2009 MAZDA MODEL B4000 CAB PLUS 4 TRUCK Owners Manual

BRAKE FLUID
The fluid level will drop slowly as
the brakes wear, and will rise when
the brake components are replaced.
Fluid levels between the “MIN” and
“MAX” lines are within the normal
operating range; there is no need to
add fluid. If the fluid levels are
outside of the normal operating
range the performance of the
system could be compromised; seek
service from your authorized dealer
immediately.
CLUTCH FLUID (IF EQUIPPED)
Check the fluid level. Refer toscheduled maintenancefor the service
interval schedules.
During normal operation, the fluid level in the clutch reservoir should
remain constant. If the fluid level drops, refill the fluid level to the step
in the reservoir.
Use only a DOT 3 brake fluid designed to meet Mazda specification.
Refer to Maintenance product specifications and capacities in this
chapter.
WARNING: Carefully read cautionary information on product
label. For MEDICAL EMERGENCY INFORMATION contact a
physician or Poison Control Center immediately. Failure to follow these
instructions may result in personal injury.
1. Clean the reservoir cap before removal to prevent dirt and
water from entering the
reservoir.
2. Remove cap and rubber diaphragm from reservoir.
3. Add fluid until the level reaches the step in the reservoir.
4. Reinstall rubber diaphragm and cap onto reservoir.
2009 B-Series (mbs)
Owners Guide, 1st Printing
USA (fus)
Maintenance and Specifications
265

AIR FILTER
Refer toscheduled maintenance for the appropriate intervals for
changing the air filter element.
When changing the air filter element, only use a genuine Mazda air filter
element.
WARNING: To reduce the risk of vehicle damage and/or
personal burn injuries do not start your engine with the air
cleaner removed and do not remove it while the engine is running.
Note: Failure to use the correct air filter element may result in severe
engine damage. The customer warranty may be void for any damage to
the engine if the correct air filter element is not used.
2009 B-Series (mbs)
Owners Guide, 1st Printing
USA (fus)
Maintenance and Specifications
270

MAINTENANCE PRODUCT SPECIFICATIONS AND CAPACITIES
ItemApplicationMazda part name or
equivalent Capacity
Brake fluid and clutch fluid (if equipped) AllHigh Performance DOT 3
Motor Vehicle Brake Fluid Between MIN and MAX on
reservoir
1
Door weather strips AllSilicone Lubricant —
Hinges, door checks,
latches, striker plates, fuel filler door hinge and seat tracks All Multi-Purpose Grease
—
Transmission
/steering/parking brake
linkages and pivots, brake and clutch pedal shaft All Premium Long-Life Grease
—
Engine coolant 2.3L I4
engine with manual
transmission
Premium Engine Coolant
2
10.5 quarts (10.0L)
2.3L I4
engine with automatic
transmission 10.2 quarts (9.7L)
4.0L V6
engine with manual
transmission 13.7 quarts (13.0L)
4.0L V6
engine with automatic
transmission 13.2 quarts (12.5L)
2009 B-Series
(mbs)
Owners Guide, 1st Printing
USA (fus)
Maintenance and Specifications
271

ItemApplicationMazda part name or
equivalent Capacity
Engine oil 2.3L I4
engine SAE 5W-20 Motor Oil 4 .0 quarts (3.8L)
4.0L V6 engine SAE 5W-30 Motor Oil 5.0 quarts (4.7L)
Power steering fluid All MERCONV AT F Fill between MAX / MIN
line on reservoir
Transfer case fluid (4X4) 4x4 Vehicles Transfer Case Fluid 1.25 quarts (1.2L)
Manual transmission fluid 5-speed
manual MERCON
V ATF 2.8 quarts (2.65L)
3
Automatic transmission
fluid (5R44E and 5R55E) 4x2 vehicles
with 2.3L I4 engine
MERCONV AT F
4
9.9 quarts (9.4L)
5
4x2 vehicles
with 4.0Lengines 10.0 quarts (9.5L)
5
4x4 vehicles
with 4.0Lengines 10.3 quarts (9.8L)
5
Front axle fluid (4X4) 4x4 Vehicles
SAE 80W-90 Premium Rear
Axle Lubricant 3.6 pints (1.7L)
Rear axle fluid AllSAE 80W-90 Premium Rear
Axle Lubricant 5.0-5.3 pints (2.4-2.5L)
6
Windshield washer fluid All Ultra-clear Windshield
Washer Concentrate 2.75 quarts (2.6L)
2009 B-Series
(mbs)
Owners Guide, 1st Printing
USA (fus)
Maintenance and Specifications
272
