment . . . . . . . . . . . . . . . . . . . . . 204
Safety wheel bolts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 228Saving electrical energy . . . . . . . . . . . . . . . . . . . . . . . 174
Seat belt height adjuster . . . . . . . . . . . . . . . . . . . . . . 143
Seat belt warning light . . . . . . . . . . . . . . . . . . . . . . . . 143
Seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Belt tensioners . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199
fastening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Height adjustment . . . . . . . . . . . . . . . . . . . . . . . . 143
Safety information . . . . . . . . . . . . . . . . . . . . . . . . 142
taking off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Warning light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Seat heaters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Selector lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
Selector lever lock
Warning light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Selector lever positions . . . . . . . . . . . . . . . . . . . . . . . 122
Selector lever-emergency unlocking . . . . . . . . . . . 125
Service Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Service Interval Display . . . . . . . . . . . . . . . . . . . . . . . . 18
Setting temperature
Heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Shifting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Side airbag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
Side lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Snow chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219
Spare wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 224
Speedometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Stability system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163Starting the engine . . . . . . . . . . . . . . . . . . . . . . . . . . 110
after fuel tank has run empty . . . . . . . . . . . . . 111
Diesel engines . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Petrol engines . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Steering
active driver-steering recommendation . . . 166
Steering force assistance . . . . . . . . . . . . . . . . . . . . . 168
Storage compartments . . . . . . . . . . . . . . . . . . . . . . . . 88
Storage facilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Sun . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Switching lights on and off . . . . . . . . . . . . . . . . . . . . . 53
Switching off the engine . . . . . . . . . . . . . . . . . . . . . 111
TTailgate
Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Taking care of your vehicle . . . . . . . . . . . . . . . . . . . 193
TCS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165
Warning light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Temperature
outside . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
the first 1 500 kilometres . . . . . . . . . . . . . . . . . . . . . 173
Thickness of brake pads
Warning light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Tilting roof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Tiptronic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 223
Top Tether . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162
Towing a trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190
Towing device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192
sgg.6.book Page 263 Thursday, September 24, 2009 2:32 PM

Škoda Auto pursues a policy of constant product and model development. We trust
that you will understand that changes to models in terms of shape, equipment and
engineering, may be introduced at any time. The information about scope of delivery,
appearance, performances, dimensions, weight, fuel consumption, standards and
functions of the vehicle is only correct at the time of publication. Certain items of
equipment might only be installed later on (information given by the local Škoda
Service Partner) or only envisaged for particular markets. It is therefore not possible for
legal claims to be made based on the data, illustrations and descriptions contained in
this Owner's Manual.Reprinting, reproduction or translation, either in whole or in part, is not permitted
without the written consent of Škoda Auto.
Škoda Auto expressly reserves all rights relating to copyright laws.
We reserve the right to make changes to this document.
Issued by: ŠKODA AUTO a.s.
© ŠKODA AUTO a.s. 2009sgg.6.book Page 268 Thursday, September 24, 2009 2:32 PM

ŠkodaService
ŠkodaGenuine Parts
ŠkodaGenuine Accessories
SIMPLY CLEVER
A-SUV_11_09.indd 6A-SUV_11_09.indd 69.9.2009 13:57:339.9.2009 13:57:33
