2009 RENAULT TWINGO RS light

81A-8
REAR LIGHTING
Number plate light: Removal - Refitting
81A
REMOVAL
I - REMOVAL PREPARATION OPERATION
aSwitch off the ignition.
II - REMOVAL OPERATION FOR PART
CONCERNED
aUnclip the license plate lights at (1) with a small flat-
blade screwdriver.
aDisconnect the license plate light connectors.
aRemove the license plate light bulbs (see 81A, Rear
lighting, Rear light bulb: Removal - Refitting,
page 81A-4) .
REFITTING
REFITTING OPERATION FOR PART CONCERNED
aRefit the license plate light bulbs (see 81A, Rear li-
ghting, Rear light bulb: Removal - Refitting, page
81A-4) .
aConnect the number plate light connectors.
aClip on the number plate lights.
121082

81B-1
INTERIOR LIGHTING
Interior lighting: List and location of components
81B
I - LIST OF COMPONENTS
II - LOCATION OF COMPONENTS
1 - Courtesy light2 - Door switch
3 - Luggage compartment light No. Description
(1) Courtesy light
(2) Door switch
(3) Luggage compar tment light
121390
121383
119529

81B-2
INTERIOR LIGHTING
Interior light: Removal - Refitting
81B
REMOVAL
OPERATION FOR REMOVAL OF PART
CONCERNED
aUnclip the translucent cover at (1) using a small flat-
blade screwdriver.
aRemove the bulbs (2) .
aUnclip the courtesy lights (3) at (4) using a small flat-
blade screwdriver.
aDisconnect the courtesy lights connector.
REFITTING
aConnect the courtesy lights connector.
aClip the courtesy lights onto their mounting.
aRefit the bulbs.
aFit the translucent cover onto the courtesy lights.
121390
121389
Note:
If the bulbs are changed, use W5W approved
bulbs.

81B-3
INTERIOR LIGHTING
Door switch: Removal - Refitting
81B
REMOVAL
I - REMOVAL PREPARATION OPERATION
aRemove:
-the rear parcel shelf side trim (see Rear parcel
shelf side trim: Removal - Refitting) (MR 412,
71A, Seat internal trim),
-the rear panel trim (see Rear panel lining: Remo-
val - Refitting) (MR 412, 71A, Seat internal trim).
II - OPERATION FOR REMOVAL OF PART
CONCERNED
aDisconnect the connector (1) from the door switch.
aRemove the door switch at (3) by pressing on the
clips (2) .
REFITTING
I - REFITTING OPERATION FOR PART
CONCERNED
aFit the door switch.
aConnect the door switch connector.
121382
121384
121383

81B-4
INTERIOR LIGHTING
Door switch: Removal - Refitting
81B
II - FINAL OPERATION.
aRefit:
-the rear panel trim (see Rear panel lining: Remo-
val - Refitting) (MR 412, 71A, Seat internal trim),
-the rear parcel shelf side trim (see Rear parcel
shelf side trim: Removal - Refitting) (MR 412,
71A, Seat internal trim).

81B-5
INTERIOR LIGHTING
Luggage compartment light: Removal - Refitting
81B
REMOVAL
aUndo the luggage compartment light (1) using a
scratch awl (2) .
aDisconnect the luggage compartment lighting con-
nector.
aUnclip the bulb mounting (3) from the translucent co-
ver (4) at (5) .
aRemove the bulb.
REFITTING
REFITTING OPERATION FOR PART CONCERNED
aRefit the bulb.
aFit the bulb mounting onto the translucent cover.
aConnect the luggage compartment light connector.
aClip the luggage compartment light onto the rear
parcel shelf side trim.
121388
121387
Note:
If the bulb is changed, use a W5W approved
bulb.

84A-1
CONTROL - SIGNALS
Steering column switch assembly: List and location of components84A
I - LIST OF COMPONENTS
II - LOCATION OF COMPONENTS
1 - UCH
2 - Steering column switch assembly
(2) : Wiper switch (3) : Indicator light switch
(4) : Telephone/radio control satellite
No. Description
(1) UCH
(2) Windscreen wiper switch
(3) Signalling light switch
(4) Telephone/radio control satellite
119507
119494

84A-8
CONTROL - SIGNALS
Signals and lighting switch: Removal - Refitting
84A
REMOVAL
I - REMOVAL PREPARATION OPERATION
aRemove the rev counter (see 83A, Instrument pa-
nel, Rev counter: Removal - Refitting, page 83A-
3) .
aRemove the lower cover bolts (1) .aUnclip the upper cover at (2) .
aRemove the upper cover (3) .
aRemove the lower cover (4) . ENGINE REV COUNTER
127437
127438
127439
